Erecting Your Instant Shelter

Step 7: Open The Frame
We can now open the frame closer to it's
final width. With your partner, grab the
bottom crossbar section as seen in
image one (left) and walk backwards from
each other as far as you can go.
The goal here is to get the red pull pins
as close to its locking position at the top
of the leg as possible.
Don't have a partner?
For setting up solo, place one hand on
the top three way joint and one under
the bottom joint. Squeeze them together
as you walk backwards as seen in image
three (left). If you have a 15' or 20' x 10'
do this from the 10' side and squeeze
the framework together. This will extend
the framework. You will see now that the
corner sliding leg joint with the red pull
pin will be inches away from the location
hole.
