- Page 1 INSTRUCTION MANUAL FILTER BOARD REPLACEMENT ON THE PRO-VERTER 7000-120 P/N: 05-1000098 DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited. Version 1.0 Updated:20200410 April 2020 | Solar Stik®, Inc.
- Page 2 • Remove jewelry. • Disconnect all power sources to the PRO-Verter such as batteries, Power Hubs, and generators. Ensure all breakers and switches are in OFF position. If in doubt, please contact Solar Stik 24/7 Tech Support at 800-793-4364 Ext. 102.
- Page 3 PRO-Verter 7000-120 Filter Board Replacement Note: • Use a camera to document original installation configuration to facilitate reassembly. • Label wires to reduce potential for misconnection during reassembly. 1. Remove the twenty-two (22) fasteners around the perimeter of the PRO-Verter Faceplate (see orange circles, right) using a #2 cross-tip screwdriver.
- Page 4 PRO-Verter 7000-120 Filter Board Replacement 4. Use a #0 flat-tip screwdriver to press down the release for the “START” and “FINISH” wires. Gently pull wires to remove. Both wires look the same. Label wires to assist installation of replacement board.
