Model Number
320C15
Performance
Sensitivity(± 10 %)
Measurement Range
Frequency Range(± 5 %)
Frequency Range(± 10 %)
Frequency Range(± 3 dB)
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range(Operating)
Temperature Response
Base Strain Sensitivity
Electrical
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Discharge Time Constant
Settling Time(within 10% of bias)
Spectral Noise(1 Hz)
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Physical
Sensing Element
Sensing Geometry
Housing Material
Sealing
Size (Hex x Height)
Weight
Electrical Connector
Electrical Connection Position
Mounting Thread
Mounting Torque
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® ACCELEROMETER
ENGLISH SI
10 mV/g 1.02 mV/(m/s²)
± 500 g pk ± 4900 m/s² pk
1.0 to 10,000 Hz 1.0 to 10,000 Hz
0.7 to 18,000 Hz 0.7 to 18,000 Hz
0.35 to 30,000 Hz 0.35 to 30,000 Hz
≥ 60 kHz ≥ 60 kHz
0.005 g rms 0.05 m/s² rms
≤ 1 % ≤ 1 %
≤ 5 % ≤ 5 %
± 10,000 g pk ± 98,100 m/s² pk
-100 to +325 ° F -73 to +163 ° C
See Graph See Graph
≤ 0.0005 g/µε ≤ 0.005 (m/s²)/µε
18 to 30 VDC 18 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 ohm ≤ 100 ohm
8 to 12 VDC 8 to 12 VDC
0.25 to 2.0 sec 0.25 to 2.0 sec
<5 sec <5 sec
2
2800 µg/√Hz
27,468 (µm/sec )/√Hz
2
700 µg/√Hz
6867 (µm/sec )/√Hz
2
180 µg/√Hz
1766 (µm/sec )/√Hz
2
64 µg/√Hz
628 (µm/sec )/√Hz
Quartz Quartz
Shear Shear
Titanium Titanium
Welded Hermetic Welded Hermetic
5/16 in x 0.43 in 5/16 in x 10.9 mm
0.07 oz 2.0 gm
5-44 Coaxial 5-44 Coaxial
Side Side
5-40 Male 5-40 Male
8 to 12 in-lb 90 to 135 N-cm
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
A
- Adhesive Mount
Supplied Accessory : Model 080A90 Quick Bonding Gel (1)
J
- Ground Isolated
[1]
[2] Frequency Range(± 5 %)
[3] Frequency Range(± 10 %)
Frequency Range(± 3 dB)
Resonant Frequency
Electrical Isolation(Base)
[1]
Size - Hex x Height
[1] Weight
M
- Metric Mount
Mounting Thread
Supplied Accessory : Model M080A15 Adhesive Mounting Base (1) replaces Model 080A15
W
- Water Resistant Cable
Electrical Connector
[1]
Electrical Connection Position
[1]
[1]
[1]
NOTES:
[1] Typical.
[2] Zero-based, least-squares, straight line method.
[3] Transverse sensitivity is typically ≤ 3%.
[1]
[4] See PCB Declaration of Conformance PS023 for details.

SUPPLIED ACCESSORIES:

Model 080A109 Petro Wax (1)
Model 080A15 Adhesive Mounting Base (1)
Model ACS-1 NIST traceable frequency response (10 Hz to upper 5% point). (1)
Entered: DMW Engineer: SDS
Date: 9/19/2011 Date: 9/19/2011
3425 Walden Avenue, Depew, NY 14043
Revision: G
ECN #: 36906
1.0 to 8000 Hz 1.0 to 8000 Hz
0.7 to 12,000 Hz 0.7 to 12,000 Hz
0.35 to 25,000 Hz 0.35 to 25,000 Hz
≥ 50 kHz ≥ 50 kHz
≥ 10 8 ≥ 10 8
ohm ohm
3/8 in x 0.38 in 3/8 in x 9.7 mm
0.11 oz 3.1 gm
M3x0.50 Male M3x0.50 Male
Sealed Integral Cable Sealed Integral Cable
Side Side
Sales: WDC Approved: BAM Spec Number:
Date: 9/19/2011 Date: 9/19/2011
Phone: 716-684-0001
Fax: 716-685-3886
E-Mail: vibration@pcb.com
9961
