  • Page 1 BEDIENUNG UND INSTALLATION OPERATION AND INSTALLATION UTILISATION ET INSTALLATION KEZELÉS ÉS TELEPÍTÉS Photovoltaikmodul | Photovoltaic Module | Module photovoltaïque | Napelem modul » Tegreon 265 P » Tegreon 270 P...
  • Page 2 CONTENTS | OPERATION General information OPERATION OPERATION General information ��������������������������������������� 11 Safety instructions ���������������������������������������������� 11 Other symbols in this documentation ���������������������� 12 General information Units of measurement ����������������������������������������� 12 Safety �������������������������������������������������������� 12 The chapters "Special Information" and "Operation" are intended Intended use �����������������������������������������������������...
  • Page 3: Other Symbols In This Documentation

    OPERATION Safety Other symbols in this documentation General safety instructions f Please observe the following: Note - Never use the module near easily combustible gases or va- General information is identified by the adjacent symbol. pours, as sparks may be produced. f Read these texts carefully.
  • Page 4: Installation 3. Safety

    INSTALLATION Safety INSTALLATION Installation The installation frame must be made of a strong and corrosion and weather-resistant material. Safety Clamping the module to the frame Only qualified contractors should carry out installation, commis- The modules may only be clamped to the long and short frame sioning, maintenance and repair of the module.
  • Page 5: Maintenance

    INSTALLATION Maintenance Maintenance 6.2.1 Connection in parallel and in series The modules are low-maintenance. We recommend an annual Note visual inspection. The requirements with regard to earthing must be f Also check the mechanical and electrical connections for checked before commencing work in accordance with the applicable regulations and standards.
  • Page 6: Specification

    INSTALLATION Specification Specification Dimensions and connections ø 5.2 ø 5.2 6 000 Pa 4 200 Pa 2 400 Pa ø 5.2 ø 5.2 13,8 i30 clamping areas www.stiebel-eltron.com TEGREON 265-270 P |...
  • Page 7: Data Table

    INSTALLATION Specification Data table TEGREON 265 P TEGREON 270 P 274218 274219 Electrical data Max. system voltage 1000 1000 Reverse current rating (IR) Efficiency at reduced insolation (200 W/m² instead of 1000 W/m² to EN 60904-1) 97% of STC efficiency...
  • Page 8 GUARANTEE | ENVIRONMENT AND RECYCLING Guarantee The guarantee conditions of our German companies do not apply to appliances acquired outside of Germany. In countries where our subsidiaries sell our products a guarantee can only be issued by those subsidiaries. Such guarantee is only grant- ed if the subsidiary has issued its own terms of guarantee.
  • Page 9   Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
