Lorex SG620R Quick Manual

Dummy Camera
The Lorex Simulated Security Dome Camera is an affordable and effective theft deterrent device. It looks like a real surveillance camera with
its flashing red indicator, imitation lens and dome construction. Mount the simulated security camera in a visible area on a ceiling or wall to
deter possible thieves and intruders.

INSTALLING BATTERIES

The Simulated Security Camera requires two "C" batteries (not supplied) if using the flashing red LED. The dome is also effective without
the flashing LED as some models of actual Security Cameras do not have a flashing LED.
Cautions:
• Use only fresh batteries of the required size and recommended type.
• Do not mix old and new batteries, different types of batteries (standard, alkaline, or rechargeable), or rechargeable batteries of different
capacities
1. Remove the four (4) black Holding screws
from the Dome Cover, and remove the cover.
NOTE: The simulated security screws are for
show only, and are not removable.
2. Remove the two (2) silver screws holding the
Simulated Lens to the Base. Remove the Lens
component to access the Battery Compartment.
3. Place the batteries in the compartment as
indicated by the polarity symbols(+ and -)
marked inside.
4. Reattach the Lens Compartment to the
base with the two (2) silver screws. Set the
switch to ON to start the RED LED blinking.
Replace the Dome Cover, and secure with the
four (4) black screws.
MODEL SG620R
Simulated (Dummy) Security Camera
Ceiling Mount Bracket
Screw & Anchor Pack
3.
THIS PACKAGE CONTAINS:
1 x Dummy Camera
1 x Ceiling Mount Bracket
1 x Screw and Anchor Pack
FEATURES
• Excellent Economical Deterrent
• Flashing Indicator Light Provides Real
Authentic Look*
* Flashing indicator light function requires 2 x "C" type batteries.
Not included.
1.
2.
NOTE: Fresh batteries will power the
simulated security camera's indicator for
about 4 months (if the flashing LED is left
on continuously).
When the indicator dims or stops
flashing, replace the batteries
4.
