- Page 1 OPERATION AND INSTALLATION Solar Thermal Collector » SOL 29 Premium S » SOL 29 Premium W...
-
Page 2: Table Of Contents
OPERATION General Instructions OPERATION OPERATION General Instructions ___________________________________________ 2 Safety instructions __________________________________________________ 2 Other symbols in this documentation __________________________ 3 General Instructions Safety ____________________________________________________________ 3 Intended use _________________________________________________________ 3 This manual includes important information regarding the safe and General safety _______________________________________________________ 3 effi... -
Page 3: Other Symbols In This Documentation
OPERATION Safety Other symbols in this documentation WARNING: Scalding Setting the maximum tank temperature higher than NOTE : 140°F at the control unit is permissible only with a Notes are bordered by horizontal lines above and below thermostatically-controlled DHW mixing valve. Other- the text. -
Page 4: Register Your Product
General product information Regulations, codes, and standards The SOL 29 Premium S & SOL 29 Premium W collectors are solar NOTE : thermal collectors designed for closed-loop operation. The absorber Observe all federal, state, and local codes when per-... -
Page 5: Determining Array Size
2 sub-arrays are needed since the maximum for one array is 10. On-center rafter-mount spacing Generally it is a good idea to have an equal number of collectors # of collectors SOL 29 Premium S SOL 29 Premium W in each sub-array along with a reverse-return pipe confi guration 0’, 4’... -
Page 6: Mounting Hardware Installation
INSTALLATION Installation Mounting hardware installation 6.5.2 Installation of tilt mount racking For a tilt mount system, consult the installation manual for the tilt NOTE : mount racking to pre-assemble the racking kits. Once assembled, The installation surface should have as little height vari- fasten the tilt mount racking to the fl... -
Page 7: Collector Installation
INSTALLATION Installation Collector installation NOTE : The collector has a sensor well near one of the four con- nection points. This sensor well must be oriented so that a sensor can measure the temperature of the solar fl uid as it exits the array. Do not orient the collector so that the sensor well is located at the bottom of the collector. -
Page 8: Collector Connection
INSTALLATION Installation 1 M8 x 20mm bolt Place the collector into the collector frames and fasten the bolt th- rough the collector frame into the collector. There are four fastening Sit the next collector into the frames and slide the inter-panel points on each collector that must be secured. -
Page 9: Temperature Sensor Installation
INSTALLATION Installation 3 Collector connection clip WARNING: Burns Once the collectors are installed, they will begin to heat Secure all external connectors with the collector connection clip. up even during cloudy days. Covering the collectors with an opaque material will make working around and with Material losses: the collectors easier during the installation. -
Page 10: Pipework Installation
The solar heating system must be fi lled exclusively with the pre- Greater than 4˝ 4˝ mixed propylene glycol heat transfer medium. Stiebel Eltron glycol containers have been premixed and require no further treatment. Never mix water with the heat transfer fl uid, otherwise the essential characteristics and corrosion protection can no longer be guaran- teed. -
Page 11: More Information
The system must not be topped off with water. Consult the manual or technical data sheet of the glycol mixture before using. 7.3.1 Freeze limit Glycol provided by Stiebel Eltron provides freeze protection to -30°F (-34°C). Weather conditions beyond this point may damage the sys- tem. -
Page 12: Technical Data
INSTALLATION Technical data Data table Technical data SOL 29 Premium S SOL 29 Premium W Dimensions Item Number 290016 290017 Type Standard / Vertical Wide / Horizontal SOL 29 Premium S Height (A) 82˝ / 2083 mm 49˝ / 1245 mm Width (B) 49˝... -
Page 13: Propylene Glycol Specifi Cations
In case of skin contact, wash off with plenty of water. In case of eye contact, contact a physician. If inhaled or swallowed, contact a phy- sician. For more safety information, contact Stiebel Eltron for more information. www.stiebel-eltron-usa.com SOL 29 Premium |... -
Page 14: Commissioning Guide
INSTALLATION Commissioning guide Serial numbers: 10. Commissioning guide Pump station: The installer should fi ll out this sheet at the end of the installation, Controller: and leave it at the installation site. Software version: Site: System operator: Installation company: Installation site: Collectors: Signature: Date:... -
Page 15: 11. Warranty
This Warranty is valid for U.S.A. & Canada only. Warranties The installation and fi rst operation of this appliance may vary by country. Please consult your local Stiebel Eltron should be carried out by a qualifi ed installer. Representative for the Warranty for your country. - Page 16 STIEBEL ELTRON, Inc. 17 West Street | West Hatfield MA Tel. 0413 247-3380 | Fax 0413 247-3369 info@stiebel-eltron-usa.com www.stiebel-eltron-usa.com 4 < A M H C M O = b c a j h b > Due to our continuous process of engineering and technological Stand 8643 advancement, specifications may change without notice.
