TECHNICAL NOTE
Date 20th Jan 17 rev 3
ref 372
Raised by: TC
Distributed to: as required
Soundtracs - Digico(UK) Ltd. unit 10 Silverglade Business Park Chessington Surrey KT9 2QL England
Tel: +44 1372 845600 Fax: +44 1372 845656 email: support@digiconsoles.com
SD12 and other Win7e based mixers
Use of HORM system and overview screen setup
Introduction to HORM
HORM - Hibernate Once Read Many - This is a Windows 7e function an equivalent to Ready On
as used on the older SD-series consoles based on Win XPe. The functionality of this is slightly
different.
In the same way as Ready On, it protects the C: Drive from unintended changes.
The method of making intended changes is quite different to the older system and is described
below.
The main difference that is immediately seen between HORM and Ready-On is that there is no
command line path to start an application on startup.
NOTE: This means that even with HORM disabled, the SD12 application will still start
automatically and that cannot be prevented.
*In the case of a corrupted startup.ses preventing the console starting up correctly, holding the
SHIFT key will still offer the option of a "default start". Hold the SHIFT key as soon as you see the
SD12 logo appear on the Master screen
Use of HORM system
The access the HORM system quit to Windows from the mixer program.
Touch "Quit to Windows" under the system button.
There is a small icon at the bottom of the Start Bar which is the shortcut to HORM configuration.
The left picture shows the HORM icon when active and with the drive locked (normal use) and the
right picture when available but the drive is not locked.
TN372
Page 1
Advertisement
Table of Contents
Related Manuals for digico SD12
Summary of Contents for digico SD12
- Page 1 The main difference that is immediately seen between HORM and Ready-On is that there is no command line path to start an application on startup. NOTE: This means that even with HORM disabled, the SD12 application will still start automatically and that cannot be prevented.
- Page 2 Double click the HORM icon in the tool bar to open the program. Once open, the HORM application looks like this: Note how the HORM status should ALWAYS be shown enabled, whether active or not. Clicking Configure opens this: Note HORM support must ALWAYS be checked. TN372 Page 2...
- Page 3 In order to disable protection in a mixer with protection on (the normal mode): Click on the C: drive to highlight this Click on the “pending command” drop down box Select “commit and disable live” as above Click on Apply Click on OK On the remaining Window click close.
- Page 4 If no overview screen is connected, see the following screen open If only one screen indicated as 1 / 2 is shown ensure “extend these displays” is selected and the 2 screens appear as above. Use the identify feature in the normal manner for Windows. Note the automatically detected screen settings (type &...
- Page 5 If the layout of screen is not as shown (2 to the left of 1 and 3 above 1 & 2) this must be set. With a new screen it will default to a horizontal spread. Use the mouse in the conventional manner to click and drag the screens so they match above. Note how the edges align.
- Page 6 Highlight the C: drive (note the state is now disabled) Click on the “pending command” drop down and note different options. Select Enable Click on Apply Click OK On the remaining Window click close. To create the HORM image and correctly save, click on the start button and close Windows as normal. Power cycle the mixer.
