SIMATIC NET
Industrial Remote Communication
Remote Networks
Cloud Connector
Getting Started
07/2020
C79000-G8976-C507-03
Preface
Description
PROFIBUS connection
PROFINET connection
1
2
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMATIC NET SCALANCE M80PB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SIMATIC NET SCALANCE M80PB

Summary of Contents for Siemens SIMATIC NET SCALANCE M80PB

  • Page 1 Preface Description SIMATIC NET PROFIBUS connection PROFINET connection Industrial Remote Communication Remote Networks Cloud Connector Getting Started 07/2020 C79000-G8976-C507-03...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Preface Purpose The configuration of the Cloud Connector is shown with examples. Validity Getting Started applies to the SCALANCE M-800 firmware version V6.3 or higher. IP settings for the examples Note The IP settings used in the examples were freely chosen. In a real network, you would need to adapt these IP settings to avoid possible address conflicts.
  • Page 4 You can find this entry under the following entry ID: 109767355 SIMATIC NET manuals You will find SIMATIC NET manuals on the Internet pages of Siemens Industry Online Support: • using the search function: Link to Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/) Enter the entry ID of the relevant manual as the search item.
  • Page 5 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to...
  • Page 6 Preface Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 7: Table Of Contents

    Table of contents Preface ..............................3 Description ............................. 9 PROFIBUS connection .......................... 11 Local service ........................11 2.1.1 Introduction ........................11 2.1.2 Enabling the TIA Portal Cloud Connector on the device ............14 2.1.3 Enabling the TIA Portal Cloud Connector on the PG/PC ............15 2.1.4 Connecting to the TIA Portal Cloud Connector ..............
  • Page 8 Table of contents Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 9: Description

    Description Machines and plants are operated in places that are often far away from their place of construction. Nevertheless, system manufacturers must be able to guarantee service in the event of a fault. High costs can occur, especially in the warranty phase. The Cloud Connector is suitable for remote maintenance (Teleservice).
  • Page 10 Description Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 11: Profibus Connection

    PROFIBUS connection Local service 2.1.1 Introduction In this example configuration, the PG/PC of the service technician is directly connected to the SCALANCE M804PB via Ethernet and the S7 automation system via the MPI/DP interface. An S7-300 with CPU 317-2 PN/DP is used as the S7 automation system. In addition to the programming software (TIA Portal or STEP 7), the TIA Portal Cloud Connector is also required on the PG/PC.
  • Page 12 PROFIBUS connection 2.1 Local service The communication connection is established as follows: SCALANCE M804PB ① Enable the integrated TIA Portal Cloud Connector. PG/PC ② Enable the TIA Portal Cloud Connector to establish an unsecured communication connection to the TIA Portal Cloud Connector of the SCALANCE M804PB. ③...
  • Page 13 – The device is accessible via the PG/PC and you are logged on to the WBM as "Administrator". You can find more information on this in the "SCALANCE M-800 Getting Started (https://support.industry.siemens.com/cs/ww/en/view/78389746)". – The device is connected to the CPU via the MPI interface. • PG/PC –...

  • Page 14: Enabling The Tia Portal Cloud Connector On The Device

    PROFIBUS connection 2.1 Local service 2.1.2 Enabling the TIA Portal Cloud Connector on the device Procedure 1. Click "System" > "Cloud Connector" in the navigation area. 2. Configure the TIA Portal Cloud Connector with the following settings: Operation Enabled Port 9023 (default port) If you change the default port, make sure that it is not occupied by another ser-...

  • Page 15: Enabling The Tia Portal Cloud Connector On The Pg/Pc

    Enabling the TIA Portal Cloud Connector on the PG/PC Requirement • The TIA Portal Cloud Connector V1.1 SP4 (https://support.industry.siemens.com/cs/ww/en/view/109764115) is installed. You can find additional information on the TIA Portal Cloud Connector in the documentation "Working with the TIA Portal Cloud Connector (https://support.industry.siemens.com/cs/ww/en/view/109747305)"...
  • Page 16 PROFIBUS connection 2.1 Local service 7. Click on the link in the "Cloud Connector Communication" area. When the connection to the TIA Portal Cloud Connector of the SCALANCE M804PB has been successfully established, a check mark appears next to the link. 8.

