- Page 1 OperatiOn and installatiOn phOtOvOltaic MOdule » tegreOn 220p » tegreOn 225p » tegreOn 230p...
-
Page 2: Table Of Contents
cOntents | OperatiOn general infOrMatiOn OperatiOn OperatiOn General information �����������������������������������������1 1.1 Safety information � ���������������������������������������������� 1 1.2 Other symbols in this documentation ����������������������� 2 1.3 Units of measurement ������������������������������������������ 2 general information Safety � ���������������������������������������������������������2 The chapter entitled "Operation" is intended for the operator and 2.1 General safety instructions ������������������������������������ 2 the heating contractor. 2.2 Intended use � ����������������������������������������������������� 2 2.3 Instructions, standards and regulations �������������������� 2 The chapter "Installation" is intended for contractors. 2.4 Test symbols ������������������������������������������������������ 2 2.5 CE designation ���������������������������������������������������... -
Page 3: Other Symbols In This Documentation
OperatiOn safetY Other symbols in this documentation - Ensure that no other system components are impairing the modules mechanically or electrically. Note - Never drill holes in the module frame or the glass surface Notes are bordered by horizontal lines above and below and never carry out any welding work on or directly near to the text. General information is identified by the symbol the modules. shown on the left. f Read these texts carefully. - A second person who can provide help in the event of a pos- sible accident is required to be present for the entire installa- tion process. symbol Damage to the appliance and environment intended use The module is designed for use in photovoltaic systems. Appliance disposal Any other use beyond that described shall be deemed inappropri- ate. Observation of these instructions and of instructions for any accessories used is also part of the correct use of this appliance. f This symbol indicates that you have to do something. The ac- We assume no liability for damage arising from failure to observe tion you need to take is described step by step. these instructions, in particular the safety instructions, as well as from misuse of the photovoltaic module. units of measurement instructions, standards and regulations Note All measurements are given in mm unless stated oth-... -
Page 4: Appliance Description
installatiOn safetY installatiOn installation Depending on the frame configuration, the modules can be se- cured with screws or clamped. The installation frame must be made of a strong and corrosion and weather-resistant material. safety securing the module to the frame with screws Only qualified contractors should carry out installation, commis- sioning, maintenance and repair of the module. appliance description required accessories Your photovoltaics dealer can advise you on which accessories are suitable for your module. You require the following accessories for commissioning the module. - Frame - Inverter f Lay the module on the frame. - Supply meter f Insert four stainless steel screws (M8) through the holes in - DC disconnect switch the frame (see "Specification/Dimensions"). f Secure screws to frame, in each case using 2 stainless steel preparations washers, a stainless steel spring washer or serrated washer and stainless steel nut (M8). -
Page 5: Electrical Connection
installatiOn Maintenance electrical connection The terminal box is on the back of the module: All relevant electrical values are given in chapter "Specification/ Data table". The solar module may, under normal operating conditions, exceed the values specified on the label. To determine the rated voltage values of components, rated current values of leads and fuse sizes, the specified values for the short circuit current and open circuit voltage should be multiplied by a factor of 1.25. The solar modules fulfil the requirements of application class A. They can be used in freely accessible systems with more than 50 V DC voltage or 240 W output. DANGER Electrocution Never disconnect any connections under load. Make sure there is sufficient protection against contact with live components. 1 Terminal box f Only use insulated tools. 2 Plug 3 Connecting cables 6.3.1 Connection in parallel and in series 4 Socket f Remove the plug and socket from the retainer. Note The requirements with regard to earthing must be f Connect the plug of this module to the socket of the next checked before beginning work in accordance with the module. -
Page 6: Specification
installatiOn disMantling dismantling DANGER Electrocution Never disconnect any connections under load. Make sure there is sufficient protection against contact with live components. f Only use insulated tools. To make the photovoltaic system load-free f Disconnect the inverter from the mains on the AC side. f Disconnect the photovoltaic system from the inverter at the disconnect point on the DC side. f Ensure that there is no electrical voltage in the system. f Dismantle the photovoltaic system in the same way as instal- lation, observing the safety instructions. specification dimensions ±100 ±100 9x15 Ø5 Ø5 9x15 ±100 ±100 1 Clamping area | tegreOn www.stiebel-eltrOn.cOM... -
Page 7: Data Table
installatiOn specificatiOn data table tegreOn tegreOn tegreOn 220 p 225 p 230 p 275072 275073 275074 weight and dimensions Height 1651 1651 1651 Width Depth Weight 19.6 19.6 19.6 Cell dimensions 156 x 156 156 x 156 156 x 156 electrical data under stc Rated output acc. to STC (P Module efficiency 13.51 13.82 14.13 Rated voltage (U... -
Page 8: Customer Service And Warranty
(referred to below as the "customer") that the photovoltaic modules tegreon 220P, 225P and 230P will be free Spatial scope/start of warranty of product or manufacturing faults for the duration of 10 years. - Page 9 custOMer service and warrantY Environment and recycling on request, the following documentation and information should be made available to us: We would ask you to help protect the environment. Please dispose of packaging in accordance with national regulations. — Photos of the damaged modules —...
- Page 10 nOtes | tegreOn www.stiebel-eltrOn.cOM...
- Page 11 nOtes www.stiebel-eltrOn.cOM tegreOn |...
- Page 12 Deutschland, Vertrieb und Kundendienst Herausgeber Der Vertrieb und Kundendienst erfolgt in Deutschland über die Firma HELTRON GmbH, STIEBEL ELTRON GmbH & Co. KG ein Unternehmen der Stiebel-Gruppe: Dr.-Stiebel-Straße | D-37603 Holzminden Tel. 0 55 31 702 0 | Fax 0 55 31 702 480 HELTRON GmbH Email info@stiebel-eltron.de...
