Lexmark W840 Quick Tips

Lexmark™ W840
Quick Tips
Loading paper or specialty
media
Loading the 500-sheet tray
1
Pull out the tray.
2
Squeeze the side guide tab, and slide the guide
to outside of the tray.
3
Squeeze the front guide tab, and then slide the
guide to the correct position for the paper you
are loading.
4
Flex the sheets back and forth to loosen them,
then fan them. Do not fold or crease the print
media. Straighten the edges on a level surface.
5
Load print media in the tray with the print side
up.
6
Squeeze the side guide tab, and slide the guide
until it lightly rests against the edge of the
media.
7
Insert the tray.

Loading the multipurpose feeder

1
Lower the multipurpose feeder.
2
Pull the tray extension out.
Note: Do not place objects on the
multipurpose feeder. Also, avoid
pressing down or applying
excessive force on it.
3
Slide the width guides to the outside of the
feeder.
4
Flex the sheets or envelopes back and forth to
loosen them, then fan them. Do not fold or
crease the print media. Straighten the edges on
a level surface.
5
Load the media in the feeder.
Note:
Make sure the print media is below
the max fill line. Overloading may
cause jams.
