Sauder Anda Norr 427346 Manual

Lateral file
Hide thumbs

Advertisement

Quick Links

Download this manual
CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Lateral File
Anda Norr Collection | Model 427346
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
Get all organized
and stuff.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 555161
Purchased: __________________
11/04/20

Advertisement

loading

Related Manuals for Sauder Anda Norr 427346

Summary of Contents for Sauder Anda Norr 427346

  • Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.

  • Page 2: Table Of Contents

    Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Hardware Identification Tip Shown Actual Size Hardware Usage Guide Assembly Steps 6-22 Hammer Not actual size Français 23-25 Español 26-28 Safety 29-30 Warranty Page 2 www.sauder.com/service 427346...

  • Page 3: Part Identification

    RIGHT DRAWER SIDE (2) LEFT END (1) FOOT (2) DRAWER BOTTOM (2) RIGHT END (1) BRACE (2) DRAWER BRACE (4) UPPER BACK (1) LEFT DRAWER SIDE (2) DRAWER FRONT (2) LOWER BACK (1) DRAWER BACK (2) SAFETY BRACE (2) 427346 www.sauder.com/service Page 3...

  • Page 4: Hardware Identification

    APPLIQUE CARD - 3 1-1/2" FLAT HEAD SCREW - 23 1-1/8" FLAT HEAD SCREW - 10 9/16" FLAT HEAD SCREW - 8 9/16" PAN HEAD SCREW - 4 1/2" PAN HEAD SCREW - 36 1/2" MACHINE SCREW - 8 Page 4 www.sauder.com/service 427346...

  • Page 5: Hardware Usage Guide

    The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. 427346 www.sauder.com/service Page 5...

  • Page 6: Assembly Steps

    Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
  • Page 7 Insert five LARGE WOOD DOWELS (8) into the UPPER BACK (D). å Push the LARGE WOOD DOWELS on the UPPER BACK (D) into the holes in the LOWER BACK (E). 1-1/8" FLAT HEAD SCREW (10 used in this step) 427346 www.sauder.com/service Page 7...
  • Page 8 å Push four LARGE HIDDEN CAMS (3) into the ENDS (B and C). å Flip the ENDS (B and C) over. å Turn four ANGLED HEAD CAM SCREWS (5) into the ENDS (B and C). Arrow Page 8 www.sauder.com/service 427346...
  • Page 9 Put the SCREW into this hole first Open end Pull up or down the black lever in and pull the SLIDE from the RAIL. Open end 1/2" PAN HEAD SCREW (12 used in this step) Open end 427346 www.sauder.com/service Page 9...
  • Page 10 NOTE: Be sure the WOOD DOWELS in the BACKS insert into the ENDS. Open end S u r f a c i t h o u t H Open end I D D S u r f a c i t h H I D D E N Page 10 www.sauder.com/service 427346...
  • Page 11 NOTE: Be sure the WOOD DOWELS in the BOTTOM insert into the ENDS and LOWER BACK. o l e r e h i t h f a c S u r 1-1/2" FLAT HEAD SCREW (7 used in this step) 427346 www.sauder.com/service Page 11...
  • Page 12 Step 7 å Fasten the FEET (G) to the BRACES (H). Use eight 1/2" MACHINE SCREWS (22). 1/2" MACHINE SCREW (8 used in this step) Page 12 www.sauder.com/service 427346...
  • Page 13 Step 8 å Fasten the FEET (G) to the BOTTOM (F). Use eight 9/16" FLAT HEAD SCREWS (19). 9/16" FLAT HEAD SCREW (8 used in this step) 427346 www.sauder.com/service Page 13...
  • Page 14 å Turn eight STRAIGHT HEAD CAM SCREWS (6) into the your drink. DRAWER FRONT (O). å Repeat this step for the remaining DRAWER SIDES, DRAWER BRACES and DRAWER FRONT. (16 used) Arrow (16 used) Page 14 www.sauder.com/service 427346...
  • Page 15 Fasten the DRAWER BACK (K) to the DRAWER SIDES (J and L) and DRAWER BRACES (N). Use eight 1-1/2" FLAT HEAD SCREWS (17). å NOTE: Be sure the DRAWER BOTTOM (M) inserts into the groove of the DRAWER BACK (K). å Repeat this step for the remaining DRAWER. 427346 www.sauder.com/service Page 15...
  • Page 16 Use two 9/16" PAN HEAD SCREWS (20). å Repeat this step for the remaining DRAWER. Open end 1/2" PAN HEAD SCREW (12 used in this step) Open end 9/16" PAN HEAD SCREW (4 used in this step) Open end (2 used) Page 16 www.sauder.com/service 427346...
  • Page 17 å Fasten the LONG FILE HANGER (11) to the DRAWER FRONT (O). Use six 1/2" PAN HEAD SCREWS (21). å Repeat this step for the remaining DRAWER. 1/2" PAN HEAD SCREW (12 used in this step) 427346 www.sauder.com/service Page 17...
  • Page 18 Push the LONG FILE GLIDE (12) onto the DRAWER BACK (K). å Place the SHORT FILE HANGERS (9) onto the LONG FILE HANGER (11) and LONG FILE GLIDE (12). å Repeat this step for the remaining drawer. Page 18 www.sauder.com/service 427346...
  • Page 19 å Fasten the drawer to the SAFETY STRAPS. Use the SCREWS and BOLTS as shown in the enlarged diagram. Pro Tip: Lift with your legs. And, you know, your arms. BOLT SCREW 427346 www.sauder.com/service Page 19...
  • Page 20 å Fasten the drawer to the SAFETY STRAPS. Use the SCREWS and BOLTS as shown in the enlarged diagram. BOLT SCREW Page 20 www.sauder.com/service 427346...
  • Page 21 å Fasten the TOP (A) to the ENDS (B and C) and UPPER BACK (D). Tighten seven HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the TOP insert into the ENDS and UPPER BACK. 427346 www.sauder.com/service Page 21...
  • Page 22 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or (18 used) Page 22 www.sauder.com/service...

