- Page 1 TANDEM HD-20 HD/SD audio embedder/de-embedder Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England. E-mail: sales@crystalvision.tv Website: www.crystalvision.tv Tel: +44(0) 1223 497049 Fax: +44(0) 1223 497059...
-
Page 2: Table Of Contents
Crystal Vision TANDEM HD-20 User Manual R1.4 Contents 1 Introduction 2 Hardware installation 2.1 Module configuration 2.2 Sub-module link settings 2.3 Rear modules and signal I/O RM33 rear module connections RM39 rear module connections 2.4 General Purpose Interface (GPI) 3 Card edge operation 3.1 Card edge controls... - Page 3 Crystal Vision TANDEM HD-20 User Manual R1.4 Updating the display 4.2 The TANDEM HD-20 active panel menu structure Card edge status Audio menu Preset menu Miscellaneous menu Factory Reset 5 Statesman 5.1 Statesman operation Status De-embed and Embed Audio routing and Delay...
-
Page 4: Introduction
Introduction 1 Introduction The TANDEM HD-20 is a High Definition video 24-bit two group audio analogue or digital embedder/de-embedder. It can be configured with two sub-PCB option cards to provide any of a number of possible functions at once, such as: •... - Page 5 Functions include audio shuffling, video delay, gain compensation and audio replace. The are two positions available on the TANDEM HD-20 for fitting optional sub-PCBs. The rear position 1 is associated with inputs 9-12 and outputs 1-4. The front position 2 with inputs 13-16 and outputs 5-8.
-
Page 6: Hardware Installation
The TANDEM HD-20 single slot module uses the single height RM33 and dual height RM39 rear connectors that will fit into all Crystal Vision rack frames. All modules can be plugged in and removed while the frame is powered without damage. -
Page 7: Sub-Module Link Settings
Set channel 1 with PL2/RV2, channel 2 with PL1/RV1, channel 3 with PL4/RV4 and channel 4 with PL3/RV3. Take care to note the adjustment and channel numbering on this sub-board. HD-AIP2 TANDEM HD-20 User Manual R1.4 24/05/2007... - Page 8 HD-DOP2-110 TANDEM HD-20 does not support an external reference. JL2 will normally be left in its upper position so giving the second AES2 output. JL3 and JL4 have no function.
- Page 9 48kHz inputs, and other sample rate inputs such as 44.1kHz and 96kHz. The signal output from the HD-DIP2-RS to the TANDEM HD-20 is at 48kHz derived from the video content of the SDI signal into which it is to be embedded.
-
Page 10: Rear Modules And Signal I/O
V bit is set or held high. Link jumpers are provided to select between 110 Ohm (upper two pins), HiZ (balanced – centre pins only) or 75 Ohm (unbalanced – lower two pins). For TANDEM HD-20 jumper JL3 must be in the 24-bit (TAD) position. - Page 11 Input 14 (Front 2) AES4+ AES4+ Input 15 (Front 3) Input 15-16 Input 15-16 AES4- AES4- (Front 3-4) (Front 3-4) AES4scrn AES4scrn Input 16 (Front 4) 19, 20, 23, 24 21, 22, 25, 26 TANDEM HD-20 User Manual R1.4 24/05/2007...
- Page 12 (H2) (duplicate) (duplicate) AES3b- AES4a+ AES4a Input 15 Output 7-8 Output 7-8 (H3) AES4a- AES4b+ AES4b Output 1-2 Output 7-8 Output 7-8 (duplicate) (duplicate) (duplicate) AES4b- 19, 20, 23, 24 21, 22, 25, 26 TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 13: Rm39 Rear Module Connections
RM39 rear module connections The RM39 dual height rear module is designed for 75 Ohm unbalanced AES operation. As this is a dual height module two frame slots are required with the TANDEM HD-20 fitted in the top slot position. -
Page 14: General Purpose Interface (Gpi)
Each General Purpose Input (GPI) is fitted with a 6800Ω resistor connected to the internal +5V. The 16 user preset configurations can be recalled using binary notation. Bit 4 Bit 3 Bit 2 Bit 1 Preset TANDEM HD-20 User Manual R1.4 24/05/2007... - Page 15 6 in each case and +5V @500mA is pin 15 on Remote 2 and Remote 6. Note. The +5V output is protected by self-resetting thermal fuses, which limit the total output current available from Remotes 1-4 to approximately 1A. Remotes 5-8 are similarly protected. TANDEM HD-20 User Manual R1.4 24/05/2007...
