MODEL: GM16
GREENHOUSE SIZE: 13' 3 7/8"L x 16'7 3/16"W x 9'11"H
EXTENSION SIZE: 6'6 3/4"L x 16' 7 3/16"W x 9'11"H
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
Item No.
Model No.
2553300
GM16
2553350
GM16 ext
Assembly Instructions
406cm L x 506cm W x 302cm H
200cm L x 506cm W x 302cm H
AL No.1
AL No.2
1CTN
1CTN
Packing List
AL No.3
AL No.4
1CTN
1CTN
1CTN
Customer Support
Support@ACFgreenhouses.com
1-888-888-9050
PC No.1
PC No.2
1CTN
2CTNS
1CTN
Advertisement
Related Manuals for ACF Greenhouses GROW MORE GM16
Summary of Contents for ACF Greenhouses GROW MORE GM16
- Page 1 Assembly Instructions MODEL: GM16 GREENHOUSE SIZE: 13' 3 7/8"L x 16'7 3/16"W x 9'11"H 406cm L x 506cm W x 302cm H EXTENSION SIZE: 6'6 3/4"L x 16' 7 3/16"W x 9'11"H 200cm L x 506cm W x 302cm H PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY Packing List Item No.
- Page 2 CONTENTS 1. Assembly Advice ..............Page 1 2. Product Features ..............Page 1 - 2 3. Parts List ................Page 3 - 6 4. Base Assembly ..............Page 7 - 10 5. Door Assembly ..............Page 11 - 13 6. Roof Vent Assembly ............Page 14 7.
- Page 3 Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that this product is assembled by at least two people. 2. Some components have sharp metal edges. Please be careful when handling metal components. Please wear gloves, shoes and safety goggles during assembly. 3.
- Page 4 5. A steel base is not required as the aluminium base frame is fixed to the necessary concrete footings with the expansion bolts provided, alternatively you can easily secure it to a timber base with timber screws(not provided). Expansion screw / Concrete ground 6.
- Page 5 ALU. Box No.1 QTY. PART PART QTY. L01A L04A L02C L04C L02D L04D L02F L04E L02G L05A L03C L05B L03D L08A L03E L08B L03F ALU. Box No.2 PART QTY. PART QTY. L01B L01C L02A L08B L02B L02E L15A L02F L04B L05B L05C L04E...
- Page 6 ALU. Box No.3 QTY. PART QTY. QTY. PART PART L18A M6X12 L18B L18C M6X20 L16A L16B L16C Ø5X15 L18D Ø4X16D L18F L18E Ø5X30 Ø4X8 L05G L05H Ø3.2X10 J01R/L M8X60 J06R/L...
- Page 7 ALU. Box No.4 (2 Section Assembly) QTY. PART QTY. PART L02A L02B L02F L02H L02K L03A L03B L04B L05B L05C L05D M5X25 M6X20 L08B Ø4X16D L15A Ø5X30 Ø4X8 L04E M8X60...
- Page 8 PC Box No.1 PART QTY. PC Box No.1 PC Box No.2 x 2PCS (2 Section Assembly) PART QTY. PC Box No.2...
- Page 9 10mm Expansion bolt in concrete It is essential the dimensions a + b are the same to ensure the base is square. Steel pegs in soil Support at the corners only is inadequate.
- Page 10 GM16 Rear Assembly Front Assembly 43.4mm 4 Section Assemby Dim/Model GM16+Ext(1) GM16+Ext(2) GM16+Ext(3) GM16+Ext(4) GM16+Ext(5) GM16 etc. (mm) 5061.8 5061.8 5061.8 5061.8 5061.8 5061.8 (mm) 4059.8 6061.8 8063.8 12067.8 10065.8 14069.8 (mm) 6488.7 7897.3 9520.8 11266.9 13086.4 14952.6 (mm) 6366.7 12972.9 14841.7 a1=b1...
- Page 11 GM16+Ext(1) Front Rear 2 Section 2 Section 2 Section Assembly Assembly Assembly Middle Middle Section Section GM16ext GM16 * The basic model,GM16,can be easily extended by adding a '2 Section Assembly'each time for a longer size.
- Page 12 1000 1000 1000 1000 1000 1000 Front Back 2 Section Assembly GM16 + Ext(1) * This shows a layout for W05's positions where it is placed in the middle of PC panel for each section. * All measurements in above diagram are in mm.
- Page 13 PART QTY. L18A Door 1 Assembly L18B L18C L18C L16C L05G L18A Ø5X15 L16C M6X12 L05G L05G L18B L18C L18C L16C L18A L18A L16C L18B L18B...
- Page 14 PART QTY. Door 2 Assembly L18A L18B L18B L16A L16B L05G L18A Ø5X15 L16A M6X12 L05G L05G L16B L18B L16A L18A L18A L16A L16B L16B...
- Page 15 PART QTY. Door 3 Assembly L18D L18E L18E L18F L05H Ø5X15 L18D M6X12 L18F L05H L05H L18E L18D L18E L05H L05H L18E L18F L18D L18F L18E L18E...
