1. Scope

This specification is applicable to Toshiba Matsushita Display Technology's 31cm diagonal size TFT-LCD module without
backlight "LTD121EA43G" designed for Note PC.

2. Product Specifications

2.1 General Specifications

Item
Display Mode
Viewing Direction
Driving Method
Input Signals
Active Area
Number of Pixels
Pixel Pitch
Pixel Arrangement
Surface Treatment
Dimensional Outline of Glass
Transmission axis direction of
polarizer
(at the time of looking from front)
1
Note 1)
R G B
1
R G B
2
767 R G B
R G B
768
Toshiba Matsushita Display Technology Co.,Ltd
Specification No.
Specifications
TN color(64 gray scales, 262,144 colors)
Transmissive type, Normally white
6 o'clock (in direction of maximum contrast)
TFT active matrix
LVDS interface
CLK+, CLK-,
RxIN0+, RxIN0-, RxIN1+, RxIN1-, RxIN2+, RxIN2-
245.76 (W ) × 184.32 (H ) (mm)
1024 (W ) × 768 (H )
0.240 (W ) × 0.240 (H ) (mm)
RGB vertical stripes
Anti-Reflection and hard coat 3H on LCD surface
252.1 (W ) × 192.4 (H ) × 1.27 (D ) (mm)
45 degree (inclination with X-axis) (refer to 2.3.2 Dimensional Outline)
2
R G B
R G B
R G B
R G B
1)
1)
1)
1023 1024
R G B R G B
R G B
R G B
R G B R G B
R G B
R G B
0.240mm
0.240mm
Date: 2004-04-20 New No. LTD121EA43G-01
Old
Date:
←# Special
: pixel
R G B
: Sub-pixel
B
R G
(Dots)
No.
←& Addition ← Change
