CHARACTERISTICS:

The HD67E23-A1 are EtherCAT / PROFINET Slave - Converters.
It allows for the following characteristics:
Isolation between EtherCAT – PROFINET – Power Supply;
Two-directional information between EtherCAT bus and PROFINET bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67E23 software on your PC in order to perform the following:
Define the parameters of EtherCAT line;
Define the parameters of PROFINET line;
Define EtherCAT variables to read and write;
Export the ESI file for configuration of EtherCAT Master;
Export the GSDML file for configuration of PROFINET Master;
Update the device.