- Page 16 Remote 2: 26-way high-density D-Type male plugs and frame ground is pin 6 and +5V @500mA is pin 15. Note. The +5V output is protected by self-resetting thermal fuses, which limit the total output current available from Remotes 1-2 to approximately 1A. TANDEM HD-20 User Manual R1.4 24/05/2007...
- Page 17 Remote 2: 26-way high-density D-Type male plugs and frame ground is pin 6 and +5V @500mA is pin 15 Note. The +5V output is protected by self-resetting thermal fuses, which limit the total output current available from Remotes 1-2 to approximately 1A. TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 18: Card Edge Operation
Rotate SCROLL to identify a menu category. In combination with the ENTER button SCROLL select and ADJUST to change the current level or select a further option. /ADJUST The rotary control can access menus and parameter values by clockwise or anti-clockwise Notes: rotation. TANDEM HD-20 User Manual R1.4 24/05/2007... -
Page 19: Reading Card Edge Leds
Push ENTER to action the change. The display will cease flashing • Use the up-arrow [ ] and SCROLL control to navigate to further menus Note. The displayed menu brightness will flash slowly if confirmation of a change is required. TANDEM HD-20 User Manual R1.4 24/05/2007... -
Page 20: Card Edge Configuration
Card edge operation 3.6 Card edge configuration Menu Tree Tip. To reach the top menu push the button repeatedly until a top menu is reached. Rotate the SCROLL control anti-clockwise until the STATUS menu appears. TANDEM HD-20 User Manual R1.4 24/05/2007... -
Page 21: Card Edge Status
Dip, DipR, Aip, Aop, Dop7, Dop1, None. Software The version number of the currently installed software. version fitted PCB serial The electronically stored PCB serial number. This should correspond number with the serial number label affixed to the PCB connector. TANDEM HD-20 User Manual R1.4 24/05/2007... -
Page 22: Audio Menu
The monitoring outputs for the board edge headphone socket are headphone selected in stereo pairs. routing A12, A34, B12, B34, R12, R34, F12, F34, C12, C34, D12 & D34 Note: If output sub-PCBs are fitted B-F will copy C-D. Audio routing sub menu TANDEM HD-20 User Manual R1.4 24/05/2007... - Page 23 Card edge operation 16x8 routing matrix At the heart of TANDEM HD-20 is the sixteen input, eight output routing matrix. This will allow any of the sixteen possible inputs, eight embedded channels and up to eight analogue or digital audio inputs to be routed to any of the eight outputs for embedding or to be outputted via output sub-PCBs.
-
Page 24: Preset Menu
The alarm menu allows the user to customise the alarm reporting from the TANDEM HD-20 to suit their individual needs. TANDEM HD-20 has two alarm outputs, GPO5 and GPO6. These GPI outputs in their non-alarm condition are held to the internal +5V via a 6800Ohm resistor. -
Page 25: Miscellaneous Menu (Factory Reset)
Miscellaneous menu (Factory Reset) At present, the only control available in the miscellaneous menu is the Factory Reset. This control can be used to return the TANDEM HD-20 to its default condition. Note the default conditions will be dependent on any sub-PCBs fitted. - Page 26 Audio Delay Unity Audio Gains Unchanged, contents of all saved presets are erased Selected Preset Unchanged GPI controls preset recall C1 and C2 Headphone monitoring Unchecked GPO5 and GPO6 Zero delay Silence Alarm delay TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 27: Using The Front Control Panel
At power up, the two line 20-character screen will display ‘Crystal Vision’ followed by the firmware version number for the control panel. All eight control panel keys LEDs will illuminate. - Page 28 Upward arrow – used to move up the menu structure / enter lock panel menu from the Device menu • Rotary control – shaft encoder used to select options or variable data Please refer to the Crystal Vision Control Panel manual for details of the Panel Setup, Lock Panel and Note: Diagnostic menus. Selecting TANDEM HD-20 To select a particular card in a frame, press the DEVICE key to go to the Device menu.
