Summary of Contents for Grundig Digi 100

  • Page 2: Table Of Contents

    Colour TV sets wit the chassis Digi Basic 3 - CUC 1832, 1930 and 1931 ............e_01/01 Flash programming for the new Digi 100 generation ..................e_02/01 Special functions (options) for the colour TV sets with the chassis Digi 100 ........... e_03/01 Chassis Digi 100 - Flash-Programmer FProg1 ....................e_04/01 Chassis CUC 21…...

  • Page 3: Service Per Mouse Click " ((Flash-Programming,Digi 100 Chassis)

    Dear business partner, For an optimum stationary and mobile product support of our new CTV models generation fitted with the DIGI 100 chassis, we are able to offer you the „Flash-Programmer F-Prog. 1“. This is a service interface enabling the dialogue between the CTV terminal unit and a desktop or notebook PC.
  • Page 4 DM 2,450.00 plus VAT EUR 1,252.67 plus VAT Please place your order directly to : Grundig AG Zentralkundendienst Beuthener Straße 55 D-90471 Nürnberg Kind regards Yours GRUNDIG Central After-Sales Service Enclosure: Hotline and further contact addresses of the supplier of the PC.
  • Page 5 Hotline und weitere Kontaktadressen Bitte halten Sie vor Ihrem Kontakt mit der PC-Hotline oder mit unseren Servicepartnern immer die Identnr. Ihres Geräts griff- bereit (siehe Beispiel Typenschild). PC-Hotline Bei Fragen oder Problemen hilft Ihnen gerne die PC-Hotline weiter. Öffnungszeiten Montag bis Freitag von 9.00 – 18.00 und Samstag von 9.00 – 14.00. Consumer-PC’s (SCENIC Xpert) + 49 (0) 180 / 3 77 70 04 (Tarif DM 0,18/min.) Notebooks...

  • Page 6: M 100 Cd Mk Ii

    Service Information Unit: M 100 CD MK II Possible complaint: CD’s are at times not read, tracks are not found. Remedy: Replacement of the microprocessor CIC 1 carrying the designation D78P048 AGF M 100 CD with a D78P048 AGF CD-05 MK-II. Workshop: In the event of a complaint, replace the microprocessor along with new software.

  • Page 7: Navigation System Gps 3

    Earth Connections are transferred directly to plug (for the car radio). Plug 1: telephone connection (6-pin) GRUNDIG devices since WKC 5300 RDS pink Telephone: AF output black Telephone: earth When using DAB and a navigation system (to be carried out by a qualified workshop): Remove plug 1, pins 11 and 12, and insert them into the corresponding plug of the DAB system.

  • Page 8: Dvd-Player Gdv 100D, Gdv 100D/002, Gdv 110, Gdv 200, Xenaro Gdp 5100, Gdp 5102, Gdp 5120, Gdp 6150, Malaga Se 1230

    Service Information Unit: DVD-Player GDV 100D, GDV 100D/002, GDV 110, GDV 200, Xenaro GDP 5100, GDP 5102, GDP 5120, GDP 6150, Malaga SE 1230 Controlling the DVD players with the TP 100C, TP 110C and TP 130C TV remote controls The basic functions of the above DVD players can be controlled with the TV remote controls TP 100C, TP 110C and TP 130C.

  • Page 9: Satellite Headend Station Stc 1880

    Service Information Satellite headend station STC 1880 Possible complaint: Complete failure of the headend station. The fuse Si 60002 T1 AL, and partly the fuse Si 60020 T2,5 AL, are broken. Cause: Short circuit in the power supply transistor T 60006 (IRF PC 50). Remedy: In addition to replacing the power supply transistor, replace the diode D60006 MUR 480 with a wire bridge.

  • Page 10: Colour Tv Sets Wit The Chassis Digi Basic 3 - Cuc 1832, 1930 And 1931

    Service Information Colour TV sets wit the chassis Digi Basic 3 - CUC 1832, 1930 and 1931 e.g.: Sydney SE 720 Dolby, Xentia M 72-400 Dolby, Denver SE 8250/8 PIP/ Dolby Possible complaint: No picture, no sound. Cause: Failure of the power supply transistor T 60006 (IRF PC50 or 2SK2699). Remedy: In addition to replacing the power supply transistor change the SMD capacitor CC 60014 from 3.3 nF to 10 nF.

  • Page 11: Flash Programming For The New Digi 100 Generation

    - Internet access or InfoTip-System Calling up the current device software The software can be called up from a protected area of the Grundig Internet Homepage after entering your customer number and a password, or it can be called up via the InfoTip-System (under „Service Tips“).
  • Page 12 Note: In the retailer support menu, you may applicate for access by entering your customer number and your address. - Click to spare parts: ordering and listings, service documents. - Enter your custumer number and password. - Click to login. - Click to spare parts lists and service documents.
  • Page 13 Service Information TV 02/01 - Select the desired software under software download. - Copy the selected device software into the folder C:\GRUNDIG\Software of your PC which has been created when installing the F-Prog 1-PC software. The downloaded packed file (*.zip) then must be unpacked by an appropriate unpacker for „ZIP“...
  • Page 14 Service Information Setting hints and special functions (options) for the colour TV sets with the chassis Digi 100 (CUC 1807, 1837, 1838, 1839, 1934, 1935) e.g.: Elegance 70 M 70-300 Dolby, Elegance 70 MW 70-150/8 Dolby, Hamburg SE 8240 Dolby, M84-212/8 Dolby, Toronto SE 7216 Dolby Below you find setting hints and explanations for various functions of the TV sets with the chassis Digi 100.
  • Page 15 „i“ -> „Installation“ -> „Time and date“. 7. AV settings: The sets with the chassis Digi 100 provide the possibility of individually configuring all available AV programme positions. The factory settings are:...

