Page 1: Table Of Contents
4.2 Mounting the door rail Removing the cover profiles 4.3 Mounting the lock module 8.2 Removing a faulty electric strike release 4.3.1 Mounting the latch lock and 8.3 Replacing the electric strike release floor-locking deadlock TP/TA EASY Safe WN 060028 45532/14241 Mounting instructions 2020-11... -
Page 2: Information About This Document
If they are Address 58256 Ennepetal lost, the latest version of the mounting instructions Germany can be downloaded from www.dormakaba.com. T: +49 2333 793-0 Abbreviations Website www.dormakaba.com Door rail for single-action door... -
Page 3: Product Description
Product description Product description The TP/TA EASY Safe door rail can be mounted at the top and bottom of the glass door panel. Depending on the variant, the door rail can be used for double-action doors, single-action doors and side panels. -
Page 4: Technical Data
Single-action door in door frame – 27 mm to 40 mm rebate depth EA corner fittings and Top door rail and bottom bottom door rail door rail Max. door height 3000 mm 3500 mm Max. door width 1000 mm 1000 mm Max. door weight 80 kg 80 kg TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 5: Variants
• Floor-locking deadlock, PZ and electric strike release • Latch lock, PZ • Electric strike release • Strike box • Latch lock and floor-locking deadlock, PZ • Floor-locking deadlock, PZ with micro switch TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 6: Floor Door Closer (Fdc)
FDC 80 = 341 FDC 84 = 108 FDC 84 = 306 Fig. 3 Dimensions of the FDC recess Remove the spindle from the FDC. 3.4.2 Floor bearing (01.106) 65/55 (20) Fig. 4 Dimensions with floor bearing TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 7: Mounting
During mounting, there is a risk of crushing injuries to the fingers by the glass edges. • Wear protective gloves. • Use glass suction cups. Fig. 7 Aligning the door rail in the case of free glass edge TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 8: Mounting The Lock Module
15 Fig. 11 Loosening the screws and sleeves 2. Insert the locking cylinder. In doing so, ensure that the cylinder driver fits in the opening (Fig. 12/1). TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 9: Mounting The Door Strap For Single-Action Doors (Ta)
2 screws through the insert in the door rail (Fig. 15/2 und Fig. 16/2). Note the tightening torque. Fig. 14 Inserting the locking cylinder and screwing into place 6. Screw the locking cylinder with the screw from the front end (Fig. 14/2). TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 10: Mounting The Panel
Sliding the top door rail on 8. Tighten the screws so that the top door rail 2. Align the top door rail with a distance of 4.5 mm. clamps firmly on the glass (Fig. 20). TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 11: Mounting The Panel With A Top Door Rail With Two-Part Insert For Rts
Attaching the insert one side, then from the other. 6. Place the panel at the bottom on the floor bearing and swing in. 4 mm 12 Nm Fig. 22 Securing the screw-on plate Fig. 24 Swinging the panel in TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 12: Mounting The Panel With A Top Door Rail With Top Pivot Bearing
4. Tighten all screws on the front and back with 15 Nm so that the top door rail clamps firmly to the glass again. TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 13: Gluing The Top Door Rail To An Lsg Glass Panel (Optional)
23°C. Fig. 31 Clearances for the side panel 4. After 15 minutes, carefully remove excess adhesive If necessary, shorten the bottom rail to the that has leaked out from the side. required length. TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 14: Aligning The Side Panel
The clip cam is bent upwards. 6. Align the side panel with a distance of 5 mm to 3. Insert the rubber seal in the cover profile across the wall. the entire length. TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 15: Finalizing The Lock Module
Fig. 39 Finalizing the lock module 2. Screw the locking cylinder with the screw from the front end (Fig. 39/2). 3. Press the end caps onto the roses (Fig. 39/3). Fig. 38 Clipping on the cover profile TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 16: Mounting The End Covers
The end cover is resting on the glass. Fig. 41 Mounting the semi-circular end cover 2. If the end cover is not resting on the glass, then if necessary align the door rail with the end cover. TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 17: Mounting Accessories
2. Centrally to that, drill the hole of diameter 25 mm 3. Secure the strike plate bushing with suitable to at least 30 mm deep. screws and dowels. 3. Secure the eccentric bushing with a suitable screw and suitable dowel. TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 18: Maintenance
Troubleshooting If damage or impaired function occurs to the unit, e.g. door catching on the floor, conchoidal fractures of glass, the unit should be checked by qualified personnel and any faulty components replaced. TP/TA EASY Safe WN 060028 45532 2020-11... -
Page 19: Removing The Cover Profiles
2. Mount the new electric strike release in reverse free state and maintain this state while order (“8.2 Removing a faulty electric strike carrying out the work. release”). TP/TA EASY Safe WN 060028 45532 2020-11... - Page 20 Deutschland GmbH DORMA Platz 1 58256 Ennepetal Germany T: +49 2333 793-0 F: +49 2333 793-4950 www.dormakaba.com...
