Vertiqual Engineering VERTILINE PRO 215 Instruction Manual

Guided type fall arresters
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

EN
Instruction manual for guided type fall arresters type VERTILINE
VERTILINE
PRO 215
< 100 kg
VERTILINE
PRO HEAVY 213
Thank you for choosing VERTIQUAL®! You have purchased a high quality product that will reliably protect you and will be your companion for a
long time when working at heights and depths.
This manual must be read and understood before using the product! This product will be used with other equipment (components) thus forming a
system for working at heights. Please refer to the instruction manual of each component in your system for compatibility and correct use! Following
these instructions accordingly is essential for your safety. Failure to do so can result in serious or even fatal accidents! Keep these instructions
together with the product, accessible to all users, so they can consult them whenever is needed!
WARNING! These instructions are a basic comprehensive guide to the safe use of the purchased equipment. They contain general information
about the product, intended to help the user, but cannot cover all the situations that may occur in the daily activities and cannot in any case replace
the specialized training courses for safety at heights. This PPE against falls from heights can only be used by well-trained users, who are familiar
with the relevant legislation and who have successfully completed a special safety training course for working at heights.
WARNING! For works with risk of falling from heights or in depths, a risk assessment must be carried out in advance in accordance with current
regulations and legal provisions (EN standards or specific national rules) that will provide adequate measures for safety and rescue!
WARNING! Instructions for use are updated when technical or legislative changes occur. The lates version of the instructions overwrites previous
certified according to EN 353-2
VERTILINE
UNIVERSAL 216
< 100 kg
VERTILINE
UNIVERSAL HEAVY 214
VERTILINE
EDGE 217
VG11-CNB/P/11.075
< 100 kg
VERTILINE
EDGE ULTRA 219
VG11-CNB/P/11.075
1 / 8
Edition: 31.07.2024
VERTILINE
CLASSIC 220
< 100 kg
VERTILINE
CLASSIC HEAVY 218

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERTILINE PRO 215 and is the answer not in the manual?

Questions and answers

Related Manuals for Vertiqual Engineering VERTILINE PRO 215

Summary of Contents for Vertiqual Engineering VERTILINE PRO 215

  • Page 1 Edition: 31.07.2024 Instruction manual for guided type fall arresters type VERTILINE certified according to EN 353-2 VERTILINE VERTILINE VERTILINE VERTILINE PRO 215 UNIVERSAL 216 EDGE 217 CLASSIC 220 VG11-CNB/P/11.075 < 100 kg < 100 kg < 100 kg < 100 kg VERTILINE VERTILINE VERTILINE...

  • Page 2: Main Components

    Edition: 31.07.2024 versions and is the only valid version. Please make sure you follow the instructions of the most recent version. You can download the most recent instructions from our website www.vertiqualsafety.com by accessing the section of each product. For help or additional questions, please contact us office@vertiqualsafety.com or Tel.
  • Page 3 Vertiline PRO 215 and PRO HEAVY 213 Vertiline UNIVERSAL 216 and UNIVERSAL HEAVY 214 CONNECTING THE GUIDED TYPE FALL ARRESTER TO THE HARNESS Connect the carabiner of the ener-...

  • Page 4: Incorrect Use

    Edition: 31.07.2024 WARNING! Before use, the integrity and compatibility of the equipment must be checked! If the guided type fall arrester is equipped with SCREW locking carabiners, make sure these are completely closed and tightened. In case of self-locking carabiners make sure they are fully closed and locked properly before use.

  • Page 5: Check Before Each Use

    Edition: 31.07.2024 USE ON HORIZONTAL OR INCLINED SURFACES (edge tested fall arresters) Models VERTILINE EDGE 217 and VERTILINE EDGE ULTRA 219 have been sucessfully tested according to CNB/P/11.075 and are approved for use over edges (horizontal /inclined use). The allowed user weight (user + equipment) is: Max.
  • Page 6 Edition: 31.07.2024 Check the energy absorber! WARNING! DO NOT USE the equipment if the energy absorber had deployed or if any damage is identified! WARNING! This product is developped as a Personal Protective Equipment against Fall (PPEaF). Bringing modifications to it or asigning other uses are strictly forbidden! Each user shall use his own PPEaF as well as his own rescue equipment.
  • Page 7 If the user is unable to do so or if he does not have the competence to do so, he cannot use this PPEaF. VERTIQUAL Engineering SRL herewith rejects any liability claims for direct, indirect, accidental or consequential damages resulting from the use of this PPEaF (Personal Protective Equipment against Fall).

  • Page 8: Product Details

    UTILISATION / PRIMER INSPECCIÓN Inspection Signature of Next inspection passed Inspection date Results of the inspection: due latest: dd / mm / yyyy inspector: dd/mm/yy Manufacturer: Vertiqual Engineering S.R.L. RO-547367 Corunca, St. Calea Sighisoarei, No. 110 www.vertiqualsafety.com 8 / 8...

This manual is also suitable for:

Vertiline universal 216Vertiline edge 217Vertiline classic 220Vertiline pro heavy 213Vertiline universal heavy 214Vertiline edge ultra 219 ... Show all
