Description Of Basic Operation; Device Power On/Off And Interface Adjustment; Button Operation - HTI HT-C600 Operation Instructions Manual

Operating/storage environment
Operating temperature
Storage temperature
Shock
Protection level
Overall dimension/Weight
Overall dimension
Weight

Description of Basic Operation

1. Device Power on/off and Interface Adjustment

Shortly press the power switch, and you can see the screen is lit
from the eyepiece;
If the characters on the display interface are fuzzy, you can adjust
the eyepiece focusing ring and rotate left and right until the
characters on the interface are clear;
After the device is normally activated, you can go to the actual
operation interface;
If power off is required, shortly press the power switch, and the
device is normally off, and there is no display on the screen.
10
-20℃ to 50℃
-30℃ to 70℃
≤30g
IP54
193.1mmx176.8mmx99mm
1.58kg (including batteries)

2. Button Operation

● After normal power on, if there is no menu display, press the
+
" " button for amplification, with images switching in cycle in
1X, 2X and 4X.
● Press the " " button to be able to switch the color palette:
rainbow, iron red, cold color, black hot and white hot.
● Press the " " button to be able to switch the mode: shimmer
mode, infrared mode, blend mode and picture in pictures mode.
Long press the " " button, and the menu is displayed on the
screen. Now, it is the menu mode. Press the "
the menu mode.
● Press the " " " " button to play the role as image
focusing.
● Press " " button for image snapshot. Long press the "
button to record videos, and long press press this button once
again to exit video recording.
" button to exit
"
11
