- Page 1 CLICK ANYWHERE on THIS PAGE to RETURN to SOLAR HOT WATER GUIDES at InspectApedia.com OPERATION AND INSTALLATION HIGH PERFORMANCE FLAT-PLATE COLLECTOR » SOL 27 PREMIUM S » SOL 27 PREMIUM W...
-
Page 2: Table Of Contents
Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Table of Contents responsibility of the installer. Failure to comply with the installation and operating instructions or improper use voids the warranty. Save these instructions for future reference. -
Page 3: Collector Basics
Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 The air-side inlet pressure should be ser to 5-7 psi less 2 Collector Basics than the system start-up (cold) pressure; check it when the system has not been fi lled or when the wet side of the The SOL 27 Premium is a highly effi... - Page 4 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Technical Data & Specifi cations single pane safety glass. As the light strikes the absorber plate, it is converted to heat. The highly selective vacuum...
-
Page 5: Assembly Instructions
Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 3 Assembly instructions Recinnebded pipe diameter for systems of up to eight collectors is ¾˝. If the pipe run is longer than 60 feet, a larger pipe diameter may be needed. - Page 6 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Thermal Insulation 4.2 Lifting onto the Roof All exterior piping also requires UV and moisture protection. Insulation must be resistant to temperatures up to 356F.
- Page 7 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 in or out until they are seated fl ush with the rivet nuts. 2. Position the grip on the collector so that it engages around the foot of the collector at the bottom.
- Page 8 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 4.4 Collector Connections Inter-panel Connection WARNING: THE SPACER SHOULD NOT BE REMOVED UNTIL THE COLLECTORS HAVE BEEN LINKED TO ONE ANOTHER. IF THE SPACER IS REMOVED BEFOREHAND, THE CONNECTOR MAY BE DAMAGED WHEN THE SECOND COLLECTOR IS PUSHED INTO PLACE.
- Page 9 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 6. Inulate the connection using the provided thermal and plug-in connection. insulation. Inlet & Outlet Connection The inlets & outlets are plug-in style connections identical to the inter-panel connections.
- Page 10 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 with DIN 571, at least 10 x 80, of stainless steel, per collector. If multiple arrays of collectors are being installed on a fl at roof, one behind another, the recommended spacing between them should be: At least 25 ft.
-
Page 11: Mounting
Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Flush Mount Vertical Side-by-side S panels in a landscape orientation. This allows for fl uid to This array orientation is designed for SOL 27 Premium S be evacuated effectively during stagnation conditions. - Page 12 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Horizontal Tilt Mount Flush Mount Rail Kits Part # # of Collectors The horizontal tilt mount kit is designed to be adjustable in the fi eld to three different angles. It comes partially pre-...
- Page 13 Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Typical System Layout Below is a schematic for a basic solar thermal system using Stiebel Eltron components. Specifi cs of this design may vary, depending on the demands of the job site.
-
Page 14: Pressure & Leak Test
Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 Collector Spacing coated with soapy water, and watching the pressure gauge For latitudes up to 50°, use the following distances for over time. Bear in mind that the pressure gauge will vary mounting solar arrays behind each other. -
Page 15: Warranty
Simply the Best INSTALLATION INSTRUCTIONS SOL 27 PREMIUM S & W COLLECTORS - 230016 & 230017 to the weather must also be checked periodically for their 8. To periods of stagnation in excess of 60 days. condition. Look for signs of abrasion, wear, corrosion, contamination, or damage. - Page 16 Simply the Best APPENDIX A SOL 27 PREMIUM S - SRCC OG-100 CERTIFICATION info @ stiebel-eltron-usa.com 17 West St., W. Hatfi eld, MA 01088 800.582.8423 413.247.3380 fax 413.247.3369 www.stiebel-eltron-usa.com...
- Page 17 Simply the Best APPENDIX A SOL 27 PREMIUM W - SRCC OG-100 CERTIFICATION info @ stiebel-eltron-usa.com 17 West St., W. Hatfi eld, MA 01088 800.582.8423 413.247.3380 fax 413.247.3369 www.stiebel-eltron-usa.com...
- Page 18 Simply the Best COMMISSIONING LOG SOL 27 PREMIUM COLLECTORS The installer should fi ll out this sheet at the end of the installation, and leave it at the installation site. Site: System operator: Installation site: Collectors: Collectors (number / type): Collector surface area: System specifi...
