2500 WATT POWER INVERTER
CPI 2500
Nothing Comes Close To A Cobra
Operating Instructions
Printed in China
Part No. 480-060-P
English

Our Thanks To You

Introduction
Thank you for purchasing the Cobra
inverter. Properly used, this Cobra
will give you many years of reliable service.
How Your Cobra
®
Power Inverter Works
The Cobra
®
Power Inverter is an electronic product that
has been designed and built to take low voltage DC (Direct
Current) power from your automobile or other low voltage
power supplies and CONVERT it to standard 115 volt AC
(Alternating Current) power like the current you have in
your home. This conversion process thereby allows you
to use many of your household appliances and electronic
products in automobiles, RVs, boats, tractors, trucks and
virtually anywhere else.
Customer Assistance
Customer Assistance
Should you encounter any problems with this product,
or not understand its many features, please refer to this
owner's manual. If you require further assistance after
reading this manual, Cobra
®
following customer assistance services:
For Assistance In the U.S.A.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators English and Spanish.
8:00 a.m. to 6:00 p.m. CT, Monday through Friday
(except holidays) 773-889-3087 (phone).
Questions English and Spanish.
Faxes can be received at 773-622-2269 (fax).
Technical Assistance English only.
www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo
For Assistance Outside the U.S.A.
Contact Your Local Dealer
A1 English
®
CPI 2500
®
product
Electronics offers the
cobra.com (e-mail).
@
© 2003 Cobra
®
Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com

Advertisement

Table of Contents
loading

Summary of Contents for Cobra CPI-2500

  • Page 1: Our Thanks To You

    2500 WATT POWER INVERTER CPI 2500 Nothing Comes Close To A Cobra ™ Introduction Thank you for purchasing the Cobra inverter. Properly used, this Cobra will give you many years of reliable service. How Your Cobra Operating Instructions The Cobra has been designed and built to take low voltage DC (Direct Current) power from your automobile or other low voltage power supplies and CONVERT it to standard 115 volt AC...
