Kaboodle W-50130 Quick Start Manual

step 2
Follow these
instructions to
add your parts
and accessories.
Things you need to know
• Always read the full instructions prior to installation.
• Consider possible obstructions to your part and accessories,
like hinges inside the cabinet or adjacent cabinet doors
and handles, prior to installation.
• Make sure you leave plumbing and electrical work
to qualified trades people. Never try this yourself.
• Make sure you always use safety gear like a mask, ear muffs
and glasses when using tools.
Hardware included
A
B
slimline lift
mechanism x 2 cover caps x 2
F G
Ø4 x 16mm screws
drilling template x 2
x 4
Tools you will need
To put your kaboodle kitchen accessory together you will need the following tools.
Cordless drill with:
• Number 2 screw tip
• 2mm drill bit
• 5mm drill bit (for
Ø5mm peg holes)
slimline cabinet door lift mechanism
C
mechanism
door brackets x 2
Tape
measure Pencil
• Tip: After marking out the pre-drill holes as per the
instructions, take the part that is to be installed and align
the appropriate holes with the markings to ensure they
match up prior to pre-drilling the holes.
• If you have any questions, contact us on:
Australia: 1800 666 078 Monday to Friday between
8:00am and 6:00pm AEST, New Zealand: 0800 522 663
Monday to Friday between 8:00am and 5:00pm NZST
or email: info@kaboodlegroup.com.au.
D E
door brackets Ø4 x 38mm screws
cover caps x 2
Screw Safety
driver gear
x 6
W-50130 / W-50131
Ver. 1 p. 1