  • Page 16: Chassis Digi 100 - Flash-Programmer Fprog1

    1.1, directly from the Internet (see Online Service brochure). This is to be found under “Reseller Support“, “Software Download“ in the category ”Programming software“, Product group ”DIGI 100”. The updated description of the FProg1, V1.1 software is to be found under Advice ”Operating instructions Flash- Programmer F-Prog1“.
  • Page 17 Chassis CUC 21… - Service Documents Service Manual 720100407000 Service Manual, 1st supplement 720100407100 Dear business partner, despite multiple checks of the printing data we are not immune against printing errors. For this reason please correct the above documents according to the following information. •...

  • Page 18: Colour Tv Sets With The Chassis Cuc 2103 And Cuc 2121

    P 37-4101 TOP Davio, T 55-4101 TOP Davio, T 55-4104 TOP Lemaxx Listed below are the unit types on which the option of retrofitting a satellite retrofit kit SER 2100 has been omitted. In the new GRUNDIG main catalogue, this is not considered in the technical data. In order to distinguish the retrofit option, the version marking at the rear panel has been changed from „VNM“...
  • Page 19 Service Information Necessary settings after replacing the memory EEPROMs for colour TV sets with the chassis CUC 2103, 2105, 2121, and 2130 e.g.: P 37-4101 TOP Davio, T 55-4101 TOP Davio, T 55-4104 TOP Leemaxx, ST 55-854/8 Dolby Possible complaint: After replacing the EEPROM CIC82501 (M24C08) the set is not fully operati- ve despite of loading the emergency data set.

  • Page 20: Burned Battery Socket Or Battery Connecting Cable P 37-830/12 And P 37-840/12 Sat, And Eqivalent Units

    Service Information Number: E/08/01; e_tv081e Burned battery socket or battery connecting cable P 37-830/12 and P 37-840/12 SAT, and eqivalent units Possible complaint: Failure of the 12V power supply due to burned battery sockets or battery connecting cables. Cause : Contact resistance between the battery socket and the plug of the battery connecting cable.

  • Page 21: Damage To The Bottom Corners And Edges Of The Tv Sets Lenaro Mfw 84 - 6110 And Mfw 92 - 6110

    Service Information Number: E/09/01; e_tv091e Damage to the bottom corners and edges of the TV sets Lenaro MFW 84 - 6110 and MFW 92 - 6110 Possible complaint: Damage to the bottom corners and edges on the front side. Cause: Due to the small bottom clearance of the front trim, the corners and edges of the trim can be damaged when putting down the TV set in an inexpert way.

  • Page 22: Tv Sets With Digi 100 Chassis

    Service Information Number: O/01/01; o_tv011e TV sets with Digi 100 chassis Possible complaint: The TV set switches at times to standby and then after several seconds back to normal operation. Cause: This failure may be caused by an uncontrolled oscillation of the CVBS input and a faulty software library of the processor.
  • Page 23 Service Information Number: O/01/01; o_tv011e CBR80240 CC80249 CC80021 CIC82001 CIC80242 CT80090 CR80099 CR80089 CC82021 CT80085 CR82005 CC82005 CR80240 CR80256 Version of the PCB without CC80209 CC80072 CC80073 CC80074 CIC80230 CC80075 CR70098 CR80117 CIC80240 CR80118 CIC80000 CR80119 CR80251 CR80252 CNW80121 CR80250 CR80253 CR80136 CR80254...
  • Page 24 Service Information Number: O/01/01; o_tv011e Table 1: Software assignment The table below shows the unit-specific assignment of the Feature modules and the part number of the associated software, the positions marked with xxxx being variable and indicating the version (e.g. 297981110800). TV set Feature module Software...
  • Page 25 Service Information Number: O/01/01; o_tv011e TV sets not requiring a hardware change For the TV sets listed below from the indicated serial number of the TV set (Made in Austria) or of the chassis (Made in Germany) no hardware change is required. The serial number of the TV set is to be found on the adhesive barcode label below the barcode at the rear of the set.
  • Page 26 Service Information Number: O/01/01; o_tv011e Table 2: TV set production „Made in Austria“ Order Chassis from unit Unit type number name serial number Boston SE 7012 DOLBY GCI2375 CUC 1837 500001 Boston SE 7012 DOLBY GCI2324 CUC 1837 500001 ELEGANCE 70 M 70-300 DOLBY GCK9742 CUC 1837 510800...

  • Page 27: Tp 750/715 And Equivalent Units

    Service Information Number: O/02/01; o_tv021e TP 750/715 and equivalent units Possible complaint: Missing hints to battery polarity in battery compartment. Remedy: Insert the batteries as shown in the figure below. TQ42_4201 (Online)) Alterations reserved.

  • Page 28: St 70-2103 Sat Retrofitting Not Possible

    Service Information Number: O/03/01; o_tv031e ST 70-2103 SAT retrofitting not possible Cause: Plug base ST-V3 missing on several chassis. Remedy: Retrofit the plug base ST-V3 (5-pin), part no. 293038700500. Stockkeeping: Plug base ST-V3 (5-pin), part no. 293038700500 TQ42_4501 (Online) Subject to alterations.
