TRANSMITTERS
2
A
1 BUTTON
Functions:
OPEN-STOP-CLOSE
CHx
or
CLOSE
Radio codes memorization
2.1
TYPE OF MEMORIZATION
A
1 BUTTON:
OPEN STOP
B
AUTOMATIC COMMANDS
(2 or 3 BUTTONS)
A
1 BUTTON:
CLOSE
C
7/42 CHANNEL TRANSMITTER
Press the button P1 as many times as requested by the type of memorization and keep it pressed. The buzzer emits a continuous sound.
Press the button of the transmitter relative to the code to memorize. The memorization is indicated by an intermittent sound of the buzzer.
* The buzzer will make a beep each press.
B
AUTOMATIC COMMANDS (2 or 3 BUTTONS)
Open
CH1 (STOP)
Close
CH2 (STOP)
Open
(STOP)
CH3
Close
CH4 (STOP)
Open
CH5
STOP
CH6
Close
CH7
7/42 channel transmitter 3/18 channel transmitter
P1
*
1x
CLOSE
*
2x
*
3x
*
4x
Open Close
Open
CH5
(STOP) (STOP)
STOP
CH6
Close
CH7
2 channel transmitter
continuous
sound
keep it
pressed
Press the button of the transmitter
relative to the code to memorize.
Press the button of the transmitter
relative to the code to memorize.
Press the button of the transmitter
relative to the code to memorize.
Press any button of the 7/42 channel
transmitter.
7
C
7/42 CHANNEL TRANSMITTER
0 % (CLOSED)
CH1
50 %
CH2
70 %
CH3
100 % (OPEN)
CH4
Open (hold-to-run)
CH5
STOP
CH6
Close (hold-to-run)
CH7
7/42 c transmitter
hannel
...
intermittent sound
P1
