44 Apple Street, Tinton Falls, NJ 07724
Phone: 732-212-4700 Fax: 952-906-3706
Read all instructions before installation or
operation of equipment. Failure to comply
with these instructions could result in
bodily injury or property damage.
Eaton Filtration, LLC
e-mail: filtration@eaton.com
Web: www.eaton.com/filtration
Table of Contents
Introduction .............................................
Receiving, Handling & Inspection .................
Storage .................................................
Installation ...............................................
Start-Up .................................................
Operation ...............................................
Normal Shut-Down ...................................
Emergency Shut-Down ..............................
Maintenance ..............................................
Internal ...................................................
Reducer ..................................................
Manual Operation of the Backwash Arm ........
Disassembly and Parts Replacement ...........
Seals Replacement.....................................
Lower Bushing Replacement ......................
Upper Shaft Seal Removal...........................
Upper Shaft Seal Replacement ....................
Motor Replacement ....................................
Speed Reducer Replacement .......................
Trouble Shooting ......................................
Drawings ................................................
Backwash ................................................
Assembly .................................................
Recommended Spare Parts .........................
Introduction
A self-cleaning strainer is a device installed in a pipe-
line to remove dirt and other unwanted debris from
fluids. Straining is accomplished by directing the fluid
through "sized" openings in perforated straining ele-
ments. Self-cleaning strainers have integral back-
wash systems designed to isolate and clean a small
portion of the element while the remaining area contin-
ues to strain normally. During operation, fluid flow
through the strainer is continuous. A small quantity of
"clean" fluid is used to wash the element and then
carry the concentrated debris away from the strainer
through the backwash system.
1
Installation, Operation &
Service Manual
Model 2596
Self-Cleaning Strainer
2" to 8"
Page No.
IOM 2596 2-8 Rev 0
1
2
2
3
4
4
4
4
5
5
5
5
5
5
6
6
7
7
8
8
9
10
10
11
11
Advertisement
Table of Contents
Related Manuals for Eaton 2596
Summary of Contents for Eaton 2596
-
Page 1: Table Of Contents
During operation, fluid flow through the strainer is continuous. A small quantity of "clean" fluid is used to wash the element and then carry the concentrated debris away from the strainer through the backwash system. IOM 2596 2-8 Rev 0... -
Page 2: Receiving, Handling & Inspection
Introduction, Continued Storage Self-cleaning strainers are installed where continuous removal of debris from the process fluid is required and Store strainers indoors in a clean, dry environment where fluid flow cannot be interrupted for cleaning the whenever possible. straining elements. These strainers are used where manual cleaning is not convenient or practicable for Replace all protective wrappings, flange protectors, reasons such as: the need for frequent cleaning, possi-... -
Page 3: Installation
Installation For all applications, a manually operated pinch valve Position the strainer in the line so that the fluid enters (supplied by others) to throttle backwash flow may be the connection marked inlet. installed downstream of the backwash valve. ‘Suggested Backwash Line Installation’, Figure 3. CAUTION: Lift strainer with slings under the inlet line nozzles and through the reducer mount. -
Page 4: Start-Up
Start-Up Start-Up...Continued Check the reducer for lubricant. Reducers are If the differential pressure exceeds 10 psid: shipped filled with oil. Before operating, the breather plug must be installed in the top of the reducer (should Check strainer to verify rotation of the backwash arm. be placed in the uppermost side). -
Page 5: Maintenance
Maintenance—Internals Manual Operation of the Backwash Arm .The Strainer is furnished with a drive pin that when removed allows manual operation. At scheduled intervals, the strainer cover should be removed for internal inspection (refer to “Normal De-energize the power supply to the strainer motor. Shut-Down”... -
Page 6: Seals Replacement
Removal of Cover and Operating Mechanism Body O-Ring, Inner and Outer Internal Seals Assembly...Continued Replacement Disconnect electrical connections to the motor. First, complete “Normal Shut Down” procedure. Match mark the body girth flange with the cover girth Disconnect power to the strainer motor, and discon- flange. -
Page 7: Upper Shaft Seal Removal
Upper Shaft Seal Replacement Upper Shaft Seal Removal Refer to Figure 1. First, complete “Normal Shut Down” procedure. Slide Gland Gasket (F) down the backwash arm/shaft Disconnect power to the strainer motor and discon- to the Packing Block (machined area around the top nect the motor leads. -
Page 8: Motor Replacement
Motor Replacement Speed Reducer Replacement..Continued First, complete “Normal Shut Down” procedure. Make note of the relative position of the shaft and the reducer top. Remove the drive pin from the top of the Disconnect power source and remove fuses in the backwash arm/shaft. -
Page 9: Trouble Shooting
Trouble Shooting Trouble Shooting, Continued Backwash Arm not rotating, Motor and/or reducer High Differential Pressure due to high solids failure: loading in process fluid: Incorrect voltage applied to strainer motor. Increase length of backwash cycle or backwash continuously Overload heaters in motor starter improperly sized. Backwash Arm not rotating, Motor overloads Lubricant level in reducer too low, reducer vent tripped:... -
Page 10: Drawings
Suggested Backwash Line Installation Figure 2... -
Page 11: Backwash
1 (Contains inner and outer internal seals) When ordering parts specify the strainer size and model number, the strainer serial number and Eaton part number, the description of the part and the part number if known and the quantity required. - Page 12 ISO 9001:2000 Standards to ensure Eaton Filtration warranties its products against defective material and workmanship only. Eaton assumes no responsibility for damage or injury resulting from improper installation, abuse, or misapplication of any product. Eaton assumes no responsibility for damage or injury resulting from chemical incompatibility between its products and the process fluids to which they are subjected.
Need help?
Do you have a question about the 2596 and is the answer not in the manual?
Questions and answers
we have a small amount of oil leaking from the exposed shaft what are the required parts to reseal the end of the shaft
To reseal the exposed shaft on an Eaton 2596 with a small oil leak, the following parts are needed:
- Quad-Rings (C) (1 piece)
- O-Ring (1 piece)
- Gland Gasket (F) (1 piece)
These components help seal the shaft and prevent oil leakage. Additionally, a Process Compatible Lubricant should be used to lubricate the Quad-Rings during installation.
