Menu Introduction

Long press the " " button to go to the menu. They are
respectively: image, color palette, time and setting.

1. Image Menu

1.1 View Images

Go to the menu, select image icon, press the "
image list, press the " " or "
press the " " to go to the image.
While viewing an image, press the "
image, press the " " to view the next image, and press the
" " to return.

1.2 Delete Images

When viewing an image, press the "
displayed on the screen. Press the "
select whether to delete the image, and press the "
con firmation.
12
" to go to the
" button to select image, and
" to view the previous
", and "delete image" is
" or " " button to
" again for

2. Color Palette Menu

2.1 Description of Color Palette

The color palette can be used to change the pseudo color display
of infrared images on the display screen. Some palettes are more
suitable for specific applications, and can be set as needed. Color
palette is divided into: rainbow, iron red, cold color, white hot,
black hot as five color palettes. These palettes work best with
high thermal contrast and provide additional color contrast
between high and low temperatures.
Selecting the appropriate palette can better show the details of
the target object. For rainbow, iron red and cool colors, the
palette focuses on displaying colors. The palette is very suitable
for high thermal contrast and is used to improve the color
contrast between high temperature and low temperature.
However, the white hot and black hot palette provides uniform
linear colors.
