Summary of Contents for Aruba EdgeConnect 10104
- Page 1 Aruba EC-10104 SD-WAN Gateway...
- Page 2 6280 America Center Drive San Jose, CA 95002 www.arubanetworks.com Hewlett Packard Enterprise Company Attn: General Counsel 6280 America Center Drive San Jose, CA 95002 Phone: 800.943.4526 (Toll Free) Phone: 650.750.0350 Aruba EC-10104 SD-WAN Gateway | Installation Guide 0512261-01 | August 2022...
-
Page 3: Table Of Contents
Approve the Discovered Appliance (Gateway)............17 Complete the Appliance Manager Configuration Wizard........17 Specifications, Safety, and Compliance .......... 18 Aruba EdgeConnect 10104 SD-WAN Gateway Specifications ......18 Safety and Regulatory Compliance ..............18 Proper Disposal of Aruba Equipment ..............20 | Installation Guide... -
Page 4: Preface
Preface This document describes the hardware features of the Aruba EdgeConnect 10104 SD-WAN Gateway. It provides a detailed overview of the physical and performance characteristics of the gateway and explains how to install the gateway and its accessories. Guide Overview Chapter 1, “EC-10104 SD-WAN Gateway”... -
Page 5: Ec-10104 Sd-Wan Gateway
Adapter cable saddle Wall mount kit (2 screws, 2 anchors, 1 template) Optional accessories are available for use with the Aruba EdgeConnect 10104 SD-WAN Gateway and are sold separately. Contact your Aruba sales representative for details and assistance. Aruba EdgeConnect 10104 SD-WAN Gateway... -
Page 6: Aruba Edgeconnect 10104 Sd-Wan Gateway Components
EC-10104. Figure 2 shows the back panel of the EC-10104. Figure 1 Front Panel of the Aruba EdgeConnect 10104 SD-WAN Gateway Figure 2 Back Panel of the Aruba EdgeConnect 10104 SD-WAN Gateway Front Panel LED The front panel LED show the power status of the EC-10104. - Page 7 Green (Solid) Link established Green (Blinking) Port is transmitting or receiving data No link STATUS Port status Speed Green (Solid) Link at 1000 Mbps Link at 100/10 Mbps Aruba EdgeConnect 10104 SD-WAN Gateway | Installation Guide EC-10104 SD-WAN Gateway |...
- Page 8 Micro-USB connection takes precedence over the RJ-45 console connection. Micro-USB Driver To use the Micro-USB console port, you must install the Aruba Micro-USB driver on the computer that will manage your SD WAN. To download the driver, perform the following steps: 1.
-
Page 9: Installation
can over heat the gateway. Precautions Dangerous voltage above 240 V AC is always present while an Aruba gateway is plugged into an electrical outlet. Remove all rings, jewelry, and other potentially conductive material before working with this device. -
Page 10: Cable Saddle Installation Instructions
2. Insert the cable into the cable saddle and attach it to the power connector slot. This secures the cable and keeps it in place.See Figure Figure 6 Securing a Cable Your cable saddle installation in now complete. Aruba EC-10104 SD-WAN Gateway | Installation Guide Installation |... -
Page 11: Wall-Mounting Installation Instructions
2. Align the mounting slots on the bottom of the gateway over the screws and slide the unit into place. See Figure Figure 8 Wall Mounting Aruba EdgeConnect 10104 SD-WAN Gateway Aruba EC-10104 SD-WAN Gateway | Installation Guide Installation |... -
Page 12: Rack Mounting Installation Instructions
Rack Mounting Installation Instructions This mounting option allows mounting the EC-10104 SD-WAN Gateway in a two-post 19-inch Telco rack with either the front panel facing outward or the rear panel facing outward using the Aruba 10104-MNT-19 Rack Mount Kit (additional accessory). - Page 13 6. Use the other rubber clamp provided with the mounting kit to secure the adapter on the rack mount tray. See Figure Figure 12 Securing Power Adapter on the Rack Mount Tray Aruba EC-10104 SD-WAN Gateway | Installation Guide Installation |...
- Page 14 9. Mount the rack mount tray within the two-post 19-inch rack using four M6 x 15 mm Phillips pan head screws and a suitable screwdriver. See Figure Figure 14 Rack Mount Installation Aruba EC-10104 SD-WAN Gateway | Installation Guide Installation |...
- Page 15 Figure 16 Inserting the DC cable into the Cable Grommet 12.Connect the DC cable into the DC jack on the device. Rack mount installation of the EC-10104 SD-WAN Gateway is now complete. Aruba EC-10104 SD-WAN Gateway | Installation Guide Installation |...
-
Page 16: Configuring The Gateway
Chapter 3 Configuring the Gateway IMPORTANT - READ THIS FIRST: You must install and register your Orchestrator with the Aruba Cloud Portal BEFORE setting up an EdgeConnect gateway. After Orchestrator is registered with your account name and key, you can proceed with EdgeConnect installation. If you don’t know or are unsure wht role the Orchestrator plays, please contact your network architect or deployment lead. -
Page 17: Approve The Discovered Appliance (Gateway)
2. At the end, click Apply. It may take up to two minutes to register the appliance. 3. Complete the remaining wizard screens. On the Deployment page’s default configuration, the WAN–side interfaces use DHCP IP addresses, unless you manually enter static IP addresses. Aruba EdgeConnect 10104 SD-WAN Gateway | Installation Guide Configuring the Gateway |... -
Page 18: Specifications, Safety, And Compliance
This document can be viewed or downloaded from the following location: www.arubanetworks.com/ safety_addendum Aruba gateways must be installed by a professional installer. The professional installer is responsible for ensuring that grounding is available and it meets applicable local and national electrical codes. FCC Class B Part 15 This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. - Page 19 Changes or modifications to this unit not expressly approved by Aruba, a Hewlett Packard Enterprise company could void the user’s authority to operate this equipment.
-
Page 20: Proper Disposal Of Aruba Equipment
Thailand Regulatory Model Name The regulatory model name for the Aruba EdgeConnect 10104 SD-WAN Gateway is EC-10104. Proper Disposal of Aruba Equipment Waste of Electrical and Electronic Equipment Aruba, a Hewlett Packard Enterprise company products at end of life are subject to...
