CHARACTERISTICS:

The HD67F27-B2 is a KNX / LoRaWAN Gateway.
It allows the following characteristics:
Electrical isolation between KNX and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12...35V DC and 8...24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67F27 software on your PC in order to perform the following:
Define the parameter of KNX line;
Define the parameter of LoRaWAN line;
Define the list of LoRaWAN end-devices to connect;
Define the LoRaWAN messages to send/receive from each LoRaWAN end-device;
Define the KNX data points accessible by the external KNX network;
Update the device.
