- Page 1 Indigo DT and Indigo DTSE Desk top boxes Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England. Tel: +44(0) 1223 497049 Fax: +44(0) 1223 497059 sales@crystalvision.tv www.crystalvision.tv...
-
Page 2: Table Of Contents
Object Identifiers (OID) Traps Filters Controlling cards via Ethernet Alternative method to access Network Setup Installing Crystal Vision modules Module positions Inserting modules Removing modules Rear connectors Fitting rear connectors Select the cooling mode Indigo DT User Manual R1.8 05 July 2018... - Page 3 Added Appendix 2 for frame software before v4.6. 23/10/13 Removed DTAE. Revision 8 Added note about new security introduced with 05/07/18 frame software version V5.9 build 16216 to beginning of page 12. Indigo DT User Manual R1.8 05 July 2018...
-
Page 4: Introduction
(EMC) requirements in this condition. The Indigo DT and Indigo DTSE have front panel processors. These processors monitor the power rail voltage levels (+5.5V and -6.0V) and the fan speed. Status information is indicated by the state of the FAN, PSU and TEMP LEDs on the front panel and the alarm relay. - Page 5 Note : Serial RS422 control from Statesman or third party applications is no longer supported. All connections should be made via Ethernet. Crystal Vision AE and SE frames running v4.6 software or later support Statesman, ASCII and HTTP/JSON control protocols. An optional SNMP licence can be purchased to enable control and monitoring via SNMP.
-
Page 6: Installation
Do not operate this unit for extended periods with the front panel open. Do not use the frame unless all the rear connector positions are filled, either with Crystal Vision rear modules, or with Crystal Vision blanking plates. Do not operate the equipment with covers or panels removed. -
Page 7: Rack Mounting And Ventilation
If the optional rack ears are fitted, and the unit is installed in a standard 19" rack, cool air circulation should be available and both side ventilation grilles should be unobstructed. Indigo DT airflow Install the Indigo DT in a standard 19" rack as follows: • Fit the optional rack ears •... -
Page 8: Frame Connectors
Replace the fuse only with one of the same type and rating. Refer to the maintenance section of the trouble shooting guide for more information. Indigo DT User Manual R1.8 05 July 2018... -
Page 9: Connector Pinout
These connections are referred to as lines 'a' to 'f'. The functions assigned to them are dependent on the module inserted in each slot, but a typical use is as a GPI line. Refer to the documentation supplied with each Crystal Vision module to determine the actual functions assigned. -
Page 10: Rj45 422 I/O (Statesman/Link Bus) Connector
Should this LED not be lit check the cable connection between the frame and network outlet. The data LED flashing will indicate that communications between the frame and the network exists. Indigo DT User Manual R1.8 05 July 2018... - Page 11 Although it is possible to operate the frame with the front panel open, the frame Warning: may not meet electromagnetic compatibility (EMC) requirements in this condition. Indigo DT User Manual R1.8 05 July 2018...
- Page 12 ‘Lower’ position. 422 Term This switch was used to terminate the RS422 chain of older pre-Ethernet enabled frames and is no longer supported by Crystal Vision. Frame Address This switch must be left in position 0. Indigo DT User Manual R1.8...
-
Page 13: Control
Ethernet control is provided by the Indigo DTSE frame. This allows the Statesman PC control system or remote active control panels to control a large number of the Indigo Ethernet series frames over a local area network. Statesman control of Indigo frames over Ethernet Indigo DT User Manual R1.8 05 July 2018... -
Page 14: Setting Up And Connecting
Set the PC’s Local Area Connection (LAN) controller’s sub-mask to 255.255.255.0 and the IP address within the same IP group i.e. 10.0.0.250. For Windows 7 users this is most easily accessed from the Network and Sharing Centre: Indigo DT User Manual R1.8 05 July 2018... - Page 15 LAN controller’s IP address. In this case setting an additional IP address could save time if a large number of frames are to be configured. Additional IP addresses can be added via the ‘Advanced’ tab in Windows 7: Indigo DT User Manual R1.8 05 July 2018...