  • Page 17: Connecting To The Tia Portal Cloud Connector

    PROFIBUS connection 2.1 Local service 2.1.4 Connecting to the TIA Portal Cloud Connector Connecting via the TIA Portal 1. Start the TIA Portal and switch to the project view. The color of the TIA Portal Cloud Connector status icon changes to green. 2.
  • Page 18 PROFIBUS connection 2.1 Local service 5. For "Active configuration", select the "SCALANCE M804PB [Automatic protocol detection]" entry and click "OK". 6. Double-click on "Update accessible devices" below the interface. The devices are listed that can be reached via the MPI interface of the SCALANCE M804PB. The diagnostics buffer can be read via "Online &...
  • Page 19 PROFIBUS connection 2.1 Local service Connecting via STEP 7 1. Double-click the STEP 7 icon on your desktop. 2. Open the dialog "Set PG/PC Interface" via "Options > Set PG/PC Interface...". 3. In the "Interface Parameter Assignment Used" list, select the interface "SCALANCE.M804PB.Auto.1".

  • Page 20: Remote Service

    PROFIBUS connection 2.2 Remote service 4. Select "PLC > Display Accessible Nodes". "Accessible Nodes" lists the devices that can be reached via the MPI interface of the SCALANCE M804PB. The diagnostics buffer can be read with "PLC > Module Information". Remote service 2.2.1 Introduction...
  • Page 21 PROFIBUS connection 2.2 Remote service center. The Service Center is connected with the SINEMA RC server via LAN and can be reached in this way. To manage the tunnel connection, the SCALANCE M804PB device and a user for the service technician are created on the SINEMA RC server.
  • Page 22 PROFIBUS connection 2.2 Remote service ② The service technician uses the SINEMA RC client to set up a VPN tunnel to the SINEMA RC server at the service center. With the configuration setting in the SINEMA Remote Connect Server (PC1a), the LAN interface is enabled for the service technician. The service technician uses Remote Desktop to connect his PC (PC2) with the server (PC1b) in the service center.
  • Page 23 – PC1a SINEMA RC server is installed and available. You can find additional information on this in the operating instructions "SINEMA RC Server (https://support.industry.siemens.com/cs/ww/en/view/109482121)". – PC1b The TIA Portal V15 Update 2 or STEP 7 V5.6 is installed on the PC.

  • Page 24: Creating A Device And User On The Sinema Rc Server

    Setting Device information Device name M804PB New password Enter a password and repeat it. Password Confirmation Vendor Siemens Type SCALANCE S615 / M804PB / M826 / M816 VPN settings Apply default settings All access Participant group Select the "Service_Admin" group and click the "Add"...
  • Page 25 PROFIBUS connection 2.2 Remote service 3. Click the "Next" button. Configure the "Network settings". Facility Parameter Setting Subnet settings Device is a network gateway Activate Subnet name Enter "Station1" and click the "Add" but- ton. Participant group Select the "Service_Admin" group and click the "Add"...
  • Page 26 PROFIBUS connection 2.2 Remote service Result A user is created on the SINEMA RC for the service technician and the SCALANCE M804PB device. To connect the SCALANCE M804PB to the SINEMA RC, you need the device ID and CA certificate. You can find this data in the device information. In the navigation area click on "Remove connections"...
  • Page 27 PROFIBUS connection 2.2 Remote service Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 28: Configuring Sinema Rc And Tia Cloud Connector On The Device

    PROFIBUS connection 2.2 Remote service 2.2.3 Configuring SINEMA RC and TIA Cloud Connector on the device Requirement • SCALANCE M804PB has been created on the SINEMA RC. • The SINEMA RC certificate is imported into the SCALANCE M804PB. Procedure 1. Click "System > SINEMA RC" in the navigation area. 2.
  • Page 29 PROFIBUS connection 2.2 Remote service Result TIA Portal Cloud Connector is started and enabled. Under "Information > SINEMA RC", you can check whether the VPN tunnel to the SINEMA RC server has been successfully established. Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 30: Start The Sinema Rc Client On The Pc

    PROFIBUS connection 2.2 Remote service 2.2.4 Start the SINEMA RC client on the PC Requirement • The "Service" user for the service technician is created on the SINEMA RC. • SCALANCE M804PB and the user are assigned to the same participant group. Procedure 1.

