- Page 1 INSTRUCTION MANUAL FO 935 ETH 1MN0257 REV.0 operates with ISO9001 certified quality system TECSYSTEM S.r.l. 20094 Corsico (MI) Tel.:+39-024581861 Fax:+39-0248600783 http://www.tecsystem.it R. 1.0 12/01/22 ENGLISH “Translations of the original instructions”...
- Page 2 INTRODUCTION First of all we wish to thank you for choosing to use a TECSYSTEM product and recommend you read this instruction manual carefully: You will understand the use of the equipment and therefore be able to take advantage of all its functions.
-
Page 3: Table Of Contents
COOLING FAN CONTROL ………………………………….. • FAN TEST ………………………………….. — 8) FAIL-SAFE FUNCTION ………………………………….. 9) PROGRAMMING ………………………………….. • — FO 935 ETH PROGRAMMING ………………………………….. • PROGRAMMING NOTES ………………………………….. 10) OUTPUT ETHERNET MODBUS TCP — ………………………………….. • INTRODUCTION TO THE ETHERNET MODULE — ………………………………….. - Page 4 POWER SUPPLY The FO 935 ETH control unit can be supplied by 85 to 260 Vac-Vdc, irrespective of the polarity in Vdc. Before using it, make sure the power cable is not damaged, knotted or pinched. Do not tamper with the power cable. Never disconnect the unit by pulling the cable and avoid touching the pins.
- Page 5 ACCESSORIES The FO system boxes contain are the following objects: FO 935 ETH control unit FO 935 ETH control unit Start guide and QR code 2 blocks for panel fixing 1 Terminal 3 pitch poles 5 supply Code:2PL0367 - Screw tightening torque 0.5Nm 1 terminal 12 pitch poles 5 relays Code:2PL0361 - Screw tightening torque 0.5Nm...
- Page 6 FO SENSORS 3 temperature sensors in optical fibre 2.5mt Start guide and QR code TECHNICAL SPECIFICATIONS FO 935 ETH POWER SUPPLY 85-260 Vac-Vcc Supply rated values 50/60HZ ● Vdc with invertible polarities INPUTS ● 1 digital input (FO IN) CONC connection.CFO 521 ●...
- Page 7 TECHNICAL SPECIFICATIONS FO 935 ETH ● TESTS AND PERFORMANCE ● Construction in compliance with the EC regulations ● Protection from electrical interferences EN 61000-4-4 Dielectric strength 1500 VAC for 1 min. between output relay and FO IN input, relay and ●...
- Page 8 CONC concentrator fixing bracket CFO 521 TEMPERATURE SENSOR TECHNICAL SPECIFICATIONS FO (FIBRE OPTIC) TESTS AND PERFORMANCE Reading range -35°C to +195°C Interface precision ±1.0°C ● Permitted humidity 90% without condensate External protection DIMENSIONS Length 2.5mt Tip probe diameter 2.3mm Fibre connector model FO 935 ETH...
- Page 9 FAN 1 (yellow) LED T-max mode selection (red) LED FAN 2 (yellow) LED Man mode selection (yellow) LED Display mode selection key Auto mode selection (green) LED Fixing blocks Scan mode selection (yellow) LED UP key Fixing blocks DOWN key FO 935 ETH...
- Page 10 We suggest carrying out the control unit LED test regularly. For this operation, press the TEST key briefly; all the displays turn on for 2 seconds. If one of the LEDS does not work, please return the control unit to TECSYSTEM for repair. ALARM RELAY TEST This function allows you to carry out a test of the relays operation without having to use further devices.
- Page 11 The CFO 521 support bracket could facilitate this operation. Always respect the safety distance, suggested by the transformer manufacturer, from the transformer windings. Fix the bracket, on one of the sides of the transformer, using the 8mm hole with an M8 pin with nut and washer. FO 935 ETH...
- Page 12 • be created with shielded cable with twisted conductors • have a section of at least 0.25 mm² • the shield must be earthed on one side only • be firmly fixed in the terminal blocks • have tin-plated or silver-plated conductors FO 935 ETH...
- Page 13 Single or multiple LED flashing:L1-L2-L3, single flash every 2 seconds, indicates correct functioning of the CH1- CH2-CH3 channel. • Single or multiple flashing LED:L1-L2-L3, double flashing every 2 seconds, indicates the incorrect operation of the reference channel of the channel CH1-CH2-CH3. FO 935 ETH...
- Page 14 Drill a hole in the panel sheet with dimensions of 92 x 92 mm. 1MN0007 REV.0 Control unit Panel hole dimensions (+0.8 mm tolerance) Identification label Secure the appliance firmly by means of the supplied fixing blocks. 1MN0008 REV.0 Control unit Fixing screws Fixing blocks Cross-head screwdriver #1X100mm FO 935 ETH...
- Page 15 ELECTRICAL CONNECTIONS FO 935 ETH 1MN0257 REV.0 Power supply 85-260Vac-dc 50/60Hz FO IN bus input for connection to the CFO 521 RJ45 Ethernet output, Link-Activity led, see Relay (ALARM-TRIP-FAULT-FAN1-FAN2) indication on page 33. Note: image relay contacts in non-alarm condition, except for the FAULT relay which switches: contacts 10–11 closed (NO) contacts 9-11 open (NO) fault condition identification.
- Page 16 POWER SUPPLY The FO 935 ETH can be supplied by 85 to 260 Vac-Vdc, 50/60 Hz irrespectively of polarity in Vdc (terminals 40 - 42). This particularity is obtained thanks to the use of a tested power supply, of new conception and realisation, which frees the installer from any uncertainty regarding the correct Vac or Vdc power supply.
