Model Number
637A06
Performance
Sensitivity(± 10 %)
Measurement Range
Frequency Range(± 5 %) 600 to 24,000 cpm
Frequency Range(± 3 dB) 240 to 90,000 cpm
Filter Type
Electrical Filter Corner Frequency
Electrical Filter Roll-off
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(1 Hz)
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Spectral Noise(10 kHz)
Electrical Isolation
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector 2-Pin MIL-C-5015
Electrical Connection Position
[7]
[8]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
INDUSTRIAL ICP® ACCELEROMETER
EN GLISH SI
25 mV/g 2.54 mV/(m/s²)
± 200 g ± 1,962 m/s²
10 to 400 Hz
4 to 1,500 Hz
Low Pass Low Pass
1.5 kHz 1.5 kHz
12 dB/octave 12 dB/octave
≥ 1,200 kcpm ≥ 20 kHz
1 mg rms 0.01 m/s² rms
± 1 % ± 1 %
≤ 5 % ≤ 5 %
1,000 g pk 9,810 m/s² pk
-320 to +250 °F -196 to +121 °C
See Graph See Graph
≤ 3 sec ≤ 3 sec
0.05 to 0.5 sec 0.05 to 0.5 sec
18 to 28 VDC 18 to 28 VDC
1.6 to 20 mA 1.6 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
7 to 11 VDC 7 to 11 VDC
600 µg/√Hz 2
5,890 (µm/sec )/√Hz
120 µg/√Hz 2
1,180 (µm/sec )/√Hz
36 µg/√Hz 2
355 (µm/sec )/√Hz
25 µg/√Hz 2
250 (µm/sec )/√Hz
6 µg/√Hz 2
59 (µm/sec )/√Hz
8 8
≥ 10 Ohm ≥ 10 Ohm
7/8 in x 2.06 in 22 mm x 52.3 mm
3.3 oz 94 gm
1/4-28 Female 1/4-28 Female
2 to 5 ft-lb 2.7 to 6.8 Nm
Quartz Quartz
Shear Shear
Stainless Steel Stainless Steel
Hermetic Hermetic
2-Pin MIL-C-5015
Top Top
Optional versions have identical specifications and accessories as listed for the standard model except
[1]
where noted below. More than one option may be used.
[2]
- Hazardous Area Approval- contact factory for
EX
specific approvals
M - Metric Mount
Supplied Accessory: Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1) replaces Model 081A40
[3]
[3]
[4]
[3]
[3]
[3]
[3]
N OTES:
[5]
[1]Conversion Factor 1g = 9.81 m/s².
[2]1Hz = 60 cpm (cycles per minute).
[3]Typical.
[4]Zero-based, least-squares, straight line method.
[5]1/4-28 has no equivalent in S.I. units.
[6]
[6]Design hydro tested to 1450 psi [10,000 kPa].
[7]See PCB Declaration of Conformance PS023 for details.
[8]See Model's "Instructions For Use" (IFU) for North American Conformity and Certification
Statements.

SUPPLIED ACCESSORIES:

Model 081A40 Mounting Stud (1)
Model ICS-6 NIST traceable single axis amplitude response calibration from 10 Hz to upper +/- 3dB
point. (1)