  • Page 31: Enable The Tia Portal Cloud Connector On The Server

    • The service technician is connected to the server via Remote Desktop • The TIA Portal Cloud Connector V1.1 SP4 (https://support.industry.siemens.com/cs/ww/en/view/109764115) is installed. You can find additional information on the TIA Portal Cloud Connector in the documentation "Working with the TIA Portal Cloud Connector (https://support.industry.siemens.com/cs/ww/en/view/109747305)"...
  • Page 32 PROFIBUS connection 2.2 Remote service Result When communication has been established successfully, the color of the status symbol changes to yellow. Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 33: Connecting To The Tia Portal Cloud Connector

    PROFIBUS connection 2.2 Remote service 2.2.6 Connecting to the TIA Portal Cloud Connector Connecting via the TIA Portal 1. Start the TIA Portal and switch to the project view. The color of the TIA Portal Cloud Connector status icon changes to green. 2.
  • Page 34 PROFIBUS connection 2.2 Remote service 5. For "Active configuration", select the "SCALANCE M804PB [Automatic protocol detection]" entry and click "OK". 6. Double-click on "Update accessible devices" below the interface. The devices are listed that can be reached via the MPI interface of the SCALANCE M804PB. The diagnostics buffer can be read via "Online &...
  • Page 35 PROFIBUS connection 2.2 Remote service Connecting via STEP 7 1. Double-click the STEP 7 icon on your desktop. 2. Open the dialog "Set PG/PC Interface" via "Options > Set PG/PC Interface...". 3. In the "Interface Parameter Assignment Used" list, select the interface "SCALANCE.M804PB.Auto.1".
  • Page 36 PROFIBUS connection 2.2 Remote service 4. Select "PLC > Display Accessible Nodes". "Accessible Nodes" lists the devices that can be reached via the MPI interface of the SCALANCE M804PB. The diagnostics buffer can be read with "PLC > Module Information". Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...
  • Page 37 PROFIBUS connection 2.2 Remote service Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 39: Profinet Connection

    PROFINET connection Local service 3.1.1 Introduction In this example configuration, the service technician's programming device or PC is directly connected to the SCALANCE M874-3 via Ethernet and the S7 automation system is connected via the PROFINET interface. An S7-300 with CPU 317-2 PN/DP is used as the S7 automation system.
  • Page 40 PROFINET connection 3.1 Local service The communication connection is established as follows: SCALANCE M874 ① Enable the integrated TIA Portal Cloud Connector. Server ② Enable the TIA Portal Cloud Connector to establish an unsecured communication connection to the TIA Portal Cloud Connector of the SCALANCE M874-3. ③...
  • Page 41 – The device is accessible via the PG/PC and you are logged on to the WBM as "Administrator". You can find more information on this in the "SCALANCE M-800 Getting Started (https://support.industry.siemens.com/cs/ww/en/view/78389746)". – The device is connected to the CPU via the PNI interface. • PG/PC –...

  • Page 42: Enabling The Tia Portal Cloud Connector On The Device

    PROFINET connection 3.1 Local service 3.1.2 Enabling the TIA Portal Cloud Connector on the device Procedure 1. Click "System" > "Cloud Connector" in the navigation area. 2. Configure the TIA Portal Cloud Connector with the following settings: Port 9023 (default port) If you change the default port, make sure that it is not occupied by another ser- vice.

  • Page 43: Enabling The Tia Portal Cloud Connector On The Pg/Pc

    Enabling the TIA Portal Cloud Connector on the PG/PC Requirement • TIA Portal Cloud Connector V1.1 SP4 (https://support.industry.siemens.com/cs/ww/en/view/109764115) is installed. Install the version even when a TIA Portal Cloud Connector is already installed. You can find additional information on the TIA Portal Cloud Connector in the documentation "Working with the TIA Portal Cloud Connector...
  • Page 44 PROFINET connection 3.1 Local service 7. Click on the link in the "Cloud Connector Communication" area. When the connection to the TIA Portal Cloud Connector of the SCALANCE M874-3 has been successfully established, a check mark appears next to the link. 8.

  • Page 45: Connecting To The Tia Portal Cloud Connector

    PROFINET connection 3.1 Local service 3.1.4 Connecting to the TIA Portal Cloud Connector Connecting via the TIA Portal 1. Start the TIA Portal and switch to the project view. The color of the TIA Portal Cloud Connector status icon changes to green. 2.
  • Page 46 PROFINET connection 3.1 Local service 5. For "Active configuration", select the "VLAN.INT[PN/IE]" entry and click "OK". 6. Double-click on "Update accessible devices" below the interface. The accessible devices that can be reached via VLAN1 are listed. The diagnostics buffer can be read via "Online & Diagnostics". Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 47: Remote Service