-
Page 29: Updating The Display
Active function keys are indicated by illuminated, integrated LEDs. The main top-level menus for the TANDEM HD-20 are obtained by pressing the F1- F4 keys from the HOME menu. Menu keys are illuminated when active and when further menus are available. - Page 30 Crystal Vision Using the front control panel TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 31: Card Edge Status
Type of sub PCB fitted in the rear position. type HD-Dip, HD-DipR, HD-Aip, HD-Aop, HD-Dop7, HD-Dop1, None PCB serial The electronically stored PCB serial number. This should correspond number with the serial number label affixed to the PCB connector. TANDEM HD-20 User Manual R1.4 24/05/2007... -
Page 32: Audio Menu
Note embedders C and D cannot be made to embed to the same output group. Audio Routing At the heart of TANDEM HD-20 is the sixteen input, eight output routing matrix. This will allow any of the sixteen possible inputs, eight embedded channels and up to eight analogue or digital audio inputs to be routed to any of the eight outputs for embedding or to be outputted via output sub-PCBs. - Page 33 The action of selecting will cause that channel to output the mono sum of itself and its associated channel. The associated channel output will still output its unaltered programme. Either channel of a pair can be selected for stereo to mono conversion. TANDEM HD-20 User Manual R1.4 24/05/2007...
- Page 34 This allows the user a certain amount of adjustment to compensate for variations between channels. Menu Comment Output channel Press F3 to enter the Gain menu. SCROLL to select output gains channel gain. Press F1 to select and SCROLL to adjust Outputs 1-8. TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 35: Preset Menu
Notes: Odd channel numbers will appear in the left headphone with the corresponding even channels appearing in the right. F (front) and R (rear) indicate a sub-PCB and its location when fitted to the TANDEM HD-20 motherboard. Menu... -
Page 36: Miscellaneous Menu
Using the front control panel Miscellaneous menu This menu allows the user to customise the alarm reporting from the TANDEM HD-20 to suit their individual needs. TANDEM HD-20 has two alarm outputs, GPO5 and GPO6. These GPI outputs in their non-alarm condition are held to the internal +5V via a 6800Ohm resistor. An alarm condition will force the GPI output to less than 0.5V through a series 270Ohm resistor. -
Page 37: Factory Reset
Using the front control panel Factory Reset The factory reset can be used to return the TANDEM HD-20 to it default condition. It should be noted that if a factory reset is carried out the final routing will depend on any sub-PCBs fitted and all preset configurations will be erased. - Page 38 Audio Delay Unity Audio Gains Unchanged, contents of all saved presets are erased Selected Preset Unchanged GPI controls preset recall C1 and C2 Headphone monitoring Unchecked GPO5 and GPO6 Zero delay Silence Alarm delay TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 39: Statesman
Statesman 5 Statesman The Crystal Vision Statesman PC control software is designed to control a range of Crystal Vision modules via serial control from a PC. Statesman provides a user friendly means of configuring and operating the TANDEM HD-20 with the benefit of see-at-a-glance status monitoring. -
Page 40: Status
Alarm configurations. Status The Status menu pane is made up of four sub sections that have been reproduced from the other menus to give a general overview of TANDEM HD-20’s configuration and signal monitoring. TANDEM HD-20 Statesman Status menu... -
Page 41: Embed And Embed
