PCB Piezotronics IMI SENSORS 637A06 Installation And Operating Manual page 17

PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
A
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010

ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
2
SIGNAL/POWER
1.00 [25.4] HEX
2.12 [53.9]
1.37 [34.7]
.04 [1.1]
DIMENSIONS IN MILLIMETERS
KRM
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25

ANGLES 2 DEGREES
FILLETS AND RADII
0.07 - 0.13
2
REV
NR
GROUND

2X .99 [25.1]
DRAWN CHECKED
12/11/18 12/11/18
KRM
OUTLINE DRAWING
CASE ISOLATED
CRYOGENIC ACCELEROMETER
1
REVISIONS
DESCRIPTION
RELEASED TO DRAFTING
5/8-24 UNEF - 2A
ELECTRICAL CONNECTOR
2-PIN MIL-C-5015

1/4-28 UNF - 2B .20
 
.265 .020
[ ]

1/4-28 UNF - 2B 5.1
 
6.73 0.51
ENGINEER
12/11/18
RMB
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 1.5X
1
DIN
48898
B
A
62512
SHEET 1 OF 1
