Edition: 18.12.2020
EN
Instruction manual for Full Body Harness
model V33 HEAT , certified according to EN 361
Thank you for choosing a VERTIQUAL® harness! You have purchased a high quality product that will reliably protect you and will be your companion for a long
time when working at heights and depths.
This manual must be read and understood before using the product! This product will be used with other equipment (components) thus forming a system for
working at heights. Please refer to the instruction manual of each component in your system for compatibility and correct use! Following these instructions ac-
cordingly is essential for your safety. Failure to do so can result in serious or even fatal accidents! Keep these instructions together with the product, accessible to
all users, so they can consult them whenever is needed!
WARNING!
These instructions are a basic comprehensive guide to the safe use of the purchased equipment. They contain general information about the product, intended to
help the user, but cannot cover all the situations that may occur in the daily activities and cannot in any case replace the specialized training courses for safety at
heights. This PPE against falls from heights can only be used by well-trained users, who are familiar with the relevant legislation and who have successfully
completed a special safety training course for working at heights.
WARNING!
For works with risk of falling from heights or in depths, a risk assessment must be carried out in advance in accordance with current regulations and legal provi-
sions (EN standards or specific national rules) that will provide adequate measures for safety and rescue!
WARNING!
Instructions for use are updated when technical or legislative changes occur. The latest version of the instructions overwrites previous versions and is the only
valid version. Please make sure you follow the instructions of the most recent version. You can download the most recent instructions from our website
www.ver-
tiqualsafety.com
by accessing the section of each product. For help or additional questions, please contact us at
office@vertiqualsafety.com
or Tel. (+40)
0365/882143.
Advertisement
Table of Contents
Related Manuals for Vertiqual Engineering V33 HEAT
Summary of Contents for Vertiqual Engineering V33 HEAT
- Page 1 Instruction manual for Full Body Harness model V33 HEAT , certified according to EN 361 Thank you for choosing a VERTIQUAL® harness! You have purchased a high quality product that will reliably protect you and will be your companion for a long time when working at heights and depths.
- Page 2 DESCRIPTION The V33 HEAT is made with 45 mm high tensile webbing that has a special composite structure of aramide fibers and flame-resistant polyester. The buckles and the anchor rings are made of high tensile steel. The Full Body Harnesses is comprised of shoulder straps, chest straps and leg straps. The dorsal attachment ring is located at the intersection of the webbings, between the shoulder blades.
- Page 3 Edition: 18.12.2020 3. Ensure there are no twisted straps then, one by one, close the chest, waist and legs buckles. 4. The chest buckle must be closed through the chest ring (check the images below). 5. Each leg strap will be passed between the legs, from back to front and the buckles will be closed with their corresponding counterpart. 6.
- Page 4 PPEaF. VERTIQUAL Engineering SRL herewith rejects any liability claims for direct, indirect, accidental or consequential damages resulting from the use of this PPEaF (Personal Protective Equipment against Fall). This product complies with the European PPE Regulation 425/2016 and the harmonized standard: EN 361:2002. Conformity assessment and production control is carried out by Eurpean Notified Body NB 2756 (INCDPM: Adress, 35 A, Ghencea Blv, Sector 6, Postal code: 061 692, Bucharest).
