Operating Instructions for Your
HighGear by Cobra
2000 Watt Power Inverter
Nothing comes close to a Cobra
HG PI2000
TM
How Your HG PI2000 Power
Inverter Works
How Your Cobra Power Inverter Works
The Cobra Power Inverter is an electronic prod-
uct that has been designed and built to take low
voltage DC (Direct Current) power from your
automobile or other low voltage power supplies
and CONVERT it to standard 115 Volt AC
(Alternating Current) power like the current you
have in your home. This conversion process
thereby allows you to use many of your house-
hold appliances and electronic products in auto-
mobiles, RVs, boats, tractors, trucks and
virtually anywhere else.
A1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PI2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra PI2000

Summary of Contents for Cobra PI2000

  • Page 1 Operating Instructions for Your HighGear by Cobra 2000 Watt Power Inverter Nothing comes close to a Cobra How Your HG PI2000 Power Inverter Works How Your Cobra Power Inverter Works The Cobra Power Inverter is an electronic prod- uct that has been designed and built to take low...

  • Page 2: Features

    Current Meter AC Outlets Battery Cable Terminals Ground Terminal Thank you for purchasing the Cobra PI2000 inverter. Properly used, this Cobra product will give you many years of reliable service. Customer Support Should you encounter any problems with this product, or not understand its many features, please refer to this owner’s manual.

  • Page 3: Table Of Contents

    How to Use Your HG PI2000 Power Inverter Contents Features ........1 The Power Inverter Story.

  • Page 4: Introduction

    Introduction To make the most of this inverter, it must be installed and used properly. Please read the installation and operating instructions carefully before installing and using it. Special attention must be paid to the CAUTION and WARNING statements in the manual. CAUTION statements specify conditions which could cause damage to the unit or other equipment.

  • Page 5: Quick Checkout

    Quick Checkout Quick Quick Checkout Checkout This section provides you with basic information about the inverter and how to check its perfor- mance before installation. Be sure to have the fol- lowing on hand: • A 12 volt DC power source (such as a vehicle battery) •...
  • Page 6 Connection Connection 2. Connect both sets of cables to the power input terminals on right side panel of the inverter. continued The red terminals are positive (+) and the CAUTION: Loosely tightened black terminals are negative (-). Insert the bare connectors can cause exces- ends of the cables into the terminals and sive voltage drops and may...

  • Page 7: Installation

    Installation Installation Installation The inverter must be installed in an area that CAUTION: To avoid fire, do not meets all of the following requirements: cover or obstruct ventilation A. Dry- Do not place in an area where water can openings. Do not install invert- er in a zero-clearance com- drip or splash on the inverter.

  • Page 8: Ground Wiring

    Cables CAUTION: Electrical installa- If the cable has too much voltage drop, the tions must meet local and inverter may shut down when drawing higher national wiring codes, and currents because voltage at the inverter may should be performed by a drop below 10 volts.

  • Page 9: Dc Wiring

    DC Wiring DC Wiring DC Wiring 1. Be sure the ON/OFF switch on the inverter is CAUTION: Loosely tightened in the OFF position. connectors result in excessive voltage drop and may cause over heated wires and melted insulation. CAUTION: Reverse polarity connections (positive to nega- 2.

  • Page 10: Controls And Indicators

    Controls and Indicators Controls and ON/OFF Switch Indicators Turns the control circuit in the inverter On and Off. It does not disconnect power from the inverter. When the switch is in the Off position, the inverter draws no current from the battery.When it’s in the On position, but no power is being supplied to the load, the inverter draws less than 500 milliamperes from the battery.

  • Page 11: Troubleshooting Guide

    Troubleshooting Guide Trouble- Problem /Symptom Possible Causes Solution Low output voltage shooting on voltmeter Guide (96 VAC to 104 VAC) Low output voltage and current indicator in red zone No output voltage and voltage indicator in lower red zone No output voltage, no voltage indication No output voltage...

  • Page 12: Power Consumption

    Power Consumption For each piece of equipment you will be operat- ing from the inverter you must determine the battery’s capacity (how long the battery can deliver a specific amount of current—in automo- tive batteries, usually 25 amperes). For example, a battery with a reserve capacity of 180 minutes can deliver 25 amperes for 180 minutes before it is completely discharged.

  • Page 13: Warranty

    Limited Three Year Warranty COBRA ELECTRONICS CORPORATION warrants that its COBRA Power Inverter, and the component parts thereof, will be free of defects in material and workmanship for a period of 3 years from the date of consumer purchase. This warranty may be enforced by the first consumer purchaser, provided that the product is utilized within the U.S.A.

  • Page 14: If You Think You Need Service

    5. Ship prepaid and insured by way of a traceable carrier such as United Parcel Service (UPS) or First Class Mail to avoid loss in transit to: Cobra Factory Service, Cobra Electronics Corporation, 6500 W. Cortland St., Chicago, IL 60707.