-
Page 16: Indigo Home Page
This page will give status information about the frame, its power supplies and means to access each card’s controls. *Recommended web browsers include IE10, Google Chrome and Mozilla Firefox. Indigo DT User Manual R1.8 05 July 2018... -
Page 17: Indigo Setup Pages
Indigo Setup home page About From the Setup home page, clicking on the ‘About’ link will open a web page that shows, amongst other things, the frame’s software version number and build: Indigo DT User Manual R1.8 05 July 2018... -
Page 18: Network Setup
Indigo ‘About’ page The above example shows that the frame is equipped with IndigoSNMP software version 4.6, build version 9259. Crystal Vision may ask you to provide this information if there is a problem. Note that only frames fitted with IndigoSNMP software are capable of supporting an SNMP interface. -
Page 19: Hardware Setup
Control Indigo ‘Network Setup’ page Hardware Setup Indigo ‘Hardware Setup’ page From the Setup home page, clicking on the ‘Hardware Setup’ link will bring up a page containing information about the frame: Indigo DT User Manual R1.8 05 July 2018... -
Page 20: Software Upgrade
Indigoxxx.Settings. Each of the files is selected in turn and the upgrade performed on each before re-booting the frame. Do not attempt to do this without specific instruction from Crystal Vision or its representatives. Indigo ‘Software Upgrade’ page Indigo DT User Manual R1.8... -
Page 21: Diagnostics
Crystal Vision Control Diagnostics The ‘Diagnostics’ link opens a page which will help Crystal Vision diagnose any faults encountered with your system. Crystal Vision may ask you to supply this information by copying and pasting part or all of the data: Indigo ‘Diagnostics’... -
Page 22: Management Information Base (Mib)
PSUs that are to be monitored have an associated MIB. Each MIB is a collection of object identifiers that identify all variables that can be read via SNMP and these MIBs are available from Crystal Vision. Use a MIB Browser to view all status and control possibilities. -
Page 23: Traps
– for example,removing an input may typically trigger eight traps. It will then be down to the SNMP manager to sort these into a hierarchical order or mask as necessary. Indigo DT User Manual R1.8 05 July 2018... -
Page 24: Filters
OIDs that will generate traps if a card is found or lost: Unless previously edited, the SNMP configuration window will show an example of enabling the trap filter using the events shown above: Indigo DT User Manual R1.8 05 July 2018... -
Page 25: Controlling Cards Via Ethernet
Extract from SNMP configuration window showing example of trap filtering 3.3 Controlling cards via Ethernet Crystal Vision cards fall into two categories. The first (newer) type uses an XML file to create a control database that is used by the card’s front-edge controller, Statesman, the Indigo frame front panel controller and the Indigo web page interface. -
Page 26: Alternative Method To Access Network Setup
(10.0.0.201 as default or if you’ve switched S2 on the upper PCB to the left) followed by port address 7780 i.e. 10.0.0.201:7780. This will bring up the older style web page: Indigo Setup home page accessed via port 7780 Indigo DT User Manual R1.8 05 July 2018... -
Page 27: Installing Crystal Vision Modules
Installing Crystal Vision modules 4 Installing Crystal Vision modules The Indigo desk top boxes each have two slots for Crystal Vision video or audio cards. Signal connections are made through single or double rear modules. An optional rack mount kit IDT-RK allows the 1U Indigo desk top box to be mounted into a 19"... -
Page 28: Rear Connectors
• Refit an EMC cover if required and replace the retaining screws. The Indigo DT with one EMC cover and an RM01 connector fitted to slot 1 To maintain product safety and EMC compliance the rear of the frame Warning: should be filled with Crystal Vision rear connectors and/or EMC covers and held in place with retaining screws before power is reapplied. - Page 29 Crystal Vision Installing Crystal Vision modules Indigo DT front panel hardware settings – cooling mode The three modes are normal, quiet and maximum cooling. The two-position DIL switch controls the three cooling modes as follows: Piano Switches Switches 1 and 2 configure the cooling fan modes.
