Lorex CVS1000 Quick Setup Manual

4. Camera Specifications
Specifications:
Image Sensor 1/3" Color CCD Sensor
Video Format / Pixels NTSC: 510(H) x 492 (V)
Horizontal Resolution 420 TVL
Internal; 2:1 Interlace
Sync. & Scan. Systems
S/N Ratio > 52dB (without AGC)
Iris & Shutter Speed AES; 1/60 ~ 1/100,000 sec.
Minimum Illumination 0.05 LUX (IR Off) / 0 LUX (IR
LEDs ON)
Video Output Comp. 1.0 Vpp @ 75ohm
Lens / Focal Length / 3.6mm F2.0/ Fixed
Aperture / Mount
FOV (diagonal) 79 Degrees
Termination Video: BNC Female
Power: Barrel Female
IR / Night Vision Range 30IRLED/850nm/66'(20m)
Power Requirement 12V DC ±10%
Power Consumption 340mA max
Operating Temp. 14°F ~ 122°F
(-10°C ~ 50°C)
Weight (with stand) 3.7 lbs / 1.68 kg
Dimensions (with stand 3.5" x 2.75" x 5"
and sunshade)(W x D x H) 9cm x 7cm x 13cm
Dimensions:
It's all on the web
Specification Sheets
Product Information
Software Upgrades
User Manuals
Firmware Upgrades
Quick Start Guides
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
COLOR SUBMERSIBLE NIGHT
VISION CAMERA
Model: CVS1000
Quick Set-up Guide
English Version 2.0
