Understanding the Configurator Work Area

Understanding the Configurator Work Area

The Main Window

Left pane
lists system
components
that can be
configured
The Main Window consists of two panes. The left pane displays a list of the system components that can be
configured. When selecting an item from the list, the application will display the corresponding configuration in the
right pane.
The window's title bar shows the application name, the configuration name and, optionally, the configuration file
path. If changes were made to the configuration file and weren't saved, the title bar will show an asterisk (*) beside
the configuration name (the save command is enabled only if you make any changes to the configuration).
4
This asterisk (*) means that the file
changes have not been saved
firealarmresources.com
Right pane
displays the
configuration that
is selected in the
left pane
