Technical Speci Cations - Calypso Instruments ULP Pro User Manual

3. Technical speci cations

The ULP has the following technical specifications:
· Diameter: 68 mm (2.68 in.)
3.1. Dimensions
· Height: 65 mm (2.56 in.)
200 grams (7 ounces)
3.2. Weight
· 3.3-18 DCV
3.3 Power
The ULP has to be connected as shown in this section.
ULP Pro
User manual
RS485/MODBUS RTU Output:
White Yellow
GND (Power -) DATA (B -)
Brown Green
,
VCC (Power +) DATA (A +)
UART/TTL Output:
White
Yellow
GND (Power -) DATA Rx
Brown
Green
VCC (Power +) DATA Tx
Data interface
Data format
Baudrate
Voltage range
Power consumption:
(RS485) 0.25 mA at 38400 bauds, 1 Hz. (5V)
(UART) 0.15 mA at 38400 bauds, 1 Hz. (5V)
(MODBUS) 0.25 mA at 38400 bauds, 1 Hz. (5V)
Ultrasonic transducers (4x)
3.4. Sensors
Sample rate: 0.5 Hz to 10 Hz
The ULP has been designed to avoid any mechanical
parts to maximize reliability and minimize maintenance.
The transducers communicate between themselves two
by two using ultrasonic range waves. Each pair of trans-
ductors calculates the signal delay and get information
about both wind direction and wind speed.
1Stream
2-POLL
3-MODBUS
NMEA0183
2400 to 115200 bauds
3.3-18V
04/08
