1 PREFACE & GENERAL SAFETY

1.1 EMC Conformity

This product is in conformity with:
EN 61000-6-2 Generic standards immunity for industrial environments,
-
EN 61000-6-4 Generic standards emission for industrial environments,
-
EN 55011 Limits and methods of measurement of radio disturbance characteristics of
-
industrial, scientific and medical (ISM) radio-frequency equipment and
EN 61000-3-12 Limits for harmonic currents produced by equipment connected to public
-
low-voltage systems with input current 16 A and 75 A per phase
With the following installation conditions:
● installing an AC line reactor to the drive power supply input.
● installing a RFI filter to the drive motor output.
● using shielded cables for motor, brake resistor and encoder connections outside the
device.

1.2 Safety Information

After switching off the device do not touch any electronic board or components until the
power capacitors are discharged (Min.5 minutes).
Do not make any connection to inverter when the power is on. Do not check components
and the signs on the electronic boards while device is running.
Be sure that the mains connections are correct. L1, L2 and L3 are line input terminals and
must not be disordered U, V and W. Otherwise, device may be damaged.
Do not mount the brake resistor on controller cabinet. Brake resistor must be mounted
vertically outside the control cabinet.
Do not place device near flammable objects in order to prevent fire.
To prevent overheat, damage and fire be sure that the environment has sufficient
ventilation.
Do not store and operate the device at environments with extreme heat, extreme cold,
extreme humidity, water, iron dust and dust.
It is necessary that the used motor has a winding isolation which is made for the operation
with VVVF inverter.
