GENERAL DESCRIPTION
The W91560DN series ICs are Si-gate CMOS ICs that provide the signals needed for either pulse or
tone dialing. They feature 3 number memories and a 12/16-digit LCD driver for displaying telephone
numbers and calling time. A real time clock is included to display the time of day. The W91560DN
series is fabricated using CMOS technology and thus provide good performance in low voltage, low
power applications.
FEATURES
•
One by 32 digits for redial
•
Three by 32 digits for one-touch direct repertory memory
Uses 5 × 6 keyboard
•
•
Pause, Pulse-to-tone (*/T) can be stored as a digit in memory
•
Flash can be stored as a digit in memory when in store mode
•
Minimum tone output duration: 87 mS (81 mS for W91564DNF and W91565DNF)
•
Minimum intertone pause: 87 mS
•
Tone/Pulse mode pin selectable
•
Make/Break ratio pin selectable
•
Dialing rate: 10 ppS
•
Pause time: 3.6 Sec. (2.0 Sec. for W91564DNF and W91565DNF)
•
Flash break time (73 mS, 100 mS, 300 mS or 600 mS) selectable by keypad
Built-in 12 or 16-digit LCD driver (1/4 duty, 1/3 bias) selectable by mask option
•
•
Built-in calling timer from [00:00] to [59:59]
•
Memory check function
•
On-chip power-on reset and clear LCD
•
Uses 3.579545 MHz TV quartz crystal or ceramic resonator
•
Uses 32768 Hz crystal as RTC frequency base
•
Switchable 24-hour clock or 12-hour clock with p.m. mode by keypad
•
0 or 9 dialing inhibition pin for PABX systems or long distance dialing lock out
•
On-hook debounce: 150 mS in normal mode and 20 mS in lock mode
•
Off-hook delay 300 mS in lock mode ( DP will keep low for 300 mS while off hook except the first
off hook after power on reset that DP will keep high for 100 mS then go low for 200 mS)
•
First key-in delay: 300 mS in lock mode
•
Mixed dialing allowed
•
Packaged in 64-pin plastic QFP with RTC
•
The functions of the different dialers in the W91560DN series are shown in following table:
Preliminary W91560DN SERIES
3-MEMORY TONE/PULSE DIALER WITH
RTC AND LCD DISPLAY FUNCTIONS
Publication Release Date: May 1997
- 1 -
Revision A2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winbond W91560DN Series
Summary of Contents for Winbond W91560DN Series
- Page 1 RTC AND LCD DISPLAY FUNCTIONS GENERAL DESCRIPTION The W91560DN series ICs are Si-gate CMOS ICs that provide the signals needed for either pulse or tone dialing. They feature 3 number memories and a 12/16-digit LCD driver for displaying telephone numbers and calling time. A real time clock is included to display the time of day. The W91560DN series is fabricated using CMOS technology and thus provide good performance in low voltage, low power applications.
-
Page 2: Pin Configuration
Preliminary W91560DN SERIES TYPE NO. LCD DIGITS LOCK HOLD PAUSE TIME W91560DNF W91561DLNF 3.6 Sec. W91562DNF W91563DLNF W91564DNF 2.0 Sec. W91565DNF W91560DNH 3.6 Sec. W91562DNH Note: W91564DNF/W91565DNF is only for the French market. The pause time will not be added when in pulse-to-tone function mode. -
Page 3: Pin Description
Preliminary W91560DN SERIES PIN DESCRIPTION SYM. PIN NO. FUNCTION The keyboard inputs may be used with either the standard 5 × 6 Row, 18−21, Column keyboard, an inexpensive single contact (form A) keyboard or 13−17 Inputs electronic input. A valid key entry is defined by a single row being connected to a single column. - Page 4 Preliminary W91560DN SERIES Pin Description, continued SYM. PIN NO. FUNCTION MODE Pulling the mode pin to V places the dialer in tone mode. Pulling the mode pin to V places the dialer in pulse mode (10 ppS, M/B = 2:3).
- Page 5 Preliminary W91560DN SERIES Pin Description, continued SYM. PIN NO. FUNCTION CP, CN 31, 32 CP is the voltage control capacitor positive pin. CN is the voltage control capacitor negative pin. A 0.1 µF capacitor is connected between these two pins.
-
Page 6: Block Diagram
Preliminary W91560DN SERIES BLOCK DIAGRAM SYSTEM CLOCK REAL TIME CLOCK GENERATOR GENERATOR CONTROL LOCK LOGIC READ/WRITE MODE (R1 ~ R4) COUNTER KEYBOARD INTERFACE COLUMN H/P MUTE PULSE/ (C1 ~ C5) TONE T/P MUTE CONTROL LOCATION LOGIC LATCH ROW & COLUMN... - Page 7 Preliminary W91560DN SERIES • RTC: Real time clock toggle key • TIM: a. Display last calling time b. Start and/or stop counting up calling time • HOUR and MIN: Adjusting time setting keys • HOLD1, HOLD2: Hold function keys •...
