Kaboodle 1000mm blind corner base cabinet Quick Start Manual

step 1
Follow these
instructions to
build and attach
your cabinet.
Things you need to know
• Base cabinets come with different positions for attaching your
back panel. If you are choosing the rebated back option make
sure you pack out the back of your cabinet before screwing
into the wall.
• All cabinets will need to be attached to the wall using a
minimum of 8 gauge 65mm screws if you have a stud wall.
If your wall is concrete, brick or another surface ask your
hardware specialist for advice on the right fixing method.
• Make sure you leave plumbing and electrical work
to qualified trades people. Never try this yourself.
• For extra strength use exterior woodworking glue
when assembling cabinets.
Hardware included
A B
50mm
wood screws x 25 wood screws x 28
G H
stick on end
caps x 8
Tools you will need
To put your kaboodle kitchen cabinets together you will need the following tools.
Cordless drill with:
• Number 2 screw tip
• 4mm drill bit
• Number 12
countersinking drill bit
Spirit level
(900mm recommended)
KBNZ_Kit_W-70110_1000_blind_cnr_BC-V9 2.indd 1
1000mm blind corner base cabinet
C
28mm shelf
support x 5
door
buffer x 2
Tape
measure Pencil
Wall fixing
(If necessary)
• To help identify panels, counter sunk holes always
face outwards.
• All holes that aren't already pre-drilled should be drilled prior
to screwing using a No 12 countersinking drill bit.
• Make sure you always use safety gear like a mask, ear muffs
and glasses when using tools.
• If you have any questions, contact us on:
Australia: 1800 666 078 Monday to Friday between
8:00am and 6:00pm AEST, New Zealand: 0800 522 663
Monday to Friday between 8:00am and 5:00pm NZST
or email: info@kaboodlegroup.com.au.
D E
14mm adjustable
wood screws x 20
Clamps Safety
(quick release) gear
F
90° angle
legs x 6 bracket x 10
Adjustable 65mm
square wood screw
Ver. 9
25/01/2017 3:56 PM
W-70106
p. 1
