COMPACT
SHELTER
Robusta (10ft x 10ft)
Canopro Lite - (10ft x 10ft) - (15ft x 10ft) -
Assembly & Elevation
A step-by-step guide to constructing your canopy
Thank you for purchasing from Surf & Turf Instant Shelters, the
leading supplier of pop up event shelters within the Canada and
North America.
Our Instant Shelters are designed to be simple to erect, however
we strongly recommend reading our instructions fully before using
the Instant Shelter and keeping them handy at all times.
We recommend that no more than 2 people erect this Instant
Shelter, to avoid the risk of damaging the frame.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SURF & TURF Robusta
Summary of Contents for SURF & TURF Robusta
- Page 1 COMPACT SHELTER Robusta (10ft x 10ft) Canopro Lite - (10ft x 10ft) - (15ft x 10ft) - Assembly & Elevation A step-by-step guide to constructing your canopy Thank you for purchasing from Surf & Turf Instant Shelters, the leading supplier of pop up event shelters within the Canada and North America.
-
Page 2: Table Of Contents
CONTENTS Receiving Your Package & First Steps Setting Up The Canopy Erecting The Instant Shetler Setting up Sidewalls Securing The Frame Using A Surf & Turf Anchor Kit Tips For Dismantling Canopy Protector Bag Taking Care & Maintenance 12-14 Warranty Details Refunds &... -
Page 3: Receiving Your Package & First Steps
Receiving Your Instant Shelter *Important note on shipped products The moment you receive your packages, please ensure they don’t have any signs of damage. If you feel that there might be missing pieces or damage, write down your concerns on the shippers paper work and then sign. -
Page 4: Setting Up The Canopy
Setting Your Canopy Step 4: Place Canopy Place the canopy over the extended frame. Ensure that the peak of the canopy is sitting comfortably on the centre apex to avoid unnecessary stress and friction on the material. Step 5: Anti-Sag Bolts Located in the small canvas bag that comes with your frame you will find tie-down rope, anchor stakes and the... -
Page 5: Erecting The Instant Shetler
Erecting Your Instant Shelter Step 6: Raise the Apex Before opening the frame - extend the center apex pole(s). As you lift you will hear it click in place. Step 7: Open The Frame We can now open the frame closer to it’s final width. - Page 6 Erecting Your Instant Shelter Step 8: Raise Lower Legs As this frame has two inner legs, making for a total of 3 sections, it is best to raise one side and one leg section at a time (as seen right). Lift a corner leg and pull out the bottom most leg section until you hear the pull pin click into place.
- Page 7 Erecting Your Instant Shelter Step 11: Set Velcro Now that the frame is fully extended and secure, we can set the velcro around the crossbars as seen right. Repeat for all four sides. This will keep the center pitch of the canopy tight and prevent rain from pooling.
-
Page 8: Setting Up Sidewalls
Setting Your Sidewalls You will notice a 45 degree cut in the corners of the sidewalls velcro strip. Align the top edge of the cut to the inside of the leg and attach to the velcro, allowing for the zipper to wrap around the outside leg. -
Page 9: Securing The Frame
Securing The Frame Each foot plate has holes for pegging, it is important that the shelter is pegged or secured no matter what the conditions are. Our Compact shelters have eyelet pegging points on the bottom of the side walls as well. These can be pegged when on soft ground. -
Page 10: Using A Surf & Turf Anchor Kit
Using Our Anchor Kit If you purchased a Anchor Kit with your shelter or if you’re using the ropes and spikes supplied by Surf and Turf, connect your rope or strap around the corner joint, as seen in image 1, and secure. Next, hook the bottom end to the metal peg. Hammer the peg into the ground at an angle and then pull the rope tight. -
Page 11: Tips For Dismantling
Tips for Dismantling When taking down the Instant shelter ensure that all leg joints, corner joints and leg adjusting joints are released. Ensure that the Velcro securing straps are all un-done and placed back in their starting positions. If it feels excessively stiff while taking down, stop and check all joints and Velcro securing straps. -
Page 12: Taking Care & Maintenance
How to take care Do not store your canopy wet! Before storage, make sure that your canopies and sidewalls are dry before putting them back in their respective storage bags. This is to prevent mold damage. Remember to always keep your frame properly anchored, high wind conditions can blow away an unsecured shelter. - Page 13 Maintaining Your Investment At Surf & Turf Instant Shelters, we will do everything we can to ensure you are happy with your purchase. Please take a few minutes to read through this advice sheet for some important tips. For more advice on erecting and dismantling your shelter, please see the instructions sheet, and/or instructional videos on our website and YouTube.
- Page 14 How to take care We strongly advise that you remove the canopy from the frame before dismantling your Instant Shelter, and pack it away. Whilst we appreciate that leaving this on the frame will help to save time when packing the frame down, and erecting it again later, the canopy can easily be caught on the framework of the Shelter.
-
Page 15: Warranty Details
Compact Warranty Details Our Compact Instant Shelter frame is covered by a 12 month manufacturer’s warranty, starting from the date of purchase. We keep a comprehensive list of spare parts in stock ready to ship should you need any. Courier charges will be applicable to any warranty claims. Proof of purchase and photographic evidence of said defects will be required. -
Page 16: Refunds & Returns Policy
Refunds & Returns The goods must be returned to Surf & Turf within 7 working days from receipt or delivery. We will process a full refund within 30 days following a quality controlled inspection. Please note: It is the responsibility of the customer to ensure that the goods are returned to Surf &... - Page 17 Refunds & Returns Faulty or Defective Items 1.10 Note that in the event of Surf & Turf sending you a faulty or defective item, we would need to be notified of said fault, within 7 working days of you receiving the goods. 1.11 In order to replace the faulty item, we may ask to see photographic evidence of the fault, or to have the item sent back to us before we can issue a replacement.
-
Page 18: Spare Parts Lists
BC1 -Complete BC2 - Middle Leg BC3 - Upper Leg BC4 - Lower Leg Section Corner Leg Section Section With Footplate BB11 - Corner Leg Top Joint BB12 - Corner Sliding Joint BC5 - Compact Cross Bar BC5 - Compact Cross Bar (Single Bar) With Connector (Double Bar) BB14 - Leg Adjust Joint... - Page 19 BB16 - Cross Bar Connector BB10 - Centre Pole Mushroom Cap BC12 - Top Centre Pole BC13 - Lower Centre Pole BA19 - Bauble BD18 - Black Screw To Attach BA20 - Pull Pin BD20 - Screw To Attach Crossbars To Joints Pull Pin To Joint BB18 - Rubber Washer For BD19 - Screw To Attach...