- Page 8 Preliminary W91560DN SERIES digits c. The one-key redialing function timing diagram is shown in Figure 3. , ∗ (or #), & HFI ¡õ OFF HOOK ON HOOK , ..., & HFI ¡õ , Busy, Come ON HOOK OFF HOOK ON HOOK , ∗...
- Page 9 Preliminary W91560DN SERIES OFF HOOK ON HOOK & , ..., HFI ¡õ & HFI ¡õ , Busy, ON HOOK OFF HOOK ON HOOK Come 1. The first R/P functions as a pause key and the second as a first key-in redial key.
- Page 10 Preliminary W91560DN SERIES & HFI ¡õ OFF HOOK ON HOOK HOLD1 HOLD2 1.The hold function is toggled on and off by the HOLD1 or HOLD2 key. When the hold function is toggled on, the hold mark (dot of digit_4) will be lit and all key-ins (except hold keys and icon keys) will be ignored.
- Page 11 Preliminary W91560DN SERIES 1.The real time clock display mode can be toggled on and off by the RTC key. 2. The icon display will not change when the RTC display mode is entered and set. APSET 1. In the off-hook state, press the APSET key to toggle the RTC function to 24-hour clock mode or 12- hour clock with p.m.
-
Page 12: Electrical Characteristics
Preliminary W91560DN SERIES PARAMETER SYMBOL RATING UNIT −V DC Supply Voltage -0.3 to +7.0 −0.3 Input/Output Voltage +0.3 −0.3 +0.3 Power Dissipation °C Operating Temperature -0.5 to +70 °C Storage Temperature -55 to +125 Note: Exposure to conditions beyond those listed under Absolute Maximum Ratings may adversely affect the life and reliability of the device. - Page 13 Preliminary W91560DN SERIES DC Characteristics, continued PARAMETER SYM. CONDITIONS MIN. TYP. MAX. UNIT DTMF Distortion RL = 10 KΩ = 2.0 to 5.5V DTMF Output DC Level = 2.0 to 5.5V DTMF Output Sink Current = 0.5V = 0.5V DP Output Sink Current Common Output Voltage = 1.5V...
- Page 14 Preliminary W91560DN SERIES AC CHARACTERISTICS −V = 2.5V , F = 3.58 MHz , T = 25° C, all outputs unloaded.) OSC. PARAMETER SYM. CONDITIONS MIN. TYP. MAX. UNIT Key-in Debounce Key Release Debounce Off-hook Delay Time First Key-in Delay Time...
-
Page 15: Timing Waveforms
Preliminary W91560DN SERIES RTC DC Characteristics = 1.5V ,V = 0V , F . = 32,768 Hz , T = 25° C, all outputs unloaded.) PARAMETER SYM. CONDITIONS MIN. TYP. MAX. UNIT Supply Voltage µA Supply Current No Load OSC. Starting Time OSC. - Page 16 Preliminary W91560DN SERIES Timing Waveforms, continued < 600mS < 300mS KEY IN T/P MUTE H/P MUTE DTMF OSC. OSCILLATION OSCILLATION Figure 1(b). Normal Dialing Timing Diagram (Pulse Mode with Lock Function) < 600mS KEY IN T/P MUTE H/P MUTE DTMF OSC.
- Page 17 Preliminary W91560DN SERIES Timing Waveforms, continued < 600mS KEY IN 300mS T/P MUTE H/P MUTE DTMF OSC. OSCILLATION Figure 1(d). Auto Dialing Timing Diagram (Pulse Mode with Lock Function) < 600mS < 300mS KEY IN DTMF T/P MUTE H/P MUTE High OSC.
- Page 18 Preliminary W91560DN SERIES Timing Waveforms, continued < 600mS < 300mS KEY IN DTMF T/P MUTE H/P MUTE OSC. OSCILLATION OSCILLATION Figure 2(b). Normal Dialing Timing Diagram (Tone Mode with Lock Function) < 600mS KEY IN DTMF T/P MUTE H/P MUTE High OSC.
- Page 19 Preliminary W91560DN SERIES Timing Waveforms, continued < 600mS KEY IN DTMF T/P MUTE 300mS H/P MUTE OSC. OSCILLATION Figure 2(d). Auto Dialing Timing Diagram (Tone Mode with Lock Function) < 600mS KEY IN 300mS T/P MUTE H/P MUTE DTMF OSC.
- Page 20 Preliminary W91560DN SERIES Timing Waveforms, continued T/P MUTE High H/P MUTE OSC. OSC. OSC. OSC. Figure 4(a). Handfree Timing Diagram (with Lock Function) T/P MUTE High H/P MUTE High OSC. Figure 4(b). Handfree Timing Diagram (without Lock Function) - 20 -...