- Page 16 PART QTY. L15A Roof Vent Assembly L15A Ø4X16D...
- Page 17 PART QTY. L08A L08B L08B L08B L08A L08B L08A J01R/L L08B L08A L08B L08A L08B make sure you pay L08A&L08B close attention to the direction of the pins J01R/L L08A L08B L08A L08B J01R/L L08A&L08B make sure you pay close attention to the direction L08A L08B...
- Page 18 QTY. PART L01A L03C L03D L03C L01A L03D L01A L01A L03C&D L01A...
- Page 19 QTY. PART L02E L02E L02C L02C L02F L02D L02G L02E L02D L02F S05x6pcs L02G L02F L02G L02C&D L05A L05B M6X12 S05x3pcs L05A L05B L05B L05A L03C&D L01A L01A L02G&F L02G L02G L05A L02G&F L05A L05A L02C L02D L03C&D L05A L02F L08A L08A L02E...
- Page 20 QTY. PART L04D L04E Y14 Y14 Y2 M6X12 L04D L04D L04E L04E L04D L04D L04D&E S05x2pcs Slide 2 x S05 into each L04D & E, and put each profile onto the edge of each PC panel, then tighten all profiles at each end with S05.
- Page 21 QTY. PART L01B L01C M6X12 L01B L01C L01B L01C make sure make sure you pay you pay close attention close attention to the direction L01B to the direction of the pins L01C of the pins...
- Page 22 L01B L01C L01C L01B L01A L01A Note: please insert upper roof supports but, do not lock in place until you have aligned the poly-carbonate inserts. L01B L01C...
- Page 23 QTY. PART L03A L03B L03B M6X12 L03A L03A L03A L03B L03B L03A...
- Page 24 QTY. PART L02H L02K M6X12 L02K L02H L02H L03B L03A L02K L02H L02H...
- Page 25 QTY. PART make sure make sure you pay you pay close attention close attention to the direction to the direction of the pins of the pins...
- Page 26 QTY. PART L02A L05B L05C M6X12 L05B L02A L05C L05C L02A L05B L02A L08B L02A L05C L03A L05B L08B...
- Page 27 PART QTY. L01A L03E L03F L02C L02D L02G L02F L04A L04C L05A M6X12 L01A L03E L03F L01A L01A L01A L03E&F...
- Page 28 Slide 3 x S05 into L04A, and tighten L04C L02F L02D L04A L04A at each end with S05. L02G L04A S05x3pcs L05A L02G L02C L05A L03E&F L01A L01A L02G L02G L02G L05A L05A L03E&F L04A L04C L02F L03E&F L04A L05A L02C L02D L05A...
- Page 29 PART QTY. L04D M6X12 Y14 Y14 L04D L04D L04D S05x2pcs Slide 2 x S05 into each L04D and put each L04D onto the edge of each PC panel, then tighten all profiles at each end with S05.
- Page 30 QTY. PART L04A L01B L01C M6X12 L01C L01B L01B L01C L01B L01C...
- Page 31 L01C L01B L01A L01A L01B L01C...
- Page 32 QTY. PART...
- Page 33 QTY. PART L02A L05B L05C M6X12 L05B L02A L05C L02A L08B L02A L05C L02A L05B L08B...
- Page 34 QTY. PART L02B L02B L02B M6X12 L02B S05x6pcs L02A L02B Note: Slide 6xS05 in the channel, which are needed later.
- Page 35 QTY. PART L02F L02F L02F L02F M6X12 L02F L03B L01B&C L02F L02F L02F L02B...
- Page 36 QTY. PART Roof Vent M6X20 Roof Vent Assembly x 4PCS L15A L15A S11/M03 L15A L15A...
- Page 37 PART QTY. L04B L04E Ø4X8 M6X12 Insert all Y6 into each side of greenhouse. Insert all Y7 into each roof of greenhouse.
- Page 38 L04B L04B L04E L04E L04E L04B S05x2pcs S05x6pcs Pay attention to the cut edge of L04B Pay attention to the cut edge of L04E which should be fixed, facing down. which should be fixed, facing up. L04E L04E L04E S05/M03 REPEAT the same assembly for another side.
- Page 39 QTY. PART L05D L05D L05D M6X12 Insert all Y9 into each roof of greenhouse.
- Page 40 QTY. PART Door 1 Door 2 Door2 Assembly Door 3 J06R/L Ø5X30 Ø4X16D Door1 Assembly Door3 Assembly Use L09 to cover the edges of all Y9 after all roof PC panels are fixed in place, then tighten them with Z10.
- Page 41 J06R/L J06R/L J06R/L J06R/L J06R/L...
- Page 42 QTY. PART Ø4X8 Ø3.2X10 Z04&Z06 Z04&Z06 L04D L04D Drill the holes on each L04D as shown, Dia.3.2mm, and secure the hooks H10 with Z04 & Z06, then ensure D17 works with Door1 & 2 & 3 properly when the doors are open.
