Summary of Contents for Tyco Integra Ci1
- Page 1 Energy Division Installation and Operating Instructions Integra Ci1...
- Page 2 The following symbols may appear in this user guide, and may also be affixed to the products discussed in this guide: Symbol Description Earth terminal Protective conductor terminal Caution, Risk of electric shock Caution, Refer to accompanying text Integra Ci1 User Manual Issue 2 April 2010...
-
Page 3: Table Of Contents
Contents Introduction Unit Characteristics ..............5 Current Transformer Primary Current ........5 RS485 Serial Option Modbus™ or JC N2Protocol....5 Pulse Output Option..............5 Start Up Screens Measurement Mode Setting-Up Setup Entry Methods ............... 8 4.1.1 Menu Option Selection............8 4.1.2 Number Entry Procedure ........... - Page 4 RS485 and Modbus™ or JC N2 Protocol.......27 7.11 Operation Check ..............27 Glossary Index Important safety information is contained in the Maintenance section. Familiarise yourself with this information before attempting installation or servicing of the unit. Integra Ci1 User Manual Issue 2 April 2010...
-
Page 5: Introduction
This document provides operating, maintenance and installation instructions for the Crompton Instruments Integra Ci1 energy meter. The unit displays imported or exported real and reactive energy, since it was last reset, in terms of Wh, kWh, MWh, VArh, kVArh and MVArh for single phase, three-phase 3-wire or three-phase 4-wire supplies. -
Page 6: Start Up Screens
The top line of the display indicates the type of supply being monitored: Single phase 3-phase 3-wire 3-phase plus N (4-wire) The blue man flashes to indicate that energy for the currently displayed parameter is being accumulated. Integra Ci1 User Manual Issue 2 April 2010... -
Page 7: Setting-Up
Test Phase sequence (V123 I123) Display on – all elements on to check display dISTG Display toggle – Each element is turned on and off alternately. SFS Build number SFH Firmware version Integra Ci1 User Manual Issue 2 April 2010... -
Page 8: Setup Entry Methods
The SET indicator comes on to confirm successful entry after the last digit has been set. 3. After setting the last digit, press to exit the number setting routine. The SET indicator will extinguish. Integra Ci1 User Manual Issue 2 April 2010... -
Page 9: Change Password
SET indicator will appear. Press to exit the system selection routine and return to the menu. The SET indicator will extinguish and you will be returned to the main Set-Up menu. Integra Ci1 User Manual Issue 2 April 2010... -
Page 10: Reset
To reset the energy readings, press . SET will be displayed and ‘hour’ will stop flashing. Press to exit the Reset routine. SET will extinguish and you will be returned to the main Set-up menu. Integra Ci1 User Manual Issue 2 April 2010... -
Page 11: Communications
Use the keys to select the desired Baud rate from the available options 9600, 4800, 2400, 38.4k (38400) and 19.2k (19200). Press to confirm your Baud rate selection. SET will be displayed. Integra Ci1 User Manual Issue 2 April 2010... - Page 12 Stop Bits option 1 or 2. Press to confirm your selection. SET will be displayed. Press to exit Stop Bits setting routine. The SET indicator will extinguish and the keys can be Integra Ci1 User Manual Issue 2 April 2010...
-
Page 13: Relay Pulse Output
Relay screen. Press . The Output 1 screen will appear. From here, the keys can be used to select menus for Output 1, Output 2, Rate and Pulse Width . Integra Ci1 User Manual Issue 2 April 2010... - Page 14 The SET indicator will appear and the display will stop flashing. Press to exit Rate setting routine. The SET indicator will extinguish and the keys can be used to select a different Relay parameter. Integra Ci1 User Manual Issue 2 April 2010...
-
Page 15: Energy Units And 1% Limit
Energy Units or 1% Limit menu. Energy Units With the Unit screen selected, press to enter the Units setting routine. The currently selected unit flashes. Use the keys to select the required units. Integra Ci1 User Manual Issue 2 April 2010... -
Page 16: Test
Use the keys to select the required test option and press confirm your selection. The available options are: Lights all LED segments so that display segments can be checked. Toggles display segments alternately. Integra Ci1 User Manual Issue 2 April 2010... - Page 17 Alternatively, the phase of L2-L3 relative to L1-L2 must be within the window 120° ± 48° and L3 relative to L1-L2 must be within the window 240° ± 48° to record the sequence V132. The display shows ‘V1--‘ if a voltage phase is outside these parameters. Current: Integra Ci1 User Manual Issue 2 April 2010...