- Page 21 Preliminary W91560DN SERIES Timing Waveforms, continued < 600mS KEY IN 300mS T/P MUTE H/P MUTE DTMF OSC. OSCILLATION OSCILLATION Figure 5. Pause Function Timing Diagram (Pulse Mode) < 600mS KEY IN 300mS T/P MUTE H/P MUTE DTMF OSC. OSCILLATION OSCILLATION Figure 6(a).
- Page 22 Preliminary W91560DN SERIES Timing Waveforms, continued < 600mS KEY IN 300mS T/P MUTE H/P MUTE DTMF OSC. OSCILLATION OSCILLATION Figure 6(b). Pulse-to-tone Timing Diagram (W91564DNF and W91565DNF only) KEY IN T/P MUTE HPM MUTE DTMF OSC. OSCILLATION Figure 7. First Priority Flash Timing Diagram...
- Page 23 Preliminary W91560DN SERIES Timing Waveforms, continued ON HOOK OFF HOOK HOLD KEY T/P MUTE High H/P MUTE CHIP ENBLE Figure 8(a). Hold and Handfree Timing Diagram Note: The HOLD KEY cannot be enabled when the chip is disabled. OFF HOOK...
- Page 24 Preliminary W91560DN SERIES Timing Waveforms, continued ON HOOK HOLD1 KEY High T/P MUTE H/P MUTE CHIP ENBLE Figure 8(c). Hold and Handfree Timing Diagram Note: Changing the state of the HKS signal from high to low will initialize the HFO and H/P MUTE signals.
-
Page 25: Lcd Display Format
Preliminary W91560DN SERIES LCD DISPLAY FORMAT A. Normal Dialing Off hook or press "HFI" switch Blinking (Here tone mode was selected). Dial " 0123456789123456" and "78" B. Redialing, Memory Dialing, One Touch Dialing Off hook or press "HFI" switch Blinking (Here tone mode was selected). -
Page 26: Memory Check
Preliminary W91560DN SERIES C. Memory Check Blinking Off-hook or press "HFI" switch (M1= "886P35P770066PP7126", and here pulse mode was selected) Press "CHK" key Blinking Press "M1" key (Display 1 to 16 digits) Press "any key" (Display 17 to 19 digits) D. - Page 27 Preliminary W91560DN SERIES Dial "9375607" If "9375607" is dialed comlepted, the system will start timer after 6 seconds (Timer will start counting up) Press "TIM" key (Timer will stop) Blinking Off-hook or press "HFI" switch (here pulse mode was selected) Dial "9375607"...
- Page 28 Preliminary W91560DN SERIES Press "CHK" key (M2 = "314P4430256") Press "M2" key The system will go back to timer mode after 6 seconds (Timer count up continuously) Press "F1", "F2", "F3" or "F4" key (The timer will stop and the LCD will display a flash mark and flash pattern)
- Page 29 Preliminary W91560DN SERIES E. RTC Setting Function On-hook (Display real time) Off-hook, before press "SET" key Blinking (Here tone mode was selected) Entering "Setting Mode" (Press "SET" key) Blinking Adjusting "Hour" (Press "HOUR" key) (Hour counts forward while the key is depressed) Adjusting "Minute"...
- Page 30 Preliminary W91560DN SERIES LCD PATTERN FOR DATA CHECK LOCK Icon1 Icon2 Icon3 Icon4 Icon5 Icon6 Icon7 Notes: Icon1: Pause Icon2: The icon will be blinking after power on. Icon3: Flash Icon4: Hold Icon5: Handfree Icon6: Timer Icon7: Tone - 30 -...
- Page 31 Preliminary W91560DN SERIES LCD PANEL PATTERN (SEG) (COM) BONDING PAD DIAGRAM 64 63 62 59 58 57 56 55 54 53 9S-1 9S-2 (0,0) Notes: 1. The substrate must be connected to V Publication Release Date: May 1997 - 31 -...
- Page 32 Preliminary W91560DN SERIES 2. The chip size is 2940 × 3630 µm Pad List NAME NAME SEG29 -1335.00 1430.70 OCM1 1335.00 -1307.90 SEG30 -1335.00 1294.50 COM2 1335.00 -1166.10 SEG31 -1335.00 1158.50 COM3 1335.00 -1024.30 SEG32 -1335.00 1022.30 COM4 1335.00 -882.50 -1335.00...
- Page 33 Preliminary W91560DN SERIES Winbond Electronics (H.K.) Ltd. Winbond Electronics North America Corp. Headquarters Winbond Memory Lab. Rm. 803, World Trade Square, Tower II, No. 4, Creation Rd. III, 123 Hoi Bun Rd., Kwun Tong, Science-Based Industrial Park, Winbond Microelectronics Corp.
