Installing the Inline Relay

1) Switch o the mains power
2) Connect the incoming Live and Neutral wires from
the 230v mains circuit to the right-hand live and
neutral terminals as shown in the diagram (marked L
& N).
3) For each of the three separate circuits, connect the
switched live and outgoing neutral wire to the
corresponding terminals as shown in the diagram.
IMPORTANT: Remember that the maximum loading
for the Relay is 3000w IN TOTAL (resistive load).
Exceeding this limit could cause damage to the
device.
IMPORTANT: The 3-Way Control relay is not
designed to be left exposed once it is installed, as
live mains wiring is connected to the terminals.
Ensure that the device is mounted securely in a
suitable housing (e.g. LightwaveRF IP56 housing).
