Double screen：left and right -- > up and down
（ select the input source displayed on the screen
through the [Win / Src] button）
Single screen rotation
HDMI①--->HDMI②--->HDMI③--->HDMI④--->DP⑤
R90ᵒ Rotate the whole input image 90 ° (only in the case of
single image)
R180ᵒ First line output image rotated 180 ° (only in case of 2
lines)
Clone Clone mode: copy display (1x1) for each output port
Note 1:
[win] key meaning: window, the number of each screen
(window) in the "whole screen", the corresponding screen
position is as follows.
Single screen mode: there is only one screen, and the value is
fixed as number 1, as shown below.