  • Page 23: Français

    REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en DESSUS ................1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) ce qui concerne cet EXTRÉMITÉ GAUCHE ..........1 GLISSIÈRE D'EXTENSION ........4 élément, faire référence EXTRÉMITÉ DROITE ..........1 COULISSE D'EXTENSION ........4...
  • Page 24 Enfoncer quatre GRANDES EXCENTRIQUES ESCAMOTABLES (3) TÊTE PLATE 14 mm (19). dans les EXTRÉMITÉS (B et C). Retourner les EXTRÉMITÉS (B et C). Faire tourner quatre VIS D'EXCENTRIQUE AVEC TÊTE EN ANGLE (5) dans les EXTRÉMITÉS (B et C). Page 24 www.sauder.com/service 427346...
  • Page 25 Enfoncer l'ARMATURE LONGUE POUR DOSSIERS (12) sur l'ARRIÈRE DE TIROIR (K). Placer les SUPPORTS POUR DOSSIERS COURTS (9) sur le SUPPORT POUR DOSSIERS LONG (11) et la ARMATURE LONGUE POUR DOSSIERS (12). Répéter cette étape pour l'autre tiroir. 427346 www.sauder.com/service Page 25...

  • Page 26: Español

    PANEL SUPERIOR ............1 BIELA DE EXCÉNTRICO CON su referencia futura. Si CABEZA ANGULADA ..........11 necesita ponerse en EXTREMO IZQUIERDO ..........1 contacto con Sauder en BIELA DE EXCÉNTRICO CON EXTREMO DERECHO ..........1 cuanto a esta unidad, CABEZA RECTA ............16 DORSO SUPERIOR .............1 refiérase al número...
  • Page 27 Fije las PATAS (G) al FONDO (F). Utilice ocho TORNILLOS DE Vuelva los EXTREMOS (B y C) al revés. CABEZA PERDIDA de 14 mm (19). Atornille cuatro BIELAS DE EXCÉNTRICO CON CABEZA ANGULADA (5) en los EXTREMOS (B y C). 427346 www.sauder.com/service Page 27...
  • Page 28 Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Empuje los SOPORTES DE ARCHIVADOR CORTOS (9) sobre el SOPORTE DE ARCHIVADOR LARGO (11) y el CORRIMIENTO LARGO DE ARCHIVERO (12). Repita este paso para el otro cajón. Page 28 www.sauder.com/service 427346...

  • Page 29: Safety

    Les téléviseurs peuvent être très un téléviseur. téléviseur. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 427346 www.sauder.com/service Page 29...
  • Page 30 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y hacerlos propensos a volcarse hacia adelante. Page 30 www.sauder.com/service 427346...

  • Page 31: Warranty

    à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 32 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