The input video standard is also given along with the type of sub-PCB if fitted in both the forward and rear positions. De-embed and Embed The De-embed and Embed menu is where TANDEM HD-20’s two de-embedders and two embedders are configured. TANDEM HD-20 Statesman De-embedder and Embedder menu Audio Groups In Here the input groups for the A and B de-embedders are selected. -
Page 42: Audio Routing And Delay
TANDEM HD-20 Statesman Audio routing and Delay menu 16x8 routing matrix At the heart of TANDEM HD-20 is the 16 input, 8 output routing matrix. This will allow any of the sixteen possible inputs, eight embedded channels and up to eight analogue or digital audio inputs to be routed to any of the eight outputs for embedding or to be outputted via output sub-PCBs. - Page 43 The delay is applied at the output of the 16x8 router and is a single global control. To add a delay to any channels tick the adjacent check box. TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 44: Audio Gain
The gain of the eight audio output channels feeding the SDI output stream embedders can be varied from unity gain by ±3.0dB. TANDEM HD-20 Statesman Audio Gain menu To adjust a channel gain click on the appropriate slider and drag it up or down whilst holding the left mouse button down. -
Page 45: Presets And Headphones
The Presets and Headphones tab gives access to the Preset save/recall and headphone monitor routing. TANDEM HD-20 Statesman Presets and Headphones menu Using Presets Up to sixteen setups may be stored and recalled from Statesman, the card edge control or by external GPIs. -
Page 46: Alarms
Notes: Odd channel numbers will appear in the left headphone with the corresponding even channel appearing in the right. F (front) and R (rear) indicate a sub-PCB and its location when fitted to the TANDEM HD-20 motherboard. Alarms The Alarms menu gives access to the GPO assignment, Silence alarm delay and Factory Reset. - Page 47 Factory Reset The factory reset can be used to return the TANDEM HD-20 to it default condition. It should be noted that if a factory reset is carried out the final routing will depend on any sub-PCBs fitted and all preset configurations will be erased.
- Page 48 Audio Delay Unity Audio Gains Unchanged, contents of all saved presets are erased Selected Preset Unchanged GPI controls preset recall C1 and C2 Headphone monitoring Unchecked GPO5 and GPO6 Zero delay Silence Alarm delay TANDEM HD-20 User Manual R1.4 24/05/2007...
-
Page 49: Trouble Shooting
Simple trouble shooting can be performed by using either the card edge or a remote status panel display. Card edge monitoring TANDEM HD-20’s card edge LEDs will give a quick overview of current status. Name Function when ON Function when Off... - Page 50 Check that the downstream equipment is properly referenced to the system audio reference The digital audio is not timed with the video (lip sync error) TANDEM HD-20 can make some adjustment to the timing of the audio to the incoming video. See audio delay for details...
-
Page 51: Specification
Typically SDI 0.2UI @ 1kHz, HD 0.2UI @ 100kHz Audio SD embedded to SMPTE 272M HD embedded to SMPTE 299M Analogue or AES dependent on sub-modules fitted Inter-channel: <1 clock cycle Embed/de-embed timing Audio to video: SD approx. 800us, HD approx. 90us TANDEM HD-20 User Manual R1.4 24/05/2007... - Page 52 -99dBu / -117 dBFS (+18dBu) rms., 22Hz to 22kHz typ. Signal to noise Total harmonic distortion 0.004% THD+N rms. 22Hz to 22kHz typ. Interchannel crosstalk -110 dB @ 1kHz, -90 dB @ 20 kHz, rms. typ. TANDEM HD-20 User Manual R1.4 24/05/2007...
- Page 53 2 x 24 bit AES/EBU stereo pairs. HD-DOP2-110, 110 Ohm or HD-DOP2- Audio output 75 (unbalanced) 75 Ohm BNC. Factory configuration only Each of the two AES signal outputs has a second buffered output, which may be available dependant on the RM module fitted. TANDEM HD-20 User Manual R1.4 24/05/2007...
