INSTRUCTION MANUAL
VRT300 SERIES
1MN0048 REV. 0
operates with ISO9001:2008 certified quality system
TECSYSTEM S.r.l.
20094 Corsico (MI)
Tel.: +39-024581861
Fax: +39-0248600783
http://www.tecsystem.it
R. 1.0 16/09/13
ENGLISH
                                                          "Translations of the original instructions"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VRT300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TECSYSTEM VRT300 Series

  • Page 1 INSTRUCTION MANUAL VRT300 SERIES 1MN0048 REV. 0 operates with ISO9001:2008 certified quality system TECSYSTEM S.r.l. 20094 Corsico (MI) Tel.: +39-024581861 Fax: +39-0248600783 http://www.tecsystem.it R. 1.0 16/09/13 ENGLISH                                                           “Translations of the original instructions” ...
  • Page 2: Table Of Contents

    INTRODUCTION First of all we wish to thank you for choosing to use a TECSYSTEM product and recommend you read this instruction manual carefully: You will understand the use of the equipment and therefore be able to take advantage of all its functions.
  • Page 3: Safety Requirements

    POWER SUPPLY The VRT300 series can be supplied by 230Vac 50/60Hz o a 12Vac –Vcc, depending on the model purchased. Before using it, make sure the power cable is not damaged, kinked or pinched. Do not tamper with the power cable. Never disconnect the unit by pulling the cable, avoid touching the pins.
  • Page 4: Accessories

    * The above terminals are optional according to the configuration purchased. ATTENTION: always install the device using the terminals included in the pack. The use of terminals other than those included with the control unit might cause malfunctions. VRT300 SERIES  ...
  • Page 5: Technical Specifications

    Hole 92 x 92 mm Hole 92 x 92 mm         TEST AND PERFORMANCE     Construction in compliance with CE regulations ● ●     Protection from electrical interference EN 61000-4-4 ● ● VRT300 SERIES  ...
  • Page 6     VRT300 SERIES VRT300 U SERIES TECHNICAL SPECIFICATIONS         TEST AND PERFORMANCE   Dielectric strength 1500 Vac for 1 minute: supply - relay fault, supply - remote.   ● ●     Ambient operating temperature from –20°C to +60°C ●...
  • Page 7: Front Panel

    Fans' control mode REM/LOC button Monitoring delay LED (yellow) at start up (REMOTE or LOCAL) start d. 10) ENT/RESET button: alarm reset and Trip delay LED (yellow) trip d. programming data selection     11) Motors' auto-tuning phase LED (yellow) VRT300 SERIES  ...
  • Page 8: Installation

    Drill a 92 x 92 mm hole in the panel sheet. 1MN0063 REV. 0 Panel hole dimensions (+0.8mm tolerance) Control unit     Identification label Fix the unit securely with the blocks supplied. 1MN0008 REV. 0 Control unit Fixing screw Fixing block Crosshead screwdriver #1X100mm VRT300 SERIES  ...
  • Page 9: Electrical Connections

    ELECTRICAL CONNECTIONS VRT300 SERIES 1MN0048 REV. 0 M1-M2-M3 motor line connection (5A FAULT relay (fault signal) max) Remote enabling contact ENABLE Fan line supply 250Vac ±10% 15 amp.max 50-60Hz.     Control unit supply 230 Vac ±10% 50-60 Hz 4VA Note: with the power to the unit ON, the FAULT relay switches, contacts 8-9 open (NO) and 7-9 closed (NC).
  • Page 10: Vrt300 U Back

    Control unit supply 12Vac-dc ±10% 4VA Note: with the power to the unit ON, the FAULT relay switches, contacts 8-9 open (NO) and 7-9 closed (NC). FAULT 8-9 NC: ALARM FAULT OR POWER OFF FAULT 7-9: NC POWER ON   VRT300 SERIES...
  • Page 11: Power Supply

    IMPORTANT NOTE: if an existing control unit must be replaced with a new one, to guarantee its correct and safe operation, all the connecting terminals must be replaced with the new terminals supplied, on condition the brand of the new terminals is different from the one of the previously installed ones.   VRT300 SERIES...
  • Page 12: Programming

    ATTENTION: We recommend you check the control unit before starting the device. The default parameters set by TECSYSTEM might not suit your requirements. Programming the device is the end user’s responsibility: the set alarm thresholds and the enabled functions described in this manual must be checked (by a specialized technician) referring them to the application and system characteristics on which the control unit is installed.
  • Page 13: Warranty Regulations

    Returning used electrical devices: contact TECSYSTEM or the TECSYSTEM agent for information on the correct disposal of the devices. TECSYSTEM is aware of the impact its products have on the environment and asks its customers active support in the correct and environmentally-friendly disposal of its devices.
  • Page 14: Useful Contacts

    USEFUL CONTACTS TECHNICAL INFORMATION: ufficiotecnico@tecsystem.it COMMERCIAL INFORMATION: info@tecsystem.it PRODUCT INFORMATION (CATALOGUES) DOWNLOAD CONTROL UNIT MANUALS ACCESSORIES       VRT300 SERIES...
