Wall Mounting - Eldat Easywave User Manual

1. Press the PTx button briefly. The LED on the bottom of the phone
flashes.
2. Press the Transmit button on the RT26 wristband transmitter. The
LED on the bottom of the phone lights up for 4 seconds..
The phone is now ready to receive commands from the RT26 wristband
transmitter.
Attention: To ensure that the wristband transmitter is programmed
correctly, test the emergency call function!

Wall mounting

The telephone can also be installed on a wall. You require two screws in
order to fix the telephone on a wall.
R
P
Drill two holes whose distance apart corresponds to the bracket to be
used, insert the screws and allow them to project 5 mm from the wall.
Position the telephone on the bracket, fit the screws in the slots and slide
the telephone downwards a little.
Feed the guide tabs (1) on the
wall-mounting bracket (2) in the slots (3)
on the rear side of the telephone. Slide
R
the wall bracket (2) 10 mm upwards until
it audibly snaps into place.
Warning: Ensure that there are no
cables or pipes etc. under the surface
Q
of the wall where you want to drill the
holes.
PTx-button
LED
33
