Model Number
352A57
Performance
Sensitivity(± 10 %)
Measurement Range
Frequency Range(± 5 %)
Frequency Range(± 10 %)
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity(1000 g, 9800 m/s²)
Non-Linearity(2000 g, 19620 m/s²)
Transverse Sensitivity
TEDS Compliant(Per IEEE P1451.4)
Environmental
Overload Limit(Shock)
Temperature Range(Operating)
Temperature Response
Electrical
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Discharge Time Constant
Settling Time(within 10% of bias)
Spectral Noise(1 Hz)
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Physical
Size (Height x Length x Width)
Weight
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Mounting
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® ACCELEROMETER
ENGLISH
2.50 mV/g 0.255 mV/(m/s²)
± 2000 g pk ± 19,620 m/s² pk
0.5 to 10,000 Hz 0.5 to 10,000 Hz
0.3 to 15,000 Hz 0.3 to 15,000 Hz
≥ 45 kHz ≥ 45 kHz
0.001 g rms 0.01 m/s² rms
≤ 1 % ≤ 1 %
<2 % <2 %
≤ 5 % ≤ 5 %
Yes Yes
± 5000 g pk ± 49,050 m/s² pk
-65 to +250 °F -54 to +121 °C
See Graph See Graph
22 to 30 VDC 22 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 200 Ohm ≤ 200 Ohm
8.5 to 15.5 VDC 8.5 to 15.5 VDC
0.5 to 2.0 sec 0.5 to 2.0 sec
<5 sec <5 sec
500. µg/√Hz
4905 (µm/sec
50 µg/√Hz
491 (µm/sec
20 µg/√Hz
196 (µm/sec
15 µg/√Hz
147 (µm/sec
0.26 in x 0.57 in x 0.30 in 6.6 mm x 14.5 mm x 7.6 mm
0.047 oz 1.33 gm
Ceramic Ceramic
Shear Shear
Titanium Titanium
Hermetic Hermetic
5-44 Coaxial 5-44 Coaxial
Side Side
Adhesive Adhesive
SI
Optional versions have identical specifications and accessories as listed for the standard model
TLA
- TEDS LMS International - Free Format
[1]
TLB
- TEDS LMS International - Automotive Format
[2]
[2][1]
TLC
- TEDS LMS International - Aeronautical Format
[3]
TLD
- TEDS Capable of Digital Memory and Communication Compliant with IEEE 1451.4
[1]
NOTES:
2 [1]
[1]Typical.
)/√Hz
[2]Zero-based, least-squares, straight line method.
2 [1]
)/√Hz
[3]TEDS Capable Digital Memory and Communication, compliant with IEEE P1451.4
2 [1]
)/√Hz
[4]See PCB Declaration of Conformance PS023 for details.
[1]
2
)/√Hz
[1]

SUPPLIED ACCESSORIES:

Model 039A31 Removal Tool (1)
Model 080A109 Petro Wax (1)
Model ACS-1 NIST traceable frequency response (10 Hz to upper 5% point). (1)