    PROFINET connection 3.2 Remote service Remote service 3.2.1 Introduction In this example configuration, the service technician accesses a server in the service center via remote desktop. In addition to the programming software (TIA Portal), the TIA Portal Cloud Connector is also installed on this server. SINEMA RC is used to secure the TIA Portal Cloud Connector communication connection.
  • Page 48 PROFINET connection 3.2 Remote service The communication connection is established as follows: Station 1 ① Enable the integrated TIA Portal Cloud Connector and connect the VPN tunnel to the SINEMA RC server. Service technician ② The service technician uses the SINEMA RC client to set up a VPN tunnel to the SINEMA RC server at the service center.
  • Page 49 PROFINET connection 3.2 Remote service Settings used For the configuration example, the devices are given the following IP address settings: Device Interface IP address SINEMA RC server LAN port 192.168.0.150 (PC1a) 255.255.255.0 WAN port 192.168.20.150 255.255.255.0 The WAN IP address via which the SINEMA RC server can be reached is the WAN IP address of the router in this example, 192.168.203.150.

  • Page 50: Creating A Device And User On The Sinema Rc Server

    – PC1a SINEMA RC server is installed and available. You can find additional information on this in the operating instructions "SINEMA RC Server (https://support.industry.siemens.com/cs/ww/en/view/109482121)". – PC1b TIA Portal V15 Update 4 is installed on the PC. Access to this server via Remote Desktop is configured for the service technician.
  • Page 51 Enter a password and repeat it. The password must be made up of up- Password Confirmation percase and lowercase letters, numbers and special characters. Vendor Siemens Type SCALANCEM874 / M876 / RM1244 VPN settings Apply default settings All access Participant group Select the "Service_Admin"...
  • Page 52 PROFINET connection 3.2 Remote service Creating users 1. Click the "Create" button and configure the user with the following settings: Parameter Setting Contact data User names Service Logon procedure Password Rights Force comment Activate When the VPN tunnel between SINEMA RC client and server is ended, the user is requested to enter a comment.
  • Page 53 PROFINET connection 3.2 Remote service See also Introduction (Page 47) Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 54: Configuring Sinema Rc And Tia Cloud Connector On The Device

    PROFINET connection 3.2 Remote service 3.2.3 Configuring SINEMA RC and TIA Cloud Connector on the device Requirement • SCALANCE M874 has been created on the SINEMA RC. • The SINEMA RC certificate is imported into the SCALANCE M874. Procedure 1. Click "System > SINEMA RC" in the navigation area. 2.

  • Page 55: Start The Sinema Rc Client On The Pc

    PROFINET connection 3.2 Remote service Result TIA Portal Cloud Connector is started and enabled. Under "Information > SINEMA RC", you can check whether the VPN tunnel to the SINEMA RC server has been successfully established. 3.2.4 Start the SINEMA RC client on the PC Requirement •...
  • Page 56 PROFINET connection 3.2 Remote service 3. Click the "Offline" button. The VPN connection to the SINEMA RC server is established. 4. Click the "Connect all devices" button. Result After successful connection, the SINEMA RC client is assigned a VPN address. Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 57: Enable The Tia Portal Cloud Connector On The Server

    Enable the TIA Portal Cloud Connector on the server Requirement • The TIA Portal Cloud Connector V1.1 SP4 (https://support.industry.siemens.com/cs/ww/en/view/109764115) is installed. You can find additional information on the TIA Portal Cloud Connector in the documentation "Working with the TIA Portal Cloud Connector (https://support.industry.siemens.com/cs/ww/en/view/109747305)"...

  • Page 58: Connecting To The Tia Portal Cloud Connector

    PROFINET connection 3.2 Remote service Result When communication has been established successfully, the color of the status symbol changes to yellow. 3.2.6 Connecting to the TIA Portal Cloud Connector Connecting via the TIA Portal 1. Start the TIA Portal and switch to the project view. The color of the TIA Portal Cloud Connector status icon changes to green.
  • Page 59 PROFINET connection 3.2 Remote service 5. For "Active configuration", select the "VLAN.INT[PN/IE]" entry and click "OK". 6. Double-click on "Update accessible devices" below the interface. The accessible devices that can be reached via VLAN1 are listed. The diagnostics buffer can be read via "Online & Diagnostics". Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...
  • Page 60 PROFINET connection 3.2 Remote service Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...

  • Page 61: Index

    Index Glossary, 4 Service & Support, 4 SIMATIC NET glossary, 4 Training, 4 Cloud Connector Getting Started, 07/2020, C79000-G8976-C507-03...
