HK Instruments DPT-Priima Series Installation Instructions

INTRODUCTION
Thank you for choosing an HK Instruments DPT-Priima differential
pressure transmitter. DPT-Priima is a high-precision differential pres-
sure transmitter engineered especially for cleanrooms and other high
accuracy applications. DPT-Priima has an automatic zero point calibra-
tion and is optionally available with span point calibration, local display
and calibration certificate. The versatility of the device is enhanced
by eight selectable measuring ranges and by outputs with a voltage or
current signal.
APPLICATIONS
DPT-Priima is commonly used in applications requiring high
measurement accuracy:
• monitoring pressure in cleanrooms
• monitoring pressure difference across the building envelope
SPECIFICATIONS
• monitoring pressure and flow
SPECIFICATIONS
Performance
Measurement accuracy* (from applied pressure):
0.4 % ±0.4 Pa
(including: general accuracy, linearity, hysteresis,
long term stability, and repetition error)
Output accuracy*:
Voltage:
± 0.025 V at 25 °C
Current: ± 0.04 mA typical, at 25 °C, load 100 Ω
± 0.1 mA max, at 25 °C, load 20–500 Ω
*after an half-hour warm-up time
Overpressure:
Proof pressure: 10 kPa
Burst pressure: 30 kPa
Zero point calibration:
Automatic autozero and manual pushbutton
Response time:
0.4 s or 8.0 s, selectable via jumper
(63 % of the change)
Technical Specifications
Media compatibility:
Dry air or non-aggressive gases
Measuring units:
Pa, kPa, mbar, inchWC, mmWC, psi, selectable
via jumper
Measuring element:
MEMS, no flow-through
Environment:
Operating temperature: -5...50 °C,
Temperature compensated range 0...50 °C
Storage temperature: -40...70 °C,
Humidity: 0 to 95 % rH, non-condensing
Copyright HK Instruments 2021
DIFFERENTIAL PRESSURE TRANSMITTERS
DPT-Priima Series
• READ THESE INSTRUCTIONS CAREFULLY BEFORE
• Failure to observe safety information and comply with
• To avoid electrical shock or damage to equipment, disconnect
• To avoid potential fire and/or explosion do not use in potentially
• Retain these instructions for future reference.
• This product, when installed, will be part of an engineered
Physical
Dimensions:
Case: 90.0 x 95.0 x 36.0 mm
Weight:
140g
Mounting:
2 each 4.3 mm screw holes, one slotted
Materials:
Case: ABS
Lid: PC
Duct connectors: ABS
Tubing: PVC
Protection standard:
IP54
Display (Optional)
2-line display (12 characters/line)
Line 1: active measurement
Line 2: units
Electrical connections:
4-screw terminal block
Wire: 0.2–1.5 mm (12–24 AWG)
2
Cable entry: M16
Pressure fittings:
Male ø 5,2 mm
+ High pressure
− Low pressure
www.hkinstruments.fi
WARNING
ATTEMPTING TO INSTALL, OPERATE OR SERVICE THIS
DEVICE.
instructions can result in PERSONAL INJURY, DEATH AND/OR
PROPERTY DAMAGE.
power before installing or servicing and use only wiring with
insulation rated for full device operating voltage.
flammable or explosive atmospheres.
system whose specifications and performance characteristics
are not designed or controlled by HK Instruments. Review
applications and national and local codes to assure that the
installation will be functional and safe. Use only experienced and
knowledgeable technicians to install this device.
Electrical
Voltage:
Circuit: 3-wire (V Out, 24 V, GND)
Input: 24 VAC or VDC, ±10 %
Output: 0–10V / 2–10V
Power consumption: <1.0 W,
Resistance minimum: 1 kΩ
Current:
Circuit: 3-wire (mA Out, 24 V, GND)
Input: 24 VAC or VDC, ±10 %
Output: 4–20 mA
Power consumption: <1.2 W,
Maximum load: 500 Ω
Minimum load: 20 Ω
Conformance
Meets the requirements for:
EMC:
RoHS:
WEEE:
INSTALLATION
INSTRUCTIONS
CE: UKCA:
2014/30/EU S.I. 2016/1091
2011/65/EU S.I. 2012/3032
2012/19/EU S.I. 2013/3113
Installation version 2.0 2021
RoHS
COMPLIANT
