- Page 1 INSTRUCTION MANUAL FILTER BOARD REPLACEMENT ON THE PRO-VERTER 5000-240 P/N: 05-1000108 DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited. Version 1.0 Updated:20200410 April 2020 | Solar Stik®, Inc.
- Page 2 • Remove jewelry. • Disconnect all power sources to the PRO-Verter such as batteries, Power Hubs and generators. Ensure all breakers and switches are in OFF position. If in doubt, please contact Solar Stik 24/7 Tech Support at 800-793-4364 Ext. 102.
- Page 3 PRO-Verter 5000-240 Filter Board Replacement 1. Remove the twenty-two (22) fasteners around the perimeter of the PRO-Verter Faceplate (see orange circles, right) using a #2 cross-tip screw driver. Retain hardware for reinstallation. 2. Lift the left side of the PRO-Verter Faceplate and swing it open to the right.
- Page 4 PRO-Verter 5000-240 Filter Board Replacement 4. Use a Torx T15 driver to remove the four (4) mounting fasteners, one on each corner of the board (orange circles). The fasteners are long and pass through standoffs to connect to the AC Board below.
