Whip Antennas

Because the transmitter tunes across such a broad frequency range,
it is best to use the appropriate antenna for maximum operation. Two
antennas are included with the transmitter, and are shipped from the
factory pre-cut and fully assembled. Each antenna covers three blocks.
Use the chart below to determine which antenna best fits your needs.
Band Block
470
19
A1
20
21
22
B1
23
www.lectrosonics.com
Frequency
Range MHz
470.100 - 495.600 Black
486.400 - 511.900 Black
512.000 - 537.500 Black
537.600 - 563.100 Red
563.200 - 588.700 Red
588.800 - 607.950 Red
Cap
Color Antenna
AMM19
AMM19
AMM19
AMM22
AMM22
AMM22