-
Page 18: Version Information
The display shows ‘I --‘ if a current phase is outside these parameters. 4.10 Version Information The last two options of the Set-up menu show the versions of firmware and hardware of the unit. Shows build number, e.g. 18.000 Shows firmware version, e.g. 1.020. Integra Ci1 User Manual Issue 2 April 2010... -
Page 19: Specification
The unit can be powered from an auxiliary a.c. or d.c. supply that is separate from the metered supply. Two-way fixed connector with 2·5mm stranded wire capacity. 110 to 400V a.c. 50/60Hz ±10% or 120V to 350V d.c. ±20%. Consumption < 5VA. Integra Ci1 User Manual Issue 2 April 2010... -
Page 20: Option Modules
Sinusoidal (distortion factor < 0·005) Auxiliary supply voltage Nominal ±1% Auxiliary supply frequency Nominal ±1% Auxiliary supply waveform (if AC) Sinusoidal (distortion factor < 0·05) Magnetic field of external origin Terrestrial flux Integra Ci1 User Manual Issue 2 April 2010... -
Page 21: Environment
RoHS regulations.) EMC Conducted and Radiated Emissions BS EN 61326, Class A (Industrial) EMC Immunity BS EN 61326, Class A (Industrial) Safety BS EN 61010-1:2001 Integra Ci1 User Manual Issue 2 April 2010... -
Page 22: Maintenance
In the unlikely event of a repair being necessary, it is recommended that the unit be returned to the factory or nearest Crompton Instruments / Tyco Electronics service centre. 7 Installation The unit may be mounted in a panel of any thickness up to a maximum of 6 mm (0·25in). -
Page 23: Emc Installation Requirements
RF fields cause problems. • It is good practice to install sensitive electronic instruments that are performing critical functions in EMC enclosures that protect against electrical interference causing a disturbance in function. Integra Ci1 User Manual Issue 2 April 2010... -
Page 24: Case Dimensions And Panel Cut-Out
7.Installation 7.3.Case Dimensions and Panel Cut-Out Crompton Instruments 7.3 Case Dimensions and Panel Cut-Out Side view Front view Integra Ci1 User Manual Issue 2 April 2010... -
Page 25: Wiring
7.6 Auxiliary Supply The Integra Ci1 should ideally be powered from a dedicated supply. However, it may be powered from the signal source providing the source remains within tolerance for the auxiliary supply. The unit can be powered from an auxiliary a.c. or d.c. supply that is separate from the metered supply. -
Page 26: Connection Diagrams
7.Installation 7.9.Connection Diagrams Crompton Instruments 7.9 Connection Diagrams Single phase 3-phase 3-wire 3-phase 4-wire Integra Ci1 User Manual Issue 2 April 2010... -
Page 27: Rs485 And Modbus™ Or Jc N2 Protocol
7.10 RS485 and Modbus™ or JC N2 Protocol An optional RS485 module can be plugged into the rear of the Integra Ci1. RS485 in conjunction with the Modbus™ or JC N2 protocol allow the unit to be interrogated and provide a response detailing the readings it has taken. -
Page 28: Glossary
8.Glossary Crompton Instruments 8 Glossary Active energy Accumulated energy (Watt hours). Current Transformer. Transforms a (usually) high current to a value that can be monitored by the meter. Firmware Software installed on a permanent medium. Johnson Controls A master - slave serial communication protocol with fixed (JC) N2 communication parameters. - Page 29 Stop bits, 12, 21 Meter creep, 16 Supply selection, 9 Meter current, 10 Temperature, 21, 24 Modbus™, 5, 11, 21, 28 Test, 6, 17 Multiplier, 16 Units, 16 Noise, 16 Version, 19 Integra Ci1 User Manual Issue 2 April 2010...
- Page 30 9.Index 7.11.Operation Check Crompton Instruments Tyco Electronics, the TE logo and INTEGRA are trademarks. CROMPTON is a trademark of Crompton Parkinson Ltd. and is used by Tyco Electronics under license. Other Trademarks or company names mentioned herein are the property of their respective owners.