-
Page 30: Trouble Shooting
Refer all servicing to qualified service personnel. Refer also to the general safely summary in the installation chapter. Indigo DT User Manual R1.8 05 July 2018... -
Page 31: Replacing The Mains Input Fuses
Replace the fuse only with one of the same type and rating (5A, 250V time Note: delay). Software upgrades Software upgrades for the Indigo DTSE front panel are done via the Ethernet connection. See the Indigo active front panel manual for information concerning remote software uploading. Indigo DT User Manual R1.8 05 July 2018... -
Page 32: Frequently Asked Questions
It will flash brightly when the communication link is active Why doesn't the switch on the front panel that sets the slot address work? Changing this switch only takes effect the next time the front panel is powered up Indigo DT User Manual R1.8 05 July 2018... -
Page 33: Specification
(rear connection by way of 26-pin high density D-Type connector and RJ45 connector) Second serial port available via 26-pin high density D-Type connector and RJ45 connector Ethernet control capable SNMP control and monitoring option. Indigo DT User Manual R1.8 05 July 2018... -
Page 34: Appendix
1.15 PSU in 1U frames 1.14 Most Crystal Vision cards have their unique node or card location address assigned automatically by the panel processor based on the slot occupied in the frame and the Upper/Lower range address setting. Older cards may have a special 16-position node switch for use with older frames such as the FR2-12 or FR1-6. -
Page 35: Indigo Frame Software Prior To V4.6
This page will give a large amount of status information about the frame and its power supplies. From the web page several options are available such as changing the IP address and frame naming. Indigo DT User Manual R1.8 05 July 2018... -
Page 36: Status
Care must be taken not to bend any pins in the cable connect as attempting to re-straighten any bent pins is likely to result in their fracture. Indigo DT User Manual R1.8 05 July 2018... -
Page 37: Adding A Frame Serial Number
Once the desired serial number has been entered press the Store button to save it to memory. Should the chosen serial number contain an error or be out of range an error dialogue box will be displayed. Indigo DT User Manual R1.8 05 July 2018... -
Page 38: Naming
A hostname (occasionally also known as a sitename) is the unique name by which a network-attached device (which could consist of a computer, file server, network storage device, fax machine, copier, cable modem, etc.) is known on a network. Indigo DT User Manual R1.8 05 July 2018... -
Page 39: Reset
The SNMP window provides a list of these config files. An in-depth explanation can be found by following the link from the SNMP window. Indigo DT User Manual R1.8 05 July 2018... -
Page 40: Snmp Agent
MIB. Each MIB is a collection of object identifiers that identify all variables that can be read via SNMP. The following diagram gives an overview of the OID sequences within the MIB tree. Indigo DT User Manual R1.8 05 July 2018... - Page 41 PSU Status 4 OK/problem/unknown OK/problem/unknown Frame Temperature Frame temperature OK/too Expected but not PSU not fitted or not Alarm 1 high/unknown fitted PSU powered Frame Temperature Frame temperature OK/too Alarm 2 high/unknown Indigo DT User Manual R1.8 05 July 2018...
-
Page 42: Downloading Licences
The Indigo DTSE is pre-installed with an SNMP manager which will require a licence to be downloaded and installed. The licence is available by email from Crystal Vision’s customer support. To obtain a licence the frame’s MAC address will be required. -
Page 43: Snmp Quick Start Guide
PCB connector become bent or misaligned. 8.2 SNMP Quick Start Guide Introduction This should provide the information you need to set up and check a Crystal Vision frame for operation with an SNMP manager. Frame Setup The frame must have a licence for SNMP operation for it to respond properly to SNMP requests. - Page 44 Check that the ‘Licenses’ section shows “Found a License for SNMP”. If no licence is found contact Crystal Vision to get an SNMP licence for this frame. Once the frame is licensed for SNMP you will need to set the address to which you want it to send unprompted SNMP messages (traps).
- Page 45 SNMP licence. The frame will report the presence of the licence even if it has not been activated by a reset. The same walk of an unlicensed frame gives the results below. Indigo DT User Manual R1.8 05 July 2018...
- Page 46 The frame should now be set up to respond to SNMP requests and send traps to the desired IP address. Sending traps to multiple addresses To send traps to multiple addresses, define multiple trapsinks in the config file. Indigo DT User Manual R1.8 05 July 2018...
- Page 47 Crystal Vision Appendix 2 Indigo DT User Manual R1.8 05 July 2018...
