Operating Instructions

Powering On in Operating Mode

Press and hold the Power Button
bar on the LCD progresses.
Hold
for
Rf On

Powering On in Standby Mode

A brief press of the Power Button
ing bar progresses, will turn the unit on with the RF output turned off.
In this Standby Mode the menus can be browsed to make settings and
adjustments without the risk of interfering with other wireless systems
nearby.
Hold
for
Rf On
After settings and adjustments are made, press the power button again
to turn the unit off, or turn on the Transmit function by entering the
main menu, selecting Xmit, then RF On?

Powering Off

Powering
O . . .
progresses, the unit will remain turned on and the LCD will return to the
same screen or menu that was displayed previously.
NOTE: If the programmable switch is in the OFF position, power can
still be turned on with the power button. If the programmable switch is
then turned on, a brief message will appear on the LCD.
6
DBu
470.100
-40 -20 +0
Release Power
Button before
the moving bar
progresses to
enter standby
mode
From any screen, power can be turned off by select-
ing Pwr Off in the power menu, holding the Power
Button in and waiting for the moving bar to
progress, or with the programmable switch (if it is
configured for this function).
If the power button is released, or the top panel
switch is turned back on again before the moving bar
for several seconds until a moving
When you release the but-
ton, the unit will be opera-
tional with the RF output
turned on and the Main
Window displayed.
, and releasing it before the mov-
RF indicator blinks
DBu
470.100
-40 -20
+0