-
Page 17: Cooling Fan Control
Eliminate the Ech indication by pressing RESET and run programming to enter the desired values. Finally switch the unit off and back on to check the memory works correctly, if it is damaged Ech will be displayed again (send the control unit to TECSYSTEM srl for repairs). TEMPERATURE DIAGNOSTICS When one of the sensors detects a temperature higher than 1°C with respect to the pre-set value as the alarm limit, after... -
Page 18: Fan Test
• PRG programming. • Test of the relays. The FAIL SAFE function is temporarily disabled and the FAULT relay switches. ATTENTION: Entering the relay test mode will temporarily disable the fail-safe function, relays with enabled function switch (ALARM-TRIP-FAULT). FO 935 ETH... -
Page 19: Programming
PROGRAMMING FO 935 ETH STEP PRESS EFFECT PRESS NOTES Press and hold the PRG button until the display shows SET PRG Select PRG SET to proceed with programming or PRG 1 PRG 1 default data to load the default values The ALARM threshold for (CH 1-2-3) is displayed. -
Page 20: Programming Notes
We recommend you check the device's programming before starting the device. The default parameters set by TECSYSTEM might not match your requirements. Programming the device is the end user's responsibility. The settings of the alarm thresholds and enabling of the functions described in this manual must be checked (by a specialist engineer) according to the application and features of the system the control unit is installed on. -
Page 21: Introduction To The Ethernet Module
The ETH module is always in slave mode. The FO 935 ETH control unit is in communication with the network only when it is in temperature reading mode, while it is inactive when in the following modes: display, programming and test relays. -
Page 22: Notes For Remote Programming
Trip thresholds and that the Fan-on thresholds must be higher than the Fan-off thresholds. In case you try to set these thresholds incorrectly, the control unit FO 935 ETH will not proceed with the programming and storage of data, therefore in subsequent readings will read the data from the previous schedule. -
Page 23: Illegal Data
Model - 2nd Digit (ASCII) Vers.Fw – MSD(ASCII) Space (20H) Vers.Fw – LSD(ASCII) Vers.Fw - 2nd Digit (ASCII) Qty channels (2*ASCII) Options (see notes) Options (see notes) Incorrect datum received R-see tab. Info various causes R-see tab. Controls W-see tab. FO 935 ETH... - Page 24 See Notes CPU Error See Notes See Notes Status Relay FREE See Note Modbus Address 1÷255 address 0=2400 1=4800 Modbus baud 2=9600 rate 3=19200 4=38400 0=N-1 None+1Stop 1=Even Modbus parity Parity 2=Odd 3=N-2 None+2Stop FREE See Note FO 935 ETH...
- Page 25 2’compl. sign 1°C ÷ 190°C As (AL) alarm set point 2’compl.Ch2 temper. 2’compl. sign 1°C ÷ 190°C As (TRP) trip set point 2’compl. sign 2’compl.Ch3 temper. –35°C ÷ 195°C 2’compl. sign 2’compl.Ch3 max temperat. 0°C ÷ 195°C FO 935 ETH...
- Page 26 2’compl. sign 2’compl.Ch4 temper. –35°C ÷ 195°C 2’compl. sign 2’compl.Ch4 max temperat. 0°C ÷ 195°C 2’compl.Ch4 temper. 2’compl. sign 1°C ÷ 190°C alarm set point 2’compl.Ch4 temper. 2’compl. sign 1°C ÷ 190°C trip set point FO 935 ETH...
- Page 27 Data LO Notes 1 Notes 2 W:write (10) W: read/write Ch1 story Ch1 status See Notes CHx Ch2 story Ch2 status See Notes CHx Ch3 story Ch3 status See Notes CHx Ch4 story Ch4 status See Notes CHx FO 935 ETH...
- Page 28 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 TEC ERR FO ERR CPU SETTING BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Failsafe Failsafe fault Failsafe trip alarm FO 935 ETH...
-
Page 29: Eth0 Connections
X Windows Vista, 7, 8. ETH0 CONNECTIONS Using an Ethernet cable, connect the FO 935 ETH of the FO 935 ETH control unit to the Ethernet card of a PC. TELNET ENABLING Use the Telnet program to set the Ethernet IP parameters. -
Page 30: Telnet Screen
13) Enter: OPEN 14) Press ENTER 192.168.10.120 9999 15) Enter: 16) Press ENTER 17) Enter the Password: TECS 18) Press ENTER Note: In this screen we have the MAC address and the software version of the ETH port available. FO 935 ETH... -
Page 31: Ip Parameter Programming Menu
IMPORTANT INFORMATION For a correct operation of the device it is advised not to access or modify menus 2-3-4-7.Changing the values contained in the indicated menus could lead to communication anomalies with loss of IP Ethernet communication. FO 935 ETH... - Page 32 At the end of the operation, the system will ask if you wish to modify the Telnet password: Type in: to modify the Telnet Password. to not modify the Telnet Password and to go to the following step. FO 935 ETH...
- Page 33 Indications of LEDs 1-2 of the Ethernet port: LED 1:Link ➢ = No link ➢ Amber = 10 Mbps ➢ Green = 100 Mbps LED 2:Activity ➢ = No Activity ➢ Amber = Half Duplex ➢ Green = Full Duplex FO 935 ETH...
- Page 34 Returning of used electrical appliances: contact TECSYSTEM or the TECSYSTEM agent to receive information on correct disposal of the appliances. TECSYSTEM is aware of the impact its products have on the environment and asks its customers active support in the correct and environmentally-friendly disposal of its devices.
- Page 35 USEFUL CONTACTS TECHNICAL INFORMATION: ufficiotecnico@tecsystem.it COMMERCIAL INFORMATION: info@tecsystem.it FO 935 ETH...
